Euro CLS I570 User Manual

Mini-itx fan sbc w/ intel socket fc-pga 478/fc-bga 479 cpu,vga, lcd, giga ethernet, mini-pci and pci slot interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IMPORTANT NOTICE : The Euro CLS I570 motherboard can be used for a large range
of panel PC's from 8.4" to 42".
In order to know the complete range of products we propose, please clic this link :
http://www.eurocls.com/product/Panel_PC/Intel_Pentium_M_-_Celeron_M/
ZI de St Génault 16 rue Jean Mermoz 91080 Courcouronnes France Tél : +33 (0) 1 60 78 97 93 Fax : +33 (0) 1 60 79 14 88 Web :
Mini-ITX Fan SBC w/ Intel
FC-PGA 478/FC-BGA 479 CPU,
VGA, LCD, Giga Ethernet, Mini-PCI
and PCI Slot Interface.
USER MANUAL Version 1.0
®
Socket
www.eurocls.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the I570 and is the answer not in the manual?

Questions and answers

Related Manuals for Euro CLS I570

Summary of Contents for Euro CLS I570

  • Page 1 PCI Slot Interface. USER MANUAL Version 1.0 IMPORTANT NOTICE : The Euro CLS I570 motherboard can be used for a large range of panel PC's from 8.4" to 42". In order to know the complete range of products we propose, please clic this link : http://www.eurocls.com/product/Panel_PC/Intel_Pentium_M_-_Celeron_M/...

  • Page 2: Fcc Statement

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at hi m own expense. I570 Motherboard User Manual...

  • Page 3: Copyright Notice

    (e. g., with A for October, B for November and C for December). For example, the serial number 1W07Axxxxxxxx means October of year 2007. I570 Motherboard User Manual...

  • Page 4: Packing List

    Before using this Motherboard, please make sure that all the items listed below are present in your package I570 Motherboard I570 SBC User Manual HDD IDE Cable User’s Manual & Driver CD If any of these items are missing or damaged, contact your distributor or sales representative immediately.

  • Page 5: Safety Precautions

    As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static -shielded bag when they are not in the chassis. I570 Motherboard User Manual...
  • Page 6 F. The equipment has obvious signs of breakage. 15. Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the equipment. I570 Motherboard User Manual...
  • Page 7 Revision History Version Date Note Author 2008.01.16 Initial Draft Aladin Huang 2008.02.25 First version Aladin Huang I570 Motherboard User Manual...

  • Page 8: Table Of Contents

    ............43 DVANCE EATURE ........... 46 DVANCED HIPSET EATURE ............49 NTEGRATED ERIPHERALS P / PCI C ............52 ONFIGURATION ............. 53 OWER ANAGEMENT ETUP PC H ..............56 EALTH TATUS 7.10 ............57 EFAULTS VIII I570 Motherboard User Manual...
  • Page 9 7.11 ............. 57 PTIMIZED EFAULTS 7.12 ............. 57 UPERVISOR ASSWORD 7.13 & E ..............57 ETUP 7.14 ............57 ITHOUT AVING NOTE: DIGITAL I/O SAMPLE CODE ..........58 I570 Motherboard User Manual...
  • Page 10 This chapter includes I570 Motherboard background information. Sections include: Introduction Feature Motherboard Specification Function Block Board Dimensions I570 Motherboard User Manual...

  • Page 11: General Information

    In peripheral connectivity, I570 SBC with one PCI slot and Mini-PCI I/O ports, two PATA connectors, and six Hi-Speed USB connectors. Thus, I570 SBC is designed to satisfy most of the applications in the industrial computer market, such as Gaming, POS, KIOSK, Industrial Automation, and Programmable Control System.

  • Page 12: Motherboard Specifications

    1 x PCI, 1 x Mini-PCI Form Factor Mini-ITX Dimensions 170mm x 170mm Operating temperature: 0 deg. C to 60 deg. C Mechanical & Operating Humidity: 30 ~ 90% Relative humidity, environmental non-condensing Certification: CE, FCC, RoHS I570 Motherboard User Manual...

