- Page 1 USER GUIDE & INSTALLATION INSTRUCTIONS 1100 Dual Fuel...
- Page 2 RED ONION, GOATS CHEESE AND WALNUT FILO TARTLETS • A good handful of chopped walnuts • 1 pack of filo pastry • 25 g butter • 1 tablespoon olive oil • 150 g soft goat’s cheese, chopped • Half 85 g bag of watercress roughly torn/chopped METHOD 1.
-
Page 3: Table Of Contents
Contents Before You Start... Troubleshooting Important! Installation Installation and Maintenance Dear Installer Peculiar smells Safety Requirements and Regulations If you smell gas Provision of Ventilation Ventilation Location of Cooker Personal Safety Conversion Cooker Care Positioning the Cooker Cleaning Moving the Cooker Cooker Overview Completing the Move Hotplate Burners... -
Page 5: Before You Start
1. Before You Start... If You Smell Gas Your cooker should give you many years of trouble-free cooking if installed and operated correctly. It is important • DO NOT turn electric switches on or off that you read this section before you start, particularly if you •... -
Page 6: Cooker Care
When the oven is on, DO NOT leave the oven door DO NOT use water on grease res and never pick open for longer than necessary, otherwise the up a aming pan. Turn the controls o and then control knobs may become very hot. smother a aming pan on a surface unit by covering the pan completely with a well tting lid or baking When using the grill, make sure that the grill pan... -
Page 7: Cooker Overview
2. Cooker Overview DocAUS.020-0004 - Overview - 110DF - Elan Fig.2-1 The 1100 dual fuel cooker (Fig.2-1) has the following features: Fig.2-2 5 hotplate burners including 1 wok burner A control panel A glide-out grill Main multi-function oven Fan oven... -
Page 8: Wok Burner
Adjust the ame height to suit by turning the knob anti- Fig.2-3 clockwise (Fig.2-3). On this cooker the low position is beyond high, NOT between high and o . If a burner ame goes out, turn o the control knob and leave it for one minute before relighting it. -
Page 9: The Griddle (Optional Extra)
The Griddle (optional extra) Fig.2-11 The griddle ts over the left-hand pan supports, front to back (Fig.2-11). It is designed for cooking food on directly. DO NOT use pans of any kind on it. The griddle surface is non-stick and metal cooking utensils (e.g. -
Page 10: The Ovens
The Ovens Fan oven This function operates the fan and the heating References to ‘left-hand’ and ‘right-hand’ ovens apply as viewed element around it. An even heat is produced from the front of the appliance. throughout the oven, allowing you to cook large The left-hand oven is a multi-function oven, while the right- amounts quickly. -
Page 11: Operating The Ovens
Browning element Function This function uses the element in the top of the To thaw small items in the oven without oven only. It is a useful function for the browning Defrost heat or nishing of pasta dishes, vegetables in sauce, A full cooking function, even heat shepherds pie and lasagne, the item to be browned being Fan oven... -
Page 12: Accessories
Accessories Fig.2-20 Fig.2-21 Oven Shelves The cooker is supplied with the following: 3 standard shelves (Fig.2-20) 1 drop shelf (Fig.2-21) 1 telescopic shelf with runners (Fig.2-22) 2 sets of side supports (Fig.2-23) The oven shelves are retained when pulled forward but can Fig.2-22 Fig.2-23 be easily removed and re tted. -
Page 13: Storage
Storage Fig.2-29 The bottom drawer is for storing oven trays and other cooking utensils. To open, simply push the drawer in and release. It can get very warm, so do not store anything in it that may melt or catch re. Never store ammable materials in the drawer. -
Page 14: Cooking Tips
3. Cooking Tips Cooking with a Multi-function Oven General Oven Tips Remember: not all modes are suitable for all food types. The The wire shelves should always be pushed rmly to the back oven cooking times given are intended for a guide only. of the oven. -
Page 15: Cooking Table
4. Cooking Table DocNo.031-0004 - Cooking table - electric & fan single cavity The oven control settings and cooking times given in the table below are intended to be used AS A GUIDE ONLY. Individual tastes may require the temperature to be altered to provide a preferred result. -
Page 16: Cleaning Your Cooker
5. Cleaning Your Cooker Essential Information Fig.5-1 Isolate the electricity supply before carrying out any thorough cleaning. Allow the cooker to cool. NEVER use paint solvents, washing soda, caustic ArtNo.311-0028 - Burner head off cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. -
Page 17: Stainless Steel Main Top
Wipe loose debris from the main top. Avoid using any Fig.5-4 abrasive cleaners including cream cleaners. For best results use a liquid detergent cleaner. Rinse with cold water and thoroughly dry with a clean, soft cloth. Make sure all parts are dry before repositioning. Griddle (optional extra) Always clean the griddle after use. -
Page 18: Control Panel And Oven Doors
Control Panel and Oven Doors Fig.5-8 Avoid using any abrasive cleaners including cream cleaners. For best results, use a liquid detergent. The control panel and control knobs should only be cleaned with a soft cloth wrung out in clean hot soapy water – but take care that no surplus water seeps into the appliance. -
Page 19: Cleaning Table
Cleaning Table Cleaners listed (Table 5-1) are available from supermarkets or electrical retailers as stated. For enamelled surfaces use a cleaner that is approved for use on vitreous enamel. Regular cleaning is recommended. For easier cleaning, wipe up any spillages immediately. Hotplate Part Finish... -
Page 20: Troubleshooting
6. Troubleshooting Hotplate ignition or cooktop burners faulty The knobs get hot when I use the oven, can I avoid this? Is the power on? Yes, this is caused by heat rising from the oven, and heating them up. Do not leave the oven door open. Are the sparker (ignition electrode) or burner holes blocked by debris? The fascia gets hot when I use the oven or grill... - Page 21 Oven temperature getting hotter as the cooker gets older Fig.6-1 If turning the knob down has not worked or only worked for a short time then you may need a new thermostat. This should be tted by a service person. The door is misaligned The bottom hinge of either oven door can be adjusted to alter the angle of the door (Fig.6-1).
