Page 1 Stereo Bluetooth Folding Headset ® Owner’s Manual Model BTH010...
Page 2 Thank you for choosing the Azeca headset Model BTH010. Please read this user’s manual carefully before use. Features • Play music from your Smartphone or MP3 player* • Answer smartphone calls, redial, mute, or make voice calls • Easily folds into portable travel case •...
Page 3: Overview - Components
Using the Headset Overview - Components Previous track Multi-function button Next track LED indicator Headband Folding and retractable Right loudspeaker Left loudspeaker Microphone Micro USB - Charging jack Volume up Volume down...
Page 4: Operation
Charging the headset The headset comes with a built-in rechargeable battery, prior to first time use it is recommendable to fully charge the battery. When the headset battery power is low, the LED indicator flashes red twice accompanied by three beeps. Using a USB cable Connect the USB cable to a computer USB port and the USB cable plug to the charging jack of the headset.
Page 5: Pairing The Headset With Bluetooth Devices
“BTH010” from the Bluetooth device list; 4) If requested enter password or PIN No:”0000” and press ” Yes” or “confirm”; 5) After successful pairing, select “BTH010” in the Bluetooth device list and press “connect”. 6) After successfully connecting the blue LED flashes twice. While connected the blue LED will continue three quick flashes every 4 seconds.
Page 6: Pairing The Headset With A Bluetooth Transmitter
• After initial pairing, the headset will automatically pair with the last paired Bluetooth device. • To pair the headset with other devices, repeats steps 1 through 6 mentioned above. • If the Bluetooth version of your cell phone is V2.1 and above, you will not need to enter a pairing password as the headset and phone will match automatically.
Page 7: Automatic Pairing
3) Pair and connect the headset with a Bluetooth cell phone (refer to “Pairing the headset with a Bluetooth cell phone”). 4) Turn on the Bluetooth transmitter; it will connect to the headset automatically. Note: • For cell phone supporting the HSP and A2DP Bluetooth profiles, pairing with the headset will simultaneously include both profiles and will not allow paring of an additional A2DP device.
Page 8: Making A Call With The Headset
Making a call with the headset INDICATION STATUS OF FUNCTION OPERATION BTH010 TONE Voice dial Stand by mode Press and hold A short tone for 2 seconds until hearing tone Redial last Stand by mode Quickly press A short tone...
Page 9: Music Playback
Select “transmit the sound via Bluetooth” in the settings menu and then choose “BTH010” as the speaker device. The music will be transmitted to the headset. Please refer to your cell phone’s user’s manual for additional information.
Page 10: Led Indicator
LED indicator 1) When the headset is charging LED Indicator STATUS OF BTH010 Red LED is on Charging in progress Red LED is off Finish charging 2) When the headset is connected to a Bluetooth device LED Indicator STATUS OF BTH010...
Page 11: Care And Maintenance
• This headset will only work with devices that support the following Bluetooth profiles: A2DP, AVRCP, HFP, HSP • Be sure to select “BTH010” from the list of found devices. Some phones require you to scroll through a list of previously paired devices.
Page 12: Specifications
Specifications Bluetooth version Bluetooth V2.1+EDR Bluetooth profiles HSP, HFP, A2DP and AVRCP Operating distance 10 meters, class II Music: up to 4 hours Working time Talk: up to 5 hours Standby: up to 6 days Standby time Up to 120 hours Charing input voltage DC +5.0±0.25VA Charging time...
Page 13: European Union Directives Conformance Statement
This Class B digital apparatus complies with Canadian ICES-003. European Union Directives Conformance Statement Azeca Corp declares that this product is in compliance with: • The key requirements and relevant provisions of Directive 1999/5/EC • All other key EU Directives...
Page 14: Limited Warranty
Headset (Model BTH010) will perform substantially in accordance with the accompanying written materials for a period of 6 months from the date of receipt and (b) that Model BTH010 (product) will be free from defects in materials and workmanship under normal use and service for a period of 6 months.
Page 15 Copyright© Azeca Corp. All rights reserved. Made in China The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Azeca Corp is under license. Other trademarks and trade names are those of...
Page 16 Other Products by Azeca Stereo Bluetooth Speaker Play music from your Smartphone or MP3 player • Answer, redial or mute calls • Built-in mic for hands-free communication • Easy-to-reach controls for volume, next/previous track and pause • Automatically pairs with last Bluetooth device •...