  • Page 13: Function Block

    18bit/Dual CH DDR2 533/400 Max.1GB 66MHz Hub Interface 1.5 ATA100 2x 1GB/s 2 x IDE Host Intel ICH4 480MB/s Audio Realtek ALC655 33MHz Mini PCI Super IO Realtek ALC655 ROM FWH Secondary IO Realtek ALC655 Realtek ALC655 I570 Motherboard User Manual...

  • Page 14: Board Dimensions

    Board dimensions I570 Motherboard User Manual...
  • Page 15 This chapter provides information on how to use the jumps and connectors on I570 Motherboard. The Sections include: Memory Module Installation I / O Equipment Installation Setting the Jumpers Connectors on I570 Motherboard I570 Motherboard User Manual...

  • Page 16: Installations

    Installations 2.1 Memory Module DIMM Installation I570 motherboard supports one DDR memory socket for a maximum total memory of 1GB in DDR memory type. 2.1.1 Installing and Removing Memory Modules To install the DDR modules, locate the memory slot on the board and perform the...
  • Page 17 Whatever, you should install the device driver before you use the device. 2.2.7 Audio Jack ( Pin-header) The Audio 5.1 channel capabilities are provided by a Realtek ALC655 chipset supporting digital audio outputs. The audio interface includes Mic-in,: line-in and line-out. I570 Motherboard User Manual...

  • Page 18: Jumpers And Connectors

    COM3 DC Jack CON7 IDE1 CON3 JP1 IDE2 NB_FAN1 Panel 1 CPU_FAN1 BOTTOM USB1 CON9 CON8 CON4 CON2 CF Card Slot(Optional) CON6 CON5 Audio Line-in +12 V DC-IN Line-out Mic-in PWIN1 USBLAN1 USBLAN2 PSKBM1 CON10 CON1 I570 Motherboard User Manual...

  • Page 19: Jumper Setting

    CF Card Priority 3x1 header , pitch 2.0mm RS232 / RS422 / RS485 Selector 2x3 header , pitch 2.0mm RS232 / RS422 / RS485 Selector 3x4 header , pitch 2.0mm CON4 LVDS VOLTAGE 2x3 header , pitch 2.0mm I570 Motherboard User Manual...
  • Page 20 RS232 RS422/485 RS232 RS422/485 10-11 11-12 2.4.3 JP3: CF Card Priority JP3 can be configured to operate CF Card Priority in Master/Slave mode. Master Slave Pin No. Functions 1 Short 2 Master 2 Short 3 Slave I570 Motherboard User Manual...
  • Page 21 2.4.4 CON4: LCD Panel Voltage Select CON4 can be configured to operate in 3.3Volts / 5Volts / 12Volts mode. 3.3Volts 5Volts 12Volts Pin No. Functions 1 Short 2 3.3Volts Selected 3 Short 4 5Volts Selected 5 Short 6 12Volts Selected I570 Motherboard User Manual...