-
Page 22: Installation
INSTALLATION Check the appliance is electrically safe and gas sound when you have nished. 7. Installation Dear Installer In the UK the cooker must be installed in accordance with: Before you start your installation, please complete the details below, so that, if your customer has a problem relating to •... -
Page 23: Location Of Cooker
INSTALLATION Check the appliance is electrically safe and gas sound when you have nished. Checking the Parts: Location of Cooker The cooker may be installed in a kitchen/kitchen diner but 5 pan supports Wok cradle NOT in a room containing a bath or shower. This appliance is designed for domestic cooking only. -
Page 24: Positioning The Cooker
INSTALLATION Check the appliance is electrically safe and gas sound when you have nished. Positioning the Cooker Fig.7-1 Fig.7-1 shows the minimum recommended distance from the 75 mm 75 mm cooker to nearby surfaces. 800 mm The cooker should not be placed on a base. Above hotplate surround should be level with, or above, any adjacent work surface. -
Page 25: Completing The Move
INSTALLATION Check the appliance is electrically safe and gas sound when you have nished. Removing the Storage Drawer Fig.7-5 Pull the drawer out to its furthest point. Push the ends of the plastic clips – down on the left-hand side, up on the right-hand side – to release the catches holding the drawer to the side runners. -
Page 26: Installing The Flue Vent
INSTALLATION Check the appliance is electrically safe and gas sound when you have nished. Fitting the Stability Bracket or Chain Fig.7-10 Unless otherwise stated, a cooker using a exible gas Restraining connector must be secured with a suitable stability device. chain Suitable stability devices are shown in Fig.7-10, Fig.7-11 and Fig.7-12. -
Page 27: Conversion To Another Gas
INSTALLATION Check the appliance is electrically safe and gas sound when you have nished. Gas Connection Fig.7-14 This must be in accordance with the relevant standards. The exible hose (not supplied with the cooker) must be in accordance with the relevant standards. Hoses may be purchased at most builders’... -
Page 28: Electrical Connection
INSTALLATION Check the appliance is electrically safe and gas sound when you have nished. Electrical Connection Fig.7-15 The cooker must be installed by a quali ed electrician, in accordance with all relevant British Standards/Codes of Practice (in particular BS 7671), or with the relevant national and local regulations. -
Page 29: Final Fitting
INSTALLATION Check the appliance is electrically safe and gas sound when you have nished. Final Fitting Fig.7-17 Fitting the Bottom Panel Open the left-hand oven door and make sure the storage drawer is removed. Note: For safety’s sake make sure the drawer runners are out of the way. -
Page 30: Conversion To Lp Gas
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have nished. 8. Conversion to LP Gas Check the ‘Technical Data’ section at the back of the book Fig.8-1 that the hob is convertible to the gas you want to use. -
Page 31: Reassembling To Liquid Propane Gas
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have nished. Re t each of the burner bases; make sure to reconnect the Fig.8-4 Fig.8-5 ignition leads and slide the insulating sleeves in place. -
Page 32: Circuit Diagram
9. Circuit Diagram P095199 P095199 P028728 br b The connections shown in the circuit diagram are for single-phase. The ratings are for 230 V 50 Hz. Code Colour Code Description Code Description Left-hand MF oven control Right-hand fan oven control Blue Left-hand MF oven control switch Right-hand fan oven thermostat... -
Page 33: Technical Data
10. Technical Data ArtNo.105-0008 - Technical data - 90 induction - Elan The cooker is category II 2H3+ . It is supplied set for group H natural gas. A conversion kit from NG to LP is packed with the cooker. INSTALLER: Please leave these instructions with the User. -
Page 35: Out Of Warranty
For warranty compliance, the requirements are that the appliance: Name of Appliance & Colour* • Has been correctly installed in accordance with current legislation, relevant British and European Standards and Codes of Practice, by a suitably competent person registered with Gas Safe or equivalent body and, where applicable, a qualified Appliance Serial Number* electrician. - Page 36 For over 45 years Divertimenti, Mercury’s sister company, has been the ultimate destination for food lovers and serious chefs alike. With its vast array of cookware, tableware and kitchenware, Divertimenti caters to all your culinary needs. With over 4500 items on the Divertimenti website www.divertimenti.co.uk Mercury Appliances,...
