  • Page 1 I l l u m i n a S R S e r i e s O w n e r ’ s M a n u a l...
  • Page 2: Table Of Contents

    WARNING: To avoid injury, read all the operating instructions presented within this guidebook. When using or installing electrical devices, take care and/or consult with a professional. Be sure to follow all directions carefully – failure to do so may result in damage to your Vertex® Illumina and void the warranty Dealers or the manufacturer are not responsible and cannot be held accountable for any personal/prop- erty damage and/or loss of livestock resulting from the misuse of products.
  • Page 3 Failure to do so will result in failure of the unit and is not covered by warranty. Safety Considerations Your Vertex Illumina has been designed to be used as a point source of illumination over an aquarium. Please note that while the unit is humidity resistant, it is NOT waterproof. It is absolutely crucial to mount the unit to a sturdy foundation.
  • Page 4 CHAPTER 1: Getting Started CHAPTER 1: Getting Started CHAPTER 1: Getting Started Illumina SR Specifications SR 300 (260/360) SR 600 (260/360) Dimensions Dimensions 300mm x 300mm | 12” x 12” Footprint 600mm x 300mm | 12” x 12” Footprint 32mm | 1.26” / 45mm | 1.77” Center Height 32mm | 1.26”...
  • Page 5: Led Pad Specifications

    CHAPTER 1: Getting Started Illumina Specifications SR 1500 (260/360) SR 1800 (260/360) Dimensions Dimensions 1500mm x 300mm | 12” x 12” Footprint 1800mm x 300mm | 12” x 12” Footprint 32mm | 1.26” / 45mm | 1.77” Center Height 32mm | 1.26” / 45mm | 1.77” Center Height Weight Weight 15.5 kg | 34.17 lbs...
  • Page 6: Components

    Out of the Box Your Vertex Illumina SR will come out of the box with the main body preassembled. You will not be re- quired to install any LED Pads or electronics. Do not attempt to open your Illumina SR. Any installations requiring disassembly of the fixture should only be done by an authorized Vertex dealer.
  • Page 7: Chapter 2: Basics

    Auxiliary slots located between each of the LED pads allow for nearly limitless spectral composi- tions. NOTES: The Vertex Illumina is meant to be suspended above a display. Though humidity resistant, it is not waterproof. Be sure that it is mounted and protected from water spray coming from overflows and/or splashing and bubbling water. Do not attempt to move the LED pads within the fixture. They are set in place to allow for exact placement of auxiliary LED pads and sealed with a thermal paste backside.
  • Page 8 Be sure to follow the connection procedure be- fore connecting the Control Cable of the Illumina to the Splitter Box. Vertex Illumina Suspension Kit (optional) High-tensile Steel Aircraft cables and cable clamp fittings provide secure, durable suspension and maxi- mum installation flexibility.
  • Page 9: Installing Your Illumina Sr

    CHAPTER 2: Basics Installing Your Illumina SR Please read the following instructions thoroughly and consult with an expert before installing your Il- lumina. The fixture should always be located above your display in a well-ventilated space and should not be touching any surfaces once suspended. Locate the unit away from areas of high humidity and/ or water and salt spray.
  • Page 10 CHAPTER 2: Basics Installing Your Illumina SR Next, take the bare end of the cable and thread it through the eye-hole of the male end of the Socket Anchor. Pull it until the cable is fully threaded through the fitting as shown. The stopper will hold once it reaches the eye-hole of the fitting. Now take the cable and thread it through the Cable Clamp. It will push out from the side wedge of the fitting and can be pulled through from there. Continue to pull the cable through the fitting. Do not worry if you draw too much length, as this can later be adjusted.
  • Page 11 CHAPTER 2: Basics Installing Your Illumina SR SOCKET ANCHOR (CEILING/FEMALE) The Female side of the Socket Anchor is the base point for suspending the fixture. In order to mount this part, you will need a sturdy surface (such as a wooden crossbeam – please refer to the weight chart and consult with an expert prior to installation) and an appropriate screw/bolt of at least 2”...
  • Page 12 CHAPTER 2: Basics Installing Your Illumina SR To begin powering up your Vertex Illumina, first plug all the power cables to their respective Mean Well AC Adapter / Driver Units. Then connect each of the power cables into a GFCI/Surge Protected electri- cal outlet. Before plugging the fixture into an wall outlet, arrange the cord in an anti-drip loop as pictured to the left.
  • Page 13 CHAPTER 2: Basics Installing Your Illumina SR SR 300 & 600 To power up these models, connect the Control Cable from the fixture to the AC Adapter / Driver connector cable. Once properly connected, the display module on your Illumina should light up and begin Initial- izing. After a few moments, you will be ready to begin programming your lights.
  • Page 14: Operation