  • Page 22: Connectors And Pin Assignment

    2x1 header, pitch 2.54mm CON9 5V External Power 2x1 header, pitch 2.54mm 5V/12V External Power header ,pitch 2.54mm CON7 5V/12V DC Jack 4x1 Pin Jack ATX12V1 12V DC Connector 2x2 Pin Connecter PWIN1 12V DC Connector 4 Pin Connecter I570 Motherboard User Manual...
  • Page 23 SYMBOL Pin No. SYMBOL LCDVDD LVDS_LTX0- LCDVDD LVDS_LTX0+ LCDVDD LVDS_LTX1- LVDS_LTX1+ LVDS_LTX2- LVDS_LTX2+ LVDS_LCLK- LCDS_LCLK LVDS_UTX0- LVDS_UTX0+ LVDS_UTX1- LVDS_UTX1+ LVDS_UTX2- LVDS_UTX2+ LVDS_UCLK- LVDS_UCLK 2.5.2 JP1: Digital Panel Backlight Brightness Control Pin No. SYMBOL Black Light Control I570 Motherboard User Manual...
  • Page 24 2.5.3 CON3: Digital Panel Backlight Control Pin No. SYMBOL +12V +12V +12V Black Light Control Black Light EN 5V 2.5.4 PSKBM1: PS2 Keyboard/Mouse Connector PS/2 Keyboard PS/2 Mouse Pin No. SYMBOL Pin No. SYMBOL KDATA MDATA Ground Ground KCLK MCLK I570 Motherboard User Manual...
  • Page 25 DTR4/422RX- NDSRA NRTSA NCTSA NRIA DAC_SDAT0 3VHSYNC0 3VVSYNC0 DAC_SCL0 2.5.6 CON6: Serial port COM2 The serial port COM2, which is Winbond I/O support, is RS232 only. SYMBOL SYMBOL NDSR1A NDCD1A NRTS1A NRXD1A NCTS1A NTXD1A NCTS1A NDTR1A I570 Motherboard User Manual...
  • Page 26 FK_NDSR2 FK_NRTS1 FK_NRTS2 FK_NCTS1 FK_NCTS2 FK_NRI1 FK_NRI2 2.5.8 AUDIO401: Audio Jack ( Pin-header ) SYMBOL Color Signal Blue Line In Green Line Out Pink Microphone In Pin-Header C0~C4 Line in B1~B4 Line out A1~A4 Mic in I570 Motherboard User Manual...
  • Page 27 2.5.9 IDE1: 44 pins IDE Connector Pin No. SYMBOL Pin No. SYMBOL RESET GND3 DD10 DD11 DD12 DD13 DD14 DD15 GND1 DREQ GND4 DIOW# GND5 DIOR# GND6 IO_RDYD CSEL DACK# GND7 IOCS16# CBL_ID# DCS#1 DCS#3 DASP# GND8 +5V1 +5V2 I570 Motherboard User Manual...
  • Page 28 Host data 15 Ground Protect pin DRQ0 Ground Host IOW Ground Host IOR Ground IOCHRDY Host ALE DACK0 Ground IRQ14 No connect Address 1 No connect Address 0 Address 2 Chip select 0 Chip select 1 Activity Ground I570 Motherboard User Manual...
  • Page 29 SYMBOL USBVCC4 USBVCC4 USB_P6- USB_P7- USB_P6+ USB_P7+ 2.5.12 NB_FAN1/CPU_FAN1: FAN CONNECTOR NB_FAN1 CPU_FAN1 2.5.13 PANEL1: Front Panel System Function Connector SYMBOL SYMBOL HD_LED+ PW_LED+ HD_LED- PW_LED- RT_BT1 PW_BT1 RT_BT2 PW_BT2 5VSB RSEV 2.5.14 J4/J5: Front Audio I570 Motherboard User Manual...
  • Page 30 2.5.15 CON8/CON9/J6: External Power CON905 CON906 2.5.16 PWIN1: DC Jack 2.5.17 ATX12V1: 12V DC Connector SYMBOL Ground Ground +12V +12V 2.5.18 CON7: 4 Pin Power Connector SYMBOL +12V Ground Ground I570 Motherboard User Manual...
  • Page 31 2.5.19 : Audio Connector SYMBOL SYMBOL LINE OUT L LINE_OUT R LINE IN L LINE IN R MICVREF MIC1 VOL OUT I570 Motherboard User Manual...
  • Page 32 This chapter offers information on the chipset software Installation utility Installation of Graphic Driver Panel Resolution Setting I570 Motherboard User Manual...

  • Page 33: Graphic Driver Installation

    Graphic Driver Installation 3.1 Graphic Driver Installation I570 Motherboard is equipped with Intel 855GME / ICH4 Companion Device. The Intel Graphic Drivers should be installed first, and it will enable “Video Controller (VGA compatible). Follow the instructions below to complete the installation.
  • Page 34 I570 Motherboard User Manual...
  • Page 35 Step.3. Click on “Next “ to install Driver. Step.4. Click on “Next “ to install Driver. I570 Motherboard User Manual...
  • Page 36 Step.5. Click on “Yes “ to agree License. Step.7. Click on “Yes, I want to restart this computer now “ to go on. I570 Motherboard User Manual...
  • Page 37 This chapter offers information on the chipset software Installation utility Installation of Chipset Driver Further information I570 Motherboard User Manual...

