Long Range 802.11b/g/n USB Adapter

for OUTDOOR use

User Manual

Revision 1.0

Table of Contents

Need help?

Do you have a question about the AOU-2410 and is the answer not in the manual?

Questions and answers

Summary of Contents for ALCON AOU-2410

Page 1: User Manual
Long Range 802.11b/g/n USB Adapter for OUTDOOR use User Manual Revision 1.0...
Page 2 Make sure there are antennas installed on each unit, otherwise the RF will be damaged when power is on. Note...
Page 3 FCC Notice NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 4: Before You Begin
CD-ROM autorun feature is disable. Run Autorun.exe in the CD’s root directory. 4. Click Install AOU-2410 for your adapter. If you are using Windows Vista, the User Account Control window may display. To proceed with the installation, click Continue (if you are performing the installation using an account that has no administrative privileges, you may also need to enter the user name and password for an administrative account).
Page 5 6. If you wish to install the driver with utility software (recommended), select Install driver and Ralink WLAN Utility. If you wish to install driver only, click Install driver only and click Next>.
Page 6 7. If you wish to use the software included with the adapter (recommended), select Install driver and Ralink Configuration Tool and click Next>. If you wish to use your system’s wireless network wizard, select Microsoft Zero Configuration Tool and click Next>.
Page 7 8. Click Install to install the driver and configuration utility. 9. If a restart is required, select Yes to restart my computer now to restart the computer after the installation or select No to restart the computer at a later...
Page 8 http://www.alcon.tw...
Page 9: Installing The Adapter
Installing the adapter 1. Turn on the computer and wait for the operating system to launch. Log in, if necessary. 2. Plug the adapter into a USB port. 3. If the Found New Hardware Wizard window appears, select Install the software automatically (recommended) and click Next.
Page 10 2. Main pane – this pane displays contents of select Tab. 3. Secondary pane – this pane contains connection information or additional options for selected in main pane option. Click More ( ) button to show secondary pane or Less ( ) button to hide it.
Page 11: Profile Tab
Profile Tab This Tab allows you to create profiles for the most frequently used wireless network, i.e. home network, company network or public hotspots. The profile can be activated as required. Profile List –This list contains configured profiles, profile name, SSID, information.
Page 12 Profile configuration – System Config Tab This Tab allows configuration of basic connection parameters. Profile Name – Enter a name to identify your profile. Default is PROF1. SSID –Enter a network service set identifier (SSID) or select from a list of active networks.
Page 13 Profile configuration – Auth. \ Encry. Tab This Tab contains all Authentication and Encryption settings Authentication:  Open –With the Open method, every wireless station can request authentication.  Shared –With the Shared authentication, the station requesting authentication must provide a secret key (which can be obtained from network administrator) using a secure channel (independent of the 802.11...
Page 14  Authentication: LEAP Authentication –Change authentication method. Identity –Enter your identity for the LEAP authentication service. Password –Enter your password for the LEAP authentication service. Domain Name –Enter your domain name for the LEAP authentication service.  Authentication: WPA and WPA2 Authentication –Change authentication method.
Page 15 Authentication –Change authentication method. Encryption –Select the encryption method to be used.  AES (Advanced Encryption System) uses symmetrical 128-bit data block encryption.  TKIP (Temporal Key Integrity protocol) uses stronger encryption algorithms and MIC (Message Integrity Check) to provide security against hackers.
Page 16 Profile configuration – 802.1x Tab Settings on this Tab allow IEEE 802.1x protocol. All information can be obtained from wireless network administrator. Appearance of this Tab depends on options selected from EAP method and Tunnel Authentication lists.  PEAP –Protect Extensible Authentication Protocol. PEAP transports secured authentication data by using tunneling between PEAP clients and an authentication server.
Page 17 EAP Method –Change EAP authentication method. Tunnel Authentication –Change tunnel authentication method. Session Resumption –Enable/disable session resumption. Authentication ID / Password –Identity, Password and Domain Name for server. Only EAP-FAST authentication can key in domain name. Domain name can be keyed in blank space.
Page 18: Client Certificate Tab
Client Certificate Tab Use Client certification –Enable this option to use Client certificate for server authentication and then select certificate from drop-down list. You can find detailed information on certificate below this list. Server Certificate Tab Use certificate chain –Enable this option, to enable the certification feature and select the certificate issue.
