What's in the box?
Battery
cover
• If any items are missing or damaged, contact our Customer Care Line
immediately. Never use damaged products!
• Need help? Get answers 24/7 at our website: www.uniden.com.
If You...
have a question or problem
need a replacement part or an
accessory
need special assistance due to
a disability
* During regular business hours, Central Standard Time; see our website for de-
tailed business hours.
© 2012 Uniden America Corp.
Ft. Worth, Texas
D1760 Series User's Guide
D1760 base
with cordless
handset
Not pictured:
• Rechargeable
battery (BT-1021)
• AC adapter (PS-0035)
• Telephone cord
If you purchased
model number:
D1760
D1760-2
D1760-11
D1760-12
* If the model number ends in R,
your package includes a DRX100
range extender. Refer to the
DRX100 owner's manual for details.
Contact Uniden's...
Customer Care Line*
Parts Department*
Accessibility Help Line
You will also find:
Accessory handset
and charger
Not pictured:
• Rechargeable
battery (BT-1021)
• Battery cover
• AC adapter
(PS-0035)
You should
Phone Number
817-858-2929 or
800-297-1023
800-554-3988
800-874-9314
(voice or TTY)
Printed in Vietnam
U01UN419EZB(0)
have:
None
1 of each
10 of each
11 of each
Advertisement
Table of Contents
Summary of Contents for Energy Star D1760
- Page 1 D1760 Series User's Guide You will also find: What's in the box? Accessory handset D1760 base and charger with cordless handset Not pictured: • Rechargeable battery (BT-1021) • Battery cover • AC adapter (PS-0035) You should If you purchased model number:...
-
Page 2: Table Of Contents
What’s in the manual? Getting Started ........ 3 Important Information ....14 Installing Your Phone .........3 Solving Problems ........14 Getting to Know Your Phone ....4 Resetting Handsets ........16 Using the Handset Menu ......6 Registering Handsets ......16 Adapter and Battery Information ..16 Using Your Phone ...... -
Page 3: Getting Started
GETTING STARTED Installing Your Phone Connect the Telephone Cord Use the telephone cord to connect Charge the Battery the jack on the base to a TEL LINE 1. Unpack all handsets, standard telephone wall jack. battery Test the Connection packs, and battery 1. Pick up the handset and press covers. If . The handset sounds a dial Talk you need to tone, and the display shows Talk. remove a – If you don't hear a dial tone or cover, press in on the notch and the display says Check Tel Line, slide the cover down and off. -
Page 4: Getting To Know Your Phone
Getting to Know Your Phone Parts of the Base Find Charging Handset Contacts Key (icon) What it does • In standby: page all handsets. Find hs Parts of the Handset PHONEBOOK SPEAKER MENU/SELECT TALK/FLASH DOWN Twelve-key dial pad REDIAL/PAUSE INTERCOM/CLEAR Microphone MESSAGE/MUTE Charging... - Page 5 Key (icon) What it does • In standby or during a call: open the phonebook. PhonEbook • In the menu: go back to the previous screen. • When entering text: move the cursor to the left. ) • Switch a normal call to the speakerphone (and back). sPEakEr • In standby: start a telephone call (get a dial tone).
-
Page 6: Using The Handset Menu
Reading the Display Status The table shows the possible icons status icons & what they mean. Since the icons appear based Current call info on what the phone is doing, you won't see all the icons at Time & the same time. record date status Icon What it means The signal from the base is 1) strong or 2) weak. The ringer is turned off and will not ring for new calls. The speakerphone is on. - Page 7 Handset Setup Menu You can change these settings separately for each handset. Turn on T-coil mode to reduce noise on hearing aids T-coil equipped with a telecoil (T-coil) feature. T-coil mode shortens talk time, so keep your battery fully charged. Choose this handset's ring tone. As you highlight each Ringer Tones ring tone, the phone plays a sample.
