- Page 1 Hardwire POD™ Power Output Distribution ANUAL...
-
Page 2: Important Safety Instructions
WARNING: When the POD is in utility position (maintenance bypass mode) the power to the connected load is not filtered or conditioned. The Liebert UPS Connected Equipment Guarantee is not valid in this Mode of Operation. GLOSSARY OF SYMBOLS... -
Page 3: System Description
Congratulations on your choice of the Liebert POD. The Liebert POD provides maintenance bypass capability as well as power output distribution. The Liebert POD provides an isolated path of power for your UPS system for preventative maintenance as well as service. SYSTEM DESCRIPTION... - Page 4 ILLATION NOTE: This manual provides instructions for the POD only. Refer to your UPS manual for UPS operation and installation instructions. 1. Unpack the POD carefully, noting the packing method. Retain the box and packing material for possible future shipments. 2.
-
Page 5: Indicator Lights
COMPRESSION FIELD CONNECTIONS Recommended POD Model External Wire Size Torque Number Overcurrent Protection MP115HW #14 AWG - #8AWG MP120HW #12 AWG - #8AWG MP130HW #10 AWG - #8AWG Max. torque: 2 Nm / 16 lbs-in. MP130HWH #10 AWG - #8AWG... -
Page 6: Specifications
SPECIFICATIONS Transfer Time: < 6 milliseconds (to and from maintenance bypass) Operating Ambient Temperature: 0 to +40 degrees C Storage Ambient Temperature: -20 to +60 degrees C Weight: 12 Lbs. (max.) Humidity: 0 to 95% non-condensing Agency/Standards: UL, c-UL listed TROUBLESHOOTING PROBLEM CAUSE... -
Page 7: Limited Warranty
If the POD fails to conform to the above warranty within the two-year warranty period, Liebert will repair or replace the POD, at Liebert's option. Repairs or replacements are warranted for the remainder of the original warranty period. -
Page 8: Technical Support
Worldwide FAX tech support +614-841-5471 The Company Behind The Products With more than 500,000 installations around While every precaution has been taken the globe, Liebert is the world leader in to ensure accuracy and completeness of computer protection systems. Since its this...