  • Page 38: Chipset Driver Installation

    Chapter 4 Chipset Driver Installation 4.1 Chipset Driver Installation Setp.1. Insert the CD that comes with the motherboard. Open the file document “Chipset Driver”. Setp.2. Click on “Setup“ to install driver. I570 Motherboard User Manual...
  • Page 39 Setp.3. Click on “Next“ to install driver. Click on “Yes “ to agree License Setp.4. I570 Motherboard User Manual...
  • Page 40 Setp.5. Click on “Next“ to install driver. Setp.6. Click on “Next“ to install driver. I570 Motherboard User Manual...
  • Page 41 Step.7. Click on “Yes, I want to restart this computer now “ to go on. I570 Motherboard User Manual...
  • Page 42 This chapter offers information on the Ethernet software installation utility. Sections include: Introduction Installation of Ethernet Driver I570 Motherboard User Manual...

  • Page 43: Chapter 5 Ethernet Driver Installation

    Chapter 5 Ethernet Driver Installation Installation of Ethernet Driver The Users must make sure which operating system you are using in the I570 Motherboard before installing the Ethernet drivers. Follow the steps below to complete the installation of the Realtek RTL8110SC LAN drivers. You will quickly complete the installation.
  • Page 44 Click on “Next“ to install driver. Step.3. Click on “Install“ to install driver. Step.3. I570 Motherboard User Manual...
  • Page 45 Click on “Finish“ and go on. Setp.3. I570 Motherboard User Manual...
  • Page 46 This chapter offers information on the Audio software installation utility. Sections include: Introduction Installation of Audio Driver I570 Motherboard User Manual...

  • Page 47: Audio Driver Installation

    PCs. Installation of Audio Driver The users must make sure which operating system you are using in the I570 Motherboard before installing the Audio drivers. Follow the steps below to complete the installation of the Realtek ALC655 Audio drivers.
  • Page 48 Step.2. Click on “Next“ to install driver. Step.3. Click on “Yes, I want to restart my computer now ” to finish installation. I570 Motherboard User Manual...
  • Page 49 BIOS Introduction BIOS Setup Standard CMOS Setup Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management Setup PC Health Status Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor/User Password Save & Exit Setup Exit Without Saving I570 Motherboard User Manual...

  • Page 50: Chapter 7 Award Bios Installation

    Power Management Setup Save & Exit Setup ► PnP/PCI Configurations Exit Without Saving ► PC Health Status : Select Item Esc: Quit F9 : Menu in BIOS F10: Save & Exit Setup Time, Date, Hard Disk Type ... I570 Motherboard User Manual...

  • Page 51: Standard Cmos Setup

    1 to 31 Year : 1999 to 2099 To set the date, highlight the “Date” field and use the PageUp/ PageDown or +/- keys to set the current time. Time The time format is: Hour 00 to 23 I570 Motherboard User Manual...
  • Page 52 Whenever the BIOS detects a non -fatal error, the system will stop and you will be prompted. All, But Keyboard The system boot will not be halted for a keyboard error; it will stop for all other errors I570 Motherboard User Manual...

  • Page 53: Advance Bios Feature

    When the CPU requests data, the system transfers the requested data from the main DRAM into cache memory, for even faster access by the CPU. These allow you to enable (speed up memory access) or disable the cache function. I570 Motherboard User Manual...
  • Page 54 Setup. When you select System, the system prompts for the User Password every time you boot up. When you select Setup, the system always boots up and prompts for the Supervisor Password only when the Setup utility is called I570 Motherboard User Manual...
  • Page 55 OS Select for DRAM > 64MB This option allows the system to access greater than 64MB of DRAM memory when used with OS/2 that depends on certain BIOS calls to access memory. The default setting is Non -OS/2. I570 Motherboard User Manual...