-
Page 8: Using Your Phone
Entering Text on Your Phone • Use the 12-key dial pad anytime you want to enter text into your phone (a name in the phonebook, the handset banner, etc.). • If two letters in a row use the same key, enter the first letter; wait for the cursor to move to the next space and enter the second letter. To... Press... move the cursor left PhonEbook move the cursor right erase the character at the cursor inTErcoM/clEar erase the entire entry and hold inTErcoM/clEar enter a blank space switch between upper and lower case letters rotate through the punctuation and symbols USING YOUR PHONE... -
Page 9: Changing The Volume
Assigning a Speed Dial Number You can assign a speed dial number to a phonebook entry when you create that entry for the first time (or when you edit it). Press and PhonEbook select Create New. As you enter the phonebook number, one of the options you will see is to assign a speed dial number to that phonebook entry. You can assign up to 10 speed dials, 0 - 9. Finding a Lost Handset With the phone in standby, press on the base. All handsets beep for Find hs 1 minute; to cancel, press again or press any handset key. Find hs Changing the Volume To change the... When... Press... you are listening to that to increase earpiece or speaker earpiece or speaker (playing the volume. -
Page 10: Using The Phonebook
To… Press... dial the Talk/Flash sPEakEr. highlighted (If the number is a toll call but there is no 1 at the number beginning, press to add 1 before dialing.) close the lists PhonEbook For individual record options, highlight a number and press MEnu/sElEcT Delete Entry Erase the number from the list. Add the number to the phonebook. -
Page 11: Using Special Features
# or just wait about 5 seconds. The phone turns on the 2. To confirm, press answering system and displays Silent Mode On on each handset. 3. After the selected number of hours, the phone automatically exits silent # again. mode. To exit silent mode manually, press and hold Multihandset Features To use the features in this section, you need at least 2 handsets. • Your base supports a total of 12 cordless handsets: the one that came with the base and up to 11 DCX170 accessory handsets. Your base also supports a total of 2 DRX100 range extenders, including any that came with your phone. If you have any DWX handsets, the D1760 is limited to a total of 6 accessory handsets. • You must register accessory handsets to the base before using them. (Handsets that came packaged with the base are already registered.) • Handsets that aren’t registered display a Not Registered message. For registration instructions, see p. 16, or see the accessory handset manual. - Page 12 • If a handset was ever registered to a base, you must reset it before it can register to a new base; see p. 16, or see the accessory handset manual. Conference Calling • When an outside call comes in, two handsets can join in a conference call with the outside caller. • To join a call that’s already in progress, just press or Talk/Flash sPEakEr • To leave the conference call, hang up normally; the other handset remains connected to the call. Call Transfer To... Press..The phone puts the call on hold and inTErcoM/clEar prompts you to select the handset you want to page. transfer a call When the other handset accepts the call, you'll be disconnected (press...
-
Page 13: Chain Dialing
To... Press... cancel a page answer a page inTErcoM/clEar Talk/Flash end an intercom call . Both handsets return to standby. Chain Dialing If you often have to enter a series of digits or a code number during a call, you can save that code number to a phonebook entry and use the phonebook to send the code number. 1. Enter the code number (up to 20 digits) into the phonebook just like a regular phonebook entry. Be sure to enter the code number into the phonebook exactly as you would enter it during a call. 2. When you hear the prompt that tells you to enter the number, open the phonebook and find the entry that contains your code number. 3. Press to send the code. If you change your mind, just close MEnu/sElEcT the phonebook. Voice Message Notification If you subscribe to a voice mail service, your phone displays the voice mail icon ( ) when you have a new message. This feature supports... -
Page 14: Important Information
4. To access your provider’s voice mail service now, press MEssagE/MuTE The system will dial the voice mail service and you can enter your security code manually when prompted. Editing Your Voice Mail Number You can add your voice mail security code to the voice mail number string. , then scroll to Global Setup/Edit Voice Mail. 1. Press MEnu/sElEcT 2. Enter your voice mail number again, then press twice to rEdial/PausE enter 2 2-second pauses. Next, enter your security code. 3. Press when you are finished. The system displays DONE! MEnu/sElEcT 4. To access your provider’s voice mail service now, just press MEssagE/ . The system will dial the access number, wait 4 seconds, and then MuTE it will dial the security code. IMPORTANT INFORMATION Solving Problems If you have any trouble with your phone, check this section first. If you need help, call our Customer Care Line listed on the front cover. General problems Possible solutions • Check the telephone cord connection. -
Page 15: Liquid Damage
