MEC-DIS-M002
Mini PCI-e DVI/VGA output graphic board
User's Manual
Third Edition, February 2014
© 2014 Cervoz Co., Ltd. All rights reserved.
Reproduction without permission is prohibited

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MEC-DIS-M002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cervoz MEC-DIS-M002

  • Page 1 MEC-DIS-M002 Mini PCI-e DVI/VGA output graphic board User’s Manual Third Edition, February 2014 © 2014 Cervoz Co., Ltd. All rights reserved. Reproduction without permission is prohibited...
  • Page 2 Copyright Notice © 2014 Cervoz Co., Ltd. All rights reserved. Reproduction without permission is prohibited. Trademarks Cervoz is a registered trademark of Cervoz Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer Information in this document is subject to change without notice and does not represent a commitment on the part of Cervoz.
  • Page 3: Table Of Contents

    Features Installation Flowchart Package Checklist Chapter 2 Hardware Installation Chapter 3 Software Installation Chapter 4 Troubleshooting Appendix Pin Assignments Board Side Pin Assignments Device Side Pin Assignments Technical Reference MEC-DIS-M002 Specifications MEC-DIS-M002 Dimensions MEC-DIS-M002 Daughter Board Dimensions Product Warranty Statement...
  • Page 4: Introduction

    Introduction Overview MEC-DIS-M002 is a graphic card for embedded PC. The card follows the Mini PCI-e standard which is complaint with PCI Express x 1 classification and small form factor (30.00 x 50.95 mm). This board fits in any host computer that has Mini PCI-e card slots.
  • Page 5: Installation Flowchart

    Installation Flowchart Installation Flowchart of MEC-DIS-M002 The following flowchart provides a brief summary of the procedure you should follow to install the Mini PCI-e card: Hardware Installation Connect the internal cable Hardware Installation Install the card in the Mini PCI-e slot...
  • Page 6: Hardware Installation

    Hardware Installation This chapter describes the PCI Express Series hardware installation procedure. Since the BIOS automatically assign the PCI Express board’s IRQ number and I/O addresses, you must plug in the board before installing the driver. Step 1 Connect the internal cable to the card Connect the internal cable to the card Both sides of the cable connectors are the same, it doesn’t matter which side Note...
  • Page 7 Step 2 Install the card to the Mini PCI-e slot Make sure you install the card in the right position (fool-proof design) Step 3 Fix the card on the motherboard (clip type or screw type) There are 2 options to fix the card. It depends on the design of the motherboard (clip or screw).
  • Page 8 Step 4 Card installation completed Find any place on mother board that you can screw the ground cable. Step 5 Connect the cable to the daughter board Connect other side of the cable to the daughter board Connect the ground cable on daughter board or chassis or mother board where you can screw it.
  • Page 9 Connector Fixation MECFIX – Versatile Mounting 1. Standard PCI/PCIe Bracket PCI / PCIe IO Bracket 2. Low Profile PCI/PCIe Bracket Low Profile IO Bracket...
  • Page 10 3. Internal Mounting Upper Fixation – Industrial System Right & Left Fixation – Industrial System...
  • Page 11 4. Customized Front / Rear Plate Front / Rear I/O Plate Universal Bracket...
  • Page 12: Software Installation

    Software Installation This chapter gives installation, configuration, and update/removal procedures for the driver for Win 2003, Win XP, Win Vista, Win 7, and Win 8. Step 1 Turn on PC and start Windows Note XP OS as example...
  • Page 13 Step 2 Windows automatically detects the new device If the card is installed properly, system would detect the new device and the hardware wizard would start automatically. Click “Cancel” to disregard Step 3 Insert CD Open the CD drive...
  • Page 14 Find the “MEC-DIS-M002” folder Step 4 Open the “MEC-DIS-M002” file folder Find the “Driver” folder Step 5 Open the “Driver” folder...
  • Page 15 Step 6 Find the appointed OS folder (Ex.: XP) Open the appointed OS folder (We use XP as an example in the above picture) Make sure you select the correct OS Step 7 Find your OS version (Ex.: XP 32bit) Select appoint OS folder (We use XP 32bit as an example in the above picture) Make sure you select the correct version of the OS (Ex.: 32-bit or 64-bit)
  • Page 16 Find the “setup” file Step 8 Run the “set up” file Step 9 Driver installation set up Click “Next”...
  • Page 17 Step 10 Select destination location Select the location where the driver will be installed Click “Next” If you are not sure what location to be installed, keep the default setting and Note click “Next”.
  • Page 18 Step 11 Select Start Menu folder Select the start menu folder Click “Next” Note: If you are not sure what folder to be selected, keep the default setting Note and click “Next”. Step 12 Start driver installation Click ”Install”...
  • Page 19 Step 13 Installation in progress Step 14 Disregard logo testing Before installation is completed, logo testing window would pop out. Disregard this information and continue the installation progress Click “Continue Anyway”...
  • Page 20 Step 15 Driver installation completed, restart PC Select “Yes, restart the computer now” Click “Finish” Step 16 Confirm if driver is installed When you restart Windows, you would find the SMI icon on the right bottom corner Start “Computer Management” program →...
  • Page 21: Troubleshooting

    Troubleshooting If MEC-DIS-M002 is removed from motherboard, a warning window would pop out stating “No SMI graphics driver to support the control panel!” Causes Solutions Once MEC-DIS-100 is removed from 1. Remove the driver → Route: Control Panel Add or motherboard, the driver is not able to →...
  • Page 22: Appendix

    Appendix Pin Assignments ...
  • Page 23: Board Side Pin Assignments

    Board Side Pin Assignments Wire to Board Connector (CN10、CN11) Description Description TD0+ DDC_CLK TD0- TD1+ CRT_Red TD1- CRT_Green TD2+ CRT_Blue TD2- CRT_HSYNC CRT_VSYNC DDC_SDA DVI_DHP (Hot Plug) DDC_SCL DDC_DAT Device Side Pin Assignments DVI-I Port Female Connector (DVI_I1) Description Description Description TD2- TD1-...
  • Page 24: Technical Reference

     Technical Reference MEC-DIS-M002 Specifications General PCI-Express Revision PCI-Express Base Specification Rev 1.1 PCI-Express Electromechanical PCI-Express Mini Card Electromechanical Rev. 1.1 Revision Hardware Controllers SiliconMotion SM750 with 16MB DDR SDRAM Single-Lane (x1) PCI-Express with throughput up to 2.5Gbps Interface (Connector)
  • Page 25: Mec-Dis-M002 Dimensions

    MEC-DIS-M002 Dimensions MEC-DIS-M002 Dimensions...
  • Page 26: Product Warranty Statement

    Limitation of Liability Cervoz’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.
