Summary of Contents for Telewins WIFI-TW510R
-
Page 1: User Manual
3G WiFi Router Model: WIFI-TW510R USER MANUAL Last Update Time: 2009-10-29 TeleWins ( HK).Co., Ltd. Bldy1, Xiandaichenghuating, Chuangye Road Nanshan District, Shenzhen 518054, P.R.China Tel.: +86-755-86217635 Fax: +86-755-86229325... -
Page 2: Table Of Contents
TeleWins(HK).,Co.LTD Table of Contents 1. PRODUCT OVERVIEW............................4 1.1 I .............................. 4 NTRODUCTION 1.2 A ..............................4 PPEARANCE 1.3 I ..............................5 NDICATORS 1.4 I ..............................5 NTERFACES 1.5 A ..............................5 PPLICATION 2. INSTALLING THE ROUTER..........................7 2.1 I ............................. - Page 3 TeleWins(HK).,Co.LTD 3.8.1 Routing Table ........................... 28 3.8.2 Static Routing ..........................29 3.9 S ............................29 YSTEM OOLS 3.9.1 System Time ............................. 29 3.9.2 Backup Setting ..........................30 3.9.3 Firmware Upgrade........................... 30 3.9.4 Reboot ............................... 31 3.9.5 Reset to Default ..........................31 3.9.6 Password ............................
-
Page 4: Product Overview
Thank you for purchasing the 3G WiFi Router (WIF I-TW510R) of TeleWins(HK). Co., Ltd. The WIFI-TW510R lets you share your broadband Internet access quickly and easily with connection to a 3G/2G (EVDO / HSPA / TD-SCDMA / EDGE) USB modem. It also supports connection to an ADSL/cable modem or Ethernet. -
Page 5: Indicators
To reset the router and restore it to factory default settings when the button is pressed via the end of a paper clip or other small-pointed object. 1.5 Application The WIFI-TW510R is suited for the places where 3G network or ADSL is available: • Coffee shops, lounge bars, hotels, restaurants;... - Page 6 TeleWins(HK).,Co.LTD • Beaches, gardens, swimming pools...; • Sports area and recreation centers, like bowling, billiards...; • Homes, apartments, enterprises, small offices, SOHO in need of Internet sharing; • Exhibition and convention sites; • Mobile vehicles (trains, ships, buses, RVs, etc.)
-
Page 7: Installing The Router
2. Installing the Router 2.1 Installation Steps 1) Locate the router as per the installation environment requirement specified in Section 2.2. If you want to use the WiFi function, you’d better choose the place which has less obstruction between the router and WiFi-enabled devices (e.g. your PC with wireless network card). 2) You can choose to let the router access the Internet either via 3G network or your existing cable/DSL modem. -
Page 8: Configuration Via Web Browser
TeleWins(HK).,Co.LTD 3. Configuration via Web Browser 3.1 Login 1) Open the web browser (Microsoft IE 5.0 or later / Netscape Navigator 6.0 or later) on your PC that is connected to the router. In the Address bar, type “192.168.1.1” (the default IP address of the router) and then press “Enter”, the login window as shown in the figure below will appear to let... -
Page 9: System Status
TeleWins(HK).,Co.LTD 3.2 System Status In the web configuration interface, click Staus in the left menu to check the current working status, parameter settings and system logs of the router. There are 2 sub-menus: Status and Syslog. 3.2.1 Status In the web configuration interface, click System Status -> Status in the left menu to check the current status and settings of the router as shown in below figure. -
Page 10: System Logs
TeleWins(HK).,Co.LTD Fields Description Current settings and information of the LAN Port, including the MAC Address, IP Address, and Subnet Mask. Wireless Current settings and information of the WiFi connection, including the Wireless Radio, SSID, Channel, Mode, MAC Address, and IP address. -
Page 11: Dynamic Ip
TeleWins(HK).,Co.LTD shall choose the type of WAN connection: Static IP Address, Dynamic IP Address, PPP over Ethernet, or 3G. If you need the router to access the Internet via 3G network (you have inserted a 3G USB modem to the router), please choose the option of 3G. -
