Congratulations! You have just purchased one of the latest products
in signal processing technology to carry the famous KICKER name.
Your KICKER KX2 is designed and built to give you years of trouble-
free performance. This installation manual contains valuable informa-
tion on how to get the most out of your new KX2 Electronic Crossover.
Thanks for buying KICKER. Enjoy!
Features & Controls
High and Low Level Inputs Speaker outputs on your deck, including high
powered units, or low level RCA signal.
High Frequency Output Jacks High passed at 18 dB/octave with infinitely
variable frequencies of 40 to 300 Hz.
Low Frequency Output Jacks Low passed at 18 dB/octave in a range of 40
to 300 Hz.
High Frequency Switching Power Supply Provide isolation and allow the
output signals to reach as much as 10 volts for lower system noise.
R
Advertisement
Table of Contents
Related Manuals for Kicker KX2
Summary of Contents for Kicker KX2
- Page 1 Your KICKER KX2 is designed and built to give you years of trouble- free performance. This installation manual contains valuable informa- tion on how to get the most out of your new KX2 Electronic Crossover. Thanks for buying KICKER. Enjoy! Features &...
- Page 2 If you are using a source which does not have a remote turn on lead the KX2 can be turned on with a switched accessory lead. You can find this accessory power source in the factory harness at the back of the radio.
- Page 3 This is the setting where the head unit puts out the maximum output without sounding bad. Due to the wide range on the level controls of the KX2 you may not be able to hear the music loud enough to tell distortion yet. If this is the case, raise both Output Level controls to the halfway point (12 o’clock position)
- Page 4 If your head unit is an aftermarket piece with low level outputs (RCA) which have no more than 2 volts of output, the KX2 Output Level controls will need to be turned all the way up to get enough signal to the amplifiers. On the other...
- Page 5 System Diagrams System Diagram using the KX2 and KX Amplifiers Bi-Amp Configuration: Tweeter MID/HIGH AMPLIFIER Crossover Other Channel Midrange SUB AMPLIFIER From Source Subwoofers Other Channel...
- Page 6 System Diagram using the KX2 and KX Amplifiers Tri-Amp Configuration: Tweeter Front Mid/ High Amp Crossover Other Channel Midrange Rear Mid/ High Amp RCA "Y" Adapters From Source Other Channel Mids/ Coaxials Sub Amplifier Subwoofers Other Channel...
- Page 7 If problem stays on the same side, proceed on -Swap left and right High Pass RCAs at output of KX2 If problem trades sides in the vehicle, then the KX2 is defective If problem stays on the same side, proceed on...
- Page 8 ONE (1) YEAR from date of original purchase if purchased from but not installed by an Authorized KICK- ER Dealer. If the product is labeled “B Stock” and purchased from an Authorized KICKER Dealer, it is war- ranted for ONE (1) YEAR from date of purchase, regardless of place of installation. Should service be nec-...
