Summary of Contents for Doughboy UltraVac 0-2035-000
- Page 1 UltraVac Automatic Pool Vacuum Cleaner Model 0-2035-000 Patent No. 5,794,293 Owner's Guide 365-1896...
-
Page 2: Components Assembly
VACUUM HOSE CAUTIONS Join hose sections by inserting male cuff of one hose into the female cuff of another. Hose length should be pool length or 1. Remove the vacuum from the pool prior to super diameter, plus one hose length. SEE FIG. 3. chlorinating the water and do not re-install it for a minimum of four hours. -
Page 3: Operation
FOR BEST RESULTS, connect the hose with flow AUTOMATIC FLOW FIG. C control valve directly to the skimmer faceplate suction CONTROL VALVE port. Be sure to lower the skimmer lid to the top of the skimmer basket before operating your pump (see Fig. - Page 4 floor, you may notice your vacuum operating slower than weights as shown above using a trial and error method normal with a reduction of flow from the return inlet as your (observe the vacuum's operation) to determine the best number of weights to use, and the most effective location filter becomes dirtier.
-
Page 5: Parts List
EXPLODED VIEW POOL VACUUM CLEANER Owner's Guide PARTS LIST ITEM PART # DESCRIPTION 1107-1682 Vacuum Body Assembly 340-2062 Driver 1121-1733 Vacuum Head Assembly 348-1047 Suction Pad 340-2066 Suction Disk 330-1253 #8 x 3/4" Screws 346-1051 1-1/2" x 3' Hose 340-2366 Rub Bar Weight Cap 341-1412 Rub Bar... -
Page 6: Five Year Limited Warranty
1. Doughboy is the warrantor of this product. 2. This warranty is extended to the original purchaser (consumer) only. 3. Doughboy warrants the automatic pool vacuum cleaner (excluding hose) for a period of five (5) years from date of purchase against all defects in materials and workmanship.