    CHAPTER 2: Basics Operation With your Vertex Illumina is powered up, you will now be able to program your lighting spectrum and schedule. Button Controls The Vertex Illumina interface consists of a view- ing screen and four control buttons. The fuction of each of the buttons is as follows: 1.
  • Page 15: Menu Structure

    CHAPTER 2: Basics Menu Structure Use the following table to orient yourself within the menus: - 15 -...
  • Page 16: Chapter 3: Advance Features

    CHAPTER 3: Advanced Features Light Manager (Main Menu 1) The Light Manager is the main interface from which you will program your Vertex Illumina. Within it, you will find the following functions: ○ DEMO ○ DEFAULT ○ CUSTOM ○ SELECT ▲ ▼ Functions 1-1 OFF: Select this function and hold the SELECT button to turn the unit off.
  • Page 17 CHAPTER 3: Advanced Features Light Manager (Main Menu 1) Functions cont. 1-4-2 WHITE / 1-4-3 ROYAL BLUE / 1-4-4 BLUE: These options allow you to configure each LED color channel independantly. Within the selections, you will find the following interface: CHANNEL NAME INTENSITY: 00-100% SUNRISE: 00:00AM RISETIME: 00:00H SUNSET: 00:00PM DAWNTIME: 00:00H – ESC/► ◄/OK Press and hold ◄/OK to exit each channel while retaining your color composition (no lighting schedule). Press and hold ESC/►...
  • Page 18: Quick Motion

    CHAPTER 3: Advanced Features Quick Motion (Main Menu 2) The Quick Motion feature allows you to quickly test and adjust any Custom settings you have defined and saved using the Light Manager. Once selected, the Quick Motion will quickly run the Illumina through an accelerated light cycle. You can exit at any time by pressing any of buttons on the control console. Settings (Main Menu 3) Use this menu to configure the interface functionality of the Illumina: LANGUAGE...
  • Page 19: Info

    3-6 MISC: Use this setting to adjust the Radio Channels between 01-15 to compensate for any interfer- ence between the Vertex Illumina, the V-Link accessory and other remote devices. 3-7 FUNCTIONS: This menu has the optional SPARE MODULES (3-7-1) and FACTORY RESET (3-7-2) selections.
  • Page 20: Chapter 4: Maintenance & Led

    Before you beging with any further maintenance operations, be mindful of the following points: Do not attempt to disassemble your Vertex Illumina without specific instruction. This action should only be done by an authorized Vertex technician and any failure caused by user error will void the war- ranty of the unit. l Do not clean with harsh acidic or alkaline cleaners/solvents which may destroy the finish.
  • Page 21: Cleaning The Central Air Shaft

    CHAPTER 4: Maintenance Cleaning the Central Air Shaft The Central Air Shaft is crucial towards maintaining proper operating temperatures and LED output life. Therefore, it is recommended that you clean perform routine maintenance to keep the shaft free of dust and other particulates.
  • Page 22: Led Modules

    SR 1800 Installation information for LED upgrades and Auxiliary Modules are included with the respective prod- ucts. All modules should only be installed by an authorized Vertex technician. Damages resulting from user error will not be covered by the warranty.
  • Page 23 0%. Individual LED Mod- If all Color Channels are functioning properly, check with your ules authorized Vertex dealer. Moonlights are not Moon Selection - Moon If set to the ‘MOON CYCLE’ option, Moon Lights may not illu- running.
  • Page 24 CHAPTER 5: Additional Information Warranty Information The Vertex Illumina LED Fixture comes with a two (2) year limited Manufacturer warranty. The Mean Well AC Adapter(s) come with a two (2) year limited Manufacturer warranty. Parts that have been damaged due to user error and misuse will not be eligible for warranty replace- ment.