Page 12: Static Ip
TeleWins(HK).,Co.LTD Fields Description Maximum Transmission Unit. The normal value for most Ethernet networks is 1500 bytes. For some ISPs you may need to enter a lower value. But this is rarely required and shall not be done unless you are sure that it’s necessary for your ISP connection. -
Page 13: Ppp Over Ethernet
TeleWins(HK).,Co.LTD Secondary DNS ISP. 3) PPP over Ethernet If you choose PPP over Ethernet, you shall have the login username and password offered by your ISP. The configuration interface will show as below. You shall enter the values as per the following description and then click the Save Settings button. -
Page 14: Mac Clone
TeleWins(HK).,Co.LTD Fields Description Access Point Name. The name used to identify a UMTS/GPRS service in the global 3G/GSM network. Some 3G operators adopt “internet” as their APN. Please consult your local 3G ISP to get the correct APN and enter it in this field. -
Page 15: Ddns
TeleWins(HK).,Co.LTD Fields Description Use the device’s MAC Address Choose this to maintain the MAC address of the router, if you have registered the router’s MAC address or your ISP doesn’t require registering MAC address. Use this PC’s MAC Address Choose this to change the MAC address of the router to that of the PC which is connecting to the router, if you have registered the PC’s MAC address. -
Page 16: Lan Setting
TeleWins(HK).,Co.LTD 3.4 LAN Setting In the web configuration interface, click LAN Setting in the left menu to configure the LAN (local area network) connection of the router (i.e. how the router share the Internet access). There are 3 sub-menus: Basic Setting, DHCP Setting and DHCP Table. -
Page 17: Dhcp Table
TeleWins(HK).,Co.LTD the DHCP parameters of your LAN. The router is set up by default as a DHCP (Dynamic Host Configuration Protocol) server, which provides TCP/IP configuration to all the devices that are connected the router on the LAN. The configuration interface will show as below. You shall enter the values as per the following description and then click the Save Settings button. -
Page 18: Wlan Setting
TeleWins(HK).,Co.LTD Fields Description IP Address The IP address that is assigned to the DHCP client. Host The host name of the DHCP client. MAC Address The MAC address of the DHCP client. 3.5 WLAN Setting In the web configuration interface, click WLAN Setting in the left menu to configure the WiFi connection of the router. -
Page 19: Security
TeleWins(HK).,Co.LTD WiFi-enabled devices. The value can include up to 32 characters and is case-sensitive. Wireless Channel This field determines what channel (operating frequency) will be used by the WiFi module of router. It is not necessary to change the value unless you notice interference problems with another nearby WiFi access point. -
Page 20: Advanced Setting
TeleWins(HK).,Co.LTD Default KEY ID Select which of the 4 keys below will be used for the encryption. The key will be required when your WiFi-enabled device is connecting to the router. WEP KEY 1 ~ WEP KEY 4 After you specify the Default KEY ID, you shall choose the key format (“HEX”... -
Page 21: Security
TeleWins(HK).,Co.LTD encounter inconsistent data flow, only minor modifications are recommended. Beacon Period This field specifies the interval between beacon packets. A beacon is a packet broadcast by the router to synchronize the wireless network. The default value is 100 (milliseconds). -
Page 22: Url Filter
TeleWins(HK).,Co.LTD Fields Description Firewall Choose to switch on or off the general SPI firewall of the router. Block the ICMP Packet If you check this, you can prevent your network from being “pinged” from WAN or detected, by other Internet users. This function also reinforces your network security by hiding your network ports. -
Page 23: Mac Filter