  • Page 56: Advanced Chipset Feature

    SDRAM. DRAM RAS# Precharge This option sets the number of cycles required for the RAS to accumulate its charge before the SDR AM refreshes. The default setting for the Active to Precharge Delay is 4. I570 Motherboard User Manual...
  • Page 57 Host cycles that hit the aperture range are forwarded to the AGP without need for transl ation. The aperture size also determines the maximum amount of system RAM that can be allocated to the graphics card for texture storage. The default setting is 64MB. I570 Motherboard User Manual...
  • Page 58 18bit SC 800*600 18bit SC 1024*768 18bit SC 1024*768 24bit SC 1280*800 18bit SC 1280*1024 24bit DC 1366*768 24 bit SC 1440*900 24bit DC 1400*1050 24bit SC 1600*1200 24bit DC 1920*1080 24bit DC 1920*1200 24bit DC I570 Motherboard User Manual...

  • Page 59: Integrated Peripherals

    PIO (Programmed Input/Output) allows the BIOS to communicate with the controller and CPU directly. The system supports five modes, numbered from 0 (default) t o 4, which primarily differ in timing. When Auto is selected, the BIOS will select the best available mode. I570 Motherboard User Manual...
  • Page 60 Normal. Other options include IrDA and ASKIR. Onboard Parallel Port These fields allow you to select the onboard parallel ports and their addresse s. The default values for these port is: On Board Parallel Port Disable 378/IRQ7 278/IRQ5 3BC/IRQ7 I570 Motherboard User Manual...
  • Page 61 These fields allow you to select t he onboard serial ports and their addresses. The default values for these ports are: On Board Serial Port 1 Disable Serial Port4 Use IRQ The default values for these ports are: IRQ5/IRQ10/IRQ11/IRQ12. I570 Motherboard User Manual...

  • Page 62: Pnp / Pci Configuration

    MPEG ISA/VESA VGA cards can work with PCI/VGA. When this field is enabled, a PCI/VGA can work with an MPEG ISA/VESA VGA card. When this field is disabled, a PCI/VGA cannot work with an MPEG ISA/VESA card. I570 Motherboard User Manual...

  • Page 63: Power Management Setup

    Power Management. Min. Saving Minimum power management Max. Saving Maximum power management. User Define Each of the ranges is from 1 min. to 1hr. Except for HDD Power Down which ranges from 1 min. to 15 min. I570 Motherboard User Manual...
  • Page 64 This field enables or disables the power on of the system through the modem connected to the serial port or LAN. Resume by Alarm This field enables or disables the resumption of the system operation. When enabled, I570 Motherboard User Manual...
  • Page 65 Date and Time. I570 Motherboard User Manual...

  • Page 66: Pc Health Status

    Temperatures/Voltages These fields are the parameters of the hardware monitoring function feature of the motherboard. The values are read -only values as monitored by the system and show the PC health status. I570 Motherboard User Manual...

  • Page 67: Load Fail-Safe Defaults

    Select this option to exit the Setup utility without saving the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Setup utility. I570 Motherboard User Manual...

  • Page 68: Note: Digital I/O Sample Code

    Note: Digital I/O Sample Code //File of the Main.cpp //===================================== ====================== //This code is for test I570 Super I/O. //===================================== ====================== #include <dos.h> #include <conio.h> #include <stdio.h> #include <stdlib.h> //===================================== ======================= #define W83627EHG_INDEX_PORT 0x2E #define W83627EHG_DATA_PORT 0x2F //===================================== ======================= #define W83627EHG_REG_LD 0x07...
  • Page 69 = Get_W83627EHG_Reg(0xF1) & 0x0F; if (ucBuf != ucDI) ucDI = ucBuf; printf("Digital I/O Input Chang ed. Current Data is 0x%X\n",ucDI); if (kbhit()) getch(); break; delay(500); return 0; //===================================== ======================= void ClrKbBuf(void) while(kbhit()) { getch(); } I570 Motherboard User Manual...
  • Page 70 Set_W83627EHG_Reg( unsigned char REG, unsigned char DATA) Unlock_W83627EHG(); outportb(W83627EHG_INDEX_PORT, REG); outportb(W83627EHG_DATA_PORT, DATA); Lock_W83627EHG(); //===================================== ======================= unsigned char Get_W83627EHG_Reg( unsigned char REG) unsigned char Result; Unlock_W83627EHG(); outportb(W83627EHG_INDEX_PORT, REG); Result = inportb(W83627EH G_DATA_PORT); Lock_W83627EHG(); return Result; //===================================== ======================= I570 Motherboard User Manual...