Audio issues Possible solutions • Check for interference from appliances (microwave ovens, TVs, etc.) or wireless devices (baby monitors, WiFi equipment, etc.). Move the handset or base away There’s a lot of from the interference source. noise or static on • If you use a telecoil hearing aid, turn on T-coil mode the line (see p. -
Page 16: Resetting Handsets
Resetting Handsets Battery pack (with normal use) If you have trouble with a handset or Part number BT-1021 if you want to replace one, clear the Capacity 300mAh, 2.4V DC registration information from the base Talk time about 7 hours and the handset: Standby time about 7 days and # at the same 1. Press & hold time until you see the System Reset Battery life about 1 year menu. x Replace the battery when the talk or 2. If you still have the base the handset standby time becomes noticeably re- is registered to, select Deregister HS, duced. For replacements, call the Parts then select the handset you want Department (see the front cover). to reset. If you don’t have that base x When the battery gets low, the handset anymore, select Base Unavailable. -
Page 17: Compliance Information
Warning! The cords on this line, as determined by the total RENs, contact the telephone provider. The product and/or accessories contain REN for this product is part of the lead, a chemical known to the product identifier that has the format state of California to cause birth US:AAAEQ##TXXXX. The digits rep- defects or other reproductive resented by ## are the REN without a harm. Wash hands after handling. decimal point (e.g., 03 is a REN of 0.3). Uniden works to reduce lead If this equipment causes harm to the telephone network, the telephone com- content in our products &... -
Page 18: Fcc Rf Exposure Information
able your alarm equipment. If you have off and on, the user is encouraged to questions about what will disable alarm try to correct the interference by one or equipment, contact your telephone more of the following measures: company or a qualified installer. x Reorient or relocate the receiving Any changes or modifications to this antenna. product not expressly approved by the x Increase the separation between the manufacturer or other party respon- equipment and receiver. sible for compliance could void your x Connect the equipment into an outlet authority to operate this product. on a circuit different from that to which the receiver is connected. NOTICE: According to telephone com- pany reports, AC electrical surges, typi- x Consult the dealer or an experienced cally resulting from lightning strikes, radio/TV technician for help. are very destructive to telephone FCC RF Exposure Information equipment connected to AC power This product complies with FCC radia- sources. To minimize damage from tion exposure limits under the follow- these types of surges, a surge arrestor is ing conditions: recommended. x The base must be placed to allow a FCC Part 15 Information minimum of 20 cm (8 inches) between... -
Page 19: 1-Year Limited Warranty
ing that Industry Canada technical the Product is (A) damaged or not specifications were met. It does not maintained as reasonable or necessary, imply that Industry Canada approved (B) modified, altered, or used as part of the equipment. any conversion kits, subassemblies, or any configurations not sold by Uniden, NOTICE: The Ringer Equivalence (C) improperly installed, (D) serviced Number (REN) for this terminal equip- or repaired by someone other than an ment is marked on the equipment itself. authorized Uniden service center for a The REN assigned to each terminal defect or malfunction covered by this equipment provides an indication of warranty, (E) used in any conjunction the maximum number of terminals with equipment or parts or as part of allowed to be connected to a telephone any system not manufactured by Un- interface. The termination on an inter- iden, or (F) installed or programmed face may consist of any combination of by anyone other than as detailed by the devices subject only to the requirement owner's manual for this product. that the sum of the Ringer Equivalence Numbers of all the devices does not STATEMENT OF REMEDY: In exceed 5. the event that the product does not conform to this warranty at any time Radio equipment while this warranty is in effect, warran- The term IC before the radio certi- tor will either, at its option, repair or fication number only signifies that replace the defective unit and return it Industry Canada technical specifica-... - Page 20 the above limitation or exclusion may has caused you to return it. The Prod- not apply to you. uct should be shipped freight prepaid, by traceable means, to warrantor at: LEGAL REMEDIES: This warranty Uniden America Service gives you specific legal rights, and Minimum size: 0.375 in wide (9.525 mm) Minimum drawing size (with clear space) = 0.555 in (14.1 mm) wide 4700 Amon Carter Blvd. you may also have other rights which Fort Worth, TX 76155 vary from state to state. This warranty is void outside the United States of As an Energy Star® Partner, America and Canada. Uniden has determined PROCEDURE FOR OBTAINING that this product meets the PERFORMANCE OF WARRANTY: Energy Star® guidelines for If, after following the instructions in energy efficiency. Energy the owner's manual you are certain Star® is a U.S. registered mark.