TeleWins(HK).,Co.LTD Fields Description URL Filter Choose to enable or disable the URL filter. Filter Mode This field defines the global policy for the URL filtering section. - Only Deny: allow everything and deny only the URLs in the below list;... -
Page 24: Acl Setting
TeleWins(HK).,Co.LTD Fields Description MAC Filter Choose to enable or disable the MAC filter. MAC Address Enter the appropriate MAC addresses into the fields. The MAC address shall be entered in this format: xx-xx-xx-xx-xx-xx (where x is any hexadecimal digit), for example, 00-0E-BE-00-B0-00-0B. -
Page 25: Forwarding
TeleWins(HK).,Co.LTD Fields Description Source IP Address Enter the range of IP address of devices in your LAN to allow or deny the traffic from these devices. Dest IP Address Enter an external IP address to allow or deny outgoing traffic to this destination IP address. -
Page 26: Nat/Napt
TeleWins(HK).,Co.LTD In the web configuration interface, click Forwarding in the left menu to configure the security setting of the router. There are 3 sub-menus: NAT/NAPT, Port Forwarding and DMZ. 3.7.1 NAT/NAPT In the web configuration interface, click Forwarding -> NAT/NAPT in the left menu to configure the NAT/NAPT setting. -
Page 27: Dmz
TeleWins(HK).,Co.LTD Fields Description Services Choose the type of service. Service Name Specify the name of the service. Service Port Enter the range of external port numbers (the port numbers seen by users on the Internet and forwarded to your PC or device in your LAN). -
Page 28: Routing Setting
TeleWins(HK).,Co.LTD Fields Description Choose to enable or disable the DMZ hosting feature. DMZ Host Specify the IP address of the PC/device to be used as the DMZ host. 3.8 Routing Setting In the web configuration interface, click Routing Setting in the left menu to check the current list of static routes and configure the static routes in the router. -
Page 29: Static Routing
TeleWins(HK).,Co.LTD - Lo (loopback): a dummy network in which one PC acts like a network, necessary for certain software programs. 3.8.2 Static Routing In the web configuration interface, click Routing Setting -> Static Routing in the left menu to build static routes in the router. -
Page 30: Backup Setting
TeleWins(HK).,Co.LTD Fields Description Time Server Choose the appropriate NTP server address. Time Zone Choose the appropriate time zone for your local place. 3.9.2 Backup Setting In the web configuration interface, click System Tools -> Backup Setting in the left menu to save the current configuration of router as a backup in the PC connecting to the router, or restore the configuration backup you saved before. -
Page 31: Reboot
TeleWins(HK).,Co.LTD If your router is not experiencing problems, there is no need to upgrade the firmware, unless the new firmware supports a new feature you need. Click the Browse button to select the firmware file for upgrading, and then click the Upgrade button. -
Page 32: Password
TeleWins(HK).,Co.LTD Choose Yes and click the Save Settings button to reset all configurations to their default values, which include: Default user name: admin; Default password: admin; Default IP address: 192.168.1.1; Default subnet mask: 255.255.255.0; 3.9.6 Password In the web configuration interface, click System Tools -> Password in the left menu to change the default password to login the router. -
Page 33: Technical Specifications
TeleWins(HK).,Co.LTD 4. Technical Specifications Specifications Supported Frequency Band EVDO: 800/1900 MHz, HSDPA-HSUPA: 850/1900/2100 MHz, TD-SCDMA: 2100MHz Data Speed 802.11b/g Access Point auto rate up to 54 Mbps Supported 3G USB Modem Huawei: E156 / E160 / E180 / E230 (HSPA), EC226 / EC1260 (EVDO), ET128 (TD-SCDMA);... -
Page 34: Service After Sale
Your satisfaction is our priority. Offering a quick and effective technical support, we always put the customer first. Please don’t hesitate to contact us by the following ways if you have any questions. TeleWins( HK).Co., Ltd. Bldy1, Xiandaichenghuating, Chuangye Road Nanshan District, Shenzhen 518054, P.R.China Tel.: +86-755-86217635...