Page 19 EAP-Fast Tab Allow unauthenticated provision mode –During the PAC can be provisioned (distributed on time) to the client automatically. It only supported Allow unauthenticated provision mode and use EAP-MSCHAP v2 authentication to authenticate now. It causes to continue with the establishment of the inner tunnel even through it is made with an unknown server.
Page 20: Network Tab
Network Tab Icons on list means: Show dBm – Check this box to show signal strength on AP List as dBm instead of percentages. This also applies to Signal Strength and Noise Strength in secondary pane. AP List –List of wireless networks in range. Columns contain follow information: SSID (hidden when SSID Broadcast on AP is disabled), network type icon (infrastructure or Ad hoc) and used channel, supported 802.11...
Page 21 Detailed network information  General Tab General information on network and security. SSID –Network SSID or Hidden if AP doesn’t broadcast SSID. MAC Address –MAC address of AP. Authentication Type –Authentication used by this network. Encryption Type –Encryption used by this network.
Page 22 Config Methods – Correspond to the methods that AP supports as an Enrollee for adding external Registrars (a bitwise or of values). Value Hardware Interface 0x0001 USBA (Flash Drive) 0x0002 Ethernet 0x0004 Label 0x0008 Display 0x0010 External NFC Token...
Page 23  CCX Tab Information regarding CCX (Cisco Compatible eXtensions) supported by 802.11n Tab  Detailed information about APs support of 802.11n protocol and its functions. FALSE value means the function is not supported or disabled. TRUE means supported and enabled.
Page 24: Advanced Tab
Advanced Tab This Tab can be used to change advanced wireless network adapter options. Wireless mode –Select wireless mode in which adapter will work. Enable TX Burst –Selecting this mode may accelerate frame transmission. Enable TCP Window Size –Selecting this feature may improve TCP performance on wireless connections.
Page 25: Statistics Tab
Statistics Tab This Tab shows Transmit and Receive statistics. Frames Transmitted Successfully –shows the number of frames transmitted errors. Frames Retransmitted Successfully –shows the number of frames transmitted successfully after retrying. Frames Fail To Receive ACK After All Retries –shows the number of frames which did not receive acknowledgement after all retries.
Page 26 CRC errors. Frames Dropped Due To Out-of-Resource –shows the number of frames dropped due to resource issue. Duplication Frames Received –show the number of duplicate frames received. Reset Counter –Click this button to reset all Receive statistics.
Page 27 WMM Tab This Tab contains settings for WMM (Wi-Fi Multimedia), which provide basic QoS (Quality of Service) for 802.11 networks. WMM prioritize traffic base on four Access Categories (AC): Voice, Video, best effort and background. WMM doesn’t guarantee throughput for ACs and can be used for VOIP applications.
Page 28 WPS Tab The primary goal of Wi-Fi Protected Setup (Wi-Fi Simple Configuration) is to simplify the security setup and management of Wi-Fi networks. Ralink STA as an Enrollee or external Registrar supports the configuration setup using PIN configuration method or PBC configuration method through an internal or external Registrar.
Page 29 Connect –Command to connect to the selected network inside credentials. The active selected credential is as like as the active selected Profile. Rotate –Command to rotate to connect to the next network inside credentials. Disconnect –Stop WPS action and disconnect this active link. And then select the last profile at the Profile Page of RaUI if exists.
Page 30 Credential information Modification of these settings is possible only in Registrar mode. SSID –Network SSID in credential. BSSID –Network BSSID in credential. Authentication Type –Authentication used by network in credential. Encryption Type –Encryption used by network in credential. Key Length –Encryption Key length.
Page 31: About Tab
About Tab This Tab contains driver, application and network adapter information. RaConfig Version –Shows the version of the RaConfig application. Driver Version –Shows the current driver version. Date –Shows the application/driver release date. EEPROM Version –Shows the current EEPROM revision.
Page 32  Restart your PC and repeat the hardware and software installation as specified in this User Manual. I cannot communicate with other computers linked via Ethernet in the Infrastructure configuration.  Make sure the power of the PC with Adapter associated is on.
Page 33: Appendix A: Specification
Appendix A: Specification Standards Compliance IEEE 802.11b/g, 802.11 draft n 2.0, USB 2.0 Chipsets Solution RT3070L Modulation IEEE802.11b: CCK,DQPSK,DBPSK IEEE802.11g: OFDM with BPSK, QPSK, 16QAM, 64QAM IEEE802.11n draft 2.0: America/FCC：2.412~2.462 GHz (11 channels) Frequency Band Europe CE/ETSI：2.412~2.472 GHz (13 channels) Japan : 2.412~2.484 GHz (14 channels)
