OWNER'S OPERATION MANUAL AND
The Linear Power™ 1752S
solution to many of the problems that plague the high end auto sound installation:
The choice of woofers for a given vehicle, the building and tuning of enclosures
for the drivers and matching up the best amplifier for the speakers.
This system provides a dedicated high current amplifier, a matched set of four 8"
woofers, and the technology and circuitry necessary to ensure consistent low
frequency response regardless of how much air space is available.
How can this work? Rather than relying on the parameters of the woofers and
exacting enclosure designs to tune the speakers for optimum response, we tune
the woofers electronically.
The 1752S Servo-Subwoofer System is programmed to interact not only with
©
the source, but also with the specially designed dual voice coil 8" woofers
supplied. The amplifier receives the signal from the head unit, amplifies it, and
sends it to the woofers. BUT THEN>>> the woofer's dual voice coils return the
signal to the control circuitry in the amplifier. The amplifier compares it to the
original source, and if there are any differences, the amplifier corrects it until the
cones move properly.
The 1752S Servo-Subwoofer System is designed for the audiophile who can
©
appreciate extended bass response comparable to that of a fine home system.
ENJOY!
R T H E L O
MODEL 1752S
(1988 - MSRP $1499.00)
INSTALLATION GUIDE

INTRODUCTION

Servo-Subwoofer System was developed as a
©
© 2008 Linear Power, Inc. - ALL RIGHTS RESERVED
LINEAR POWER™ is a trademark of Linear Power, Inc
