Summary of Contents for RedOne RO-S6L
- Page 1 ELECTRIC FRYERS RO-S6L RO-DF6L RO-SF8L RO-DF8L USER’S MANUAL TELEPHONE: SERVICE (44) 01332 875665 FAX: SERVICE (44) 01332 875536...
- Page 2 Please read the manual carefully before use and keep it for future reference. WARNINGS! ANY REFITTING, INCORRECT INSTALLATION, ADJUSTMENT AND MAINTENANCE CAN LEAD TO DAMAGE. PLEASE CONTACT THE SUPPLIER IF YOU NEED TO AJDUST OR MAINTAIN THIS UNIT. ALL ADJUSTMENTS SHOULD BE CARRIED OUT BY AUTHORISED PROFESSIONALS.
- Page 3 A. Structure Single Electric Fryer Double Electric Fryer POWER INDICATOR HEATING INDICATOR TEMPERATURE CONTROLLER ELECTRIC BOX ELECTRIC HEATING ELEMENT POWER CABLE RUBBER FOOT LOWER BOX FRYING BASKET OIL TANK PROTECTING BOARD FOR ELECTRIC HEATING TUBE B. FUNCTION 1. Single product is 1-tank fryer; double product is 2-tank fryer. Double tank fryers can fry two different kinds of food at once.
- Page 4 C. Basic statistics SINGLE (1) Tank Electric Fryers DOUBLE (2)-Tank Electric Fryers RO-SF6L RO-DF6L Model RO-SF8L RO-DF8L ~230V, 50Hz ~230V, 50Hz Voltage 220-240V,50/60Hz 220-240V,50/60Hz 2.5KW 2×2.5KW Power 2×3KW Number of oil tanks 185×270×175 185×270×175 Oil tank Size (mm) 240×300×200 240×300×200 6(L) 2×6(L) Volume...
-
Page 5: Circuit Diagram
Circuit diagram S1－ MICRO-SWITCH SA－ TEMPERATURE LIMITER ELECTRIC ELEMENT HL1 POWER INDICATOR HL2 HEATING INDICATOR E－ EARTH GROUND TEMPERATURE CONTROLLER NOTE: THE CIRCUIT PRINCIPLE OF RO SERIES 1-TANK/2-TANK ELECTRIC FRYER IS DIFFERENT. THE DIFFERENCE IS THAT 2-TANK ELECTRIC FRYER HAS TWO TANKS AND TWO ELECTRIC BOXES AND TWO SEPARATE TEMPERATURE CONTROLLERS. -
Page 6: Notes For Installation
3) This process repeats to ensure temperature is constant. 5. The cover of tank is designed to keep pot clean and retain heat. Please ensure no liquid is on the cover before use to minimize risk of spitting oil. 6. 1) The enclosed frying basket is for frying small food. There is hook and handle on the basket. -
Page 7: Troubleshooting
Notice ● This equipment must be operated by trained professionals. Modification of this product may cause serious accident. ● Do not clean the product with a water jet or expose the electrics to water while cleaning. ● Do not use another power supply with different voltage. Do not use main switch that is not coordinated with safety regulation. -
Page 8: Transportation And Storage
6. Temperature control can 1. Temperature limiter is 1. Change temperature limiter. not be controlled. faulty If any faults occur do not use and consult professionals for repair. F. Transportation and storage During transportation, the machine should be not be shaken. The packaged machine should not be stored in the open air. - Page 9 machine if necessary.
