User Manual –WDMX-1
9. Disposal :
Please disposal of the unserviceable device according to the current
statutory requirements.
10. Technical specification :
Power supply
9Vdc, 1000mA
Power consumption
Frequency
2.450GHz
Max range
Dimensions
120 x 80 x 42mm
Weight
Manual copyright protected by QTX Light
154.150UK
3W
100m
750g
8
WDMX-1
Wireless DMX Sender/Receiver
User Manual
154.150UK
Version 1.0
Advertisement
Summary of Contents for QTX Light WDMX-1
- Page 1 10. Technical specification : Power supply 9Vdc, 1000mA Power consumption Frequency 2.450GHz Max range 100m Dimensions 120 x 80 x 42mm Weight 750g WDMX-1 Wireless DMX Sender/Receiver Manual copyright protected by QTX Light User Manual 154.150UK Version 1.0...
- Page 2 User Manual –WDMX-1 154.150UK User Manual –WDMX-1 154.150UK WDMX-1- Wireless DMX Sender/Receiver: For indoor use only Example Setup (1 Sender – 3 Receivers): not to scale CAUTION! Please read this manual carefully before operating! General introduction : This device allows the transmission of a DMX signal to units without the need to install long cables.
- Page 3 Each unit can be set as either a transmitter or receiver and can be easily changed by “switch 4” (see diagram). You then need to set both the WDMX-1 x 1 unit User’s Guide x 1pcs 1 x Power supply and cable transmitter and receiver addresses the same for it to work.
- Page 4 User Manual –WDMX-1 154.150UK User Manual –WDMX-1 154.150UK Do not use the device during thunderstorms. Please disconnect the power. 7. Setup: Do not use solvents or aggressive detergent to clean the device. Use a soft and clean cloth. Side 1 Do not modify the device or the connected power cord without authorisation.
