FEATURES
Heavy duty, rugged front loading Tape Deck Mechanism with Auto-stop, Pause, FF and REW functions.
AC mains and 12V DC car battery operation.
Provision for automatic changeover from AC to Battery Operation ensuring continuity of program.
100V line for long distance speaker connections .
Separate active BASS and TREBLE controls for shaping tonal quality of music & speech as desired.
Built-in FM Radio (Range 88MHz - 108MHz)
stability.
Three low impedance Microphone inputs and one Aux. Input. The Aux input is for connecting Mixer, CD Player, etc.
LINE / BOOSTER OUT for connecting additional booster amplifier.
SPECIFICATIONS
PLAYER SECTION
Track System
Tape Speed
FF/REW Time
Wow & Flutter
Tape Speed Accuracy
AMPLIFIER SECTION
Power Output
Input Channels
Frequency Response
S/N Ratio
Tone Control:
Output Taps for speaker : 4, 8, 16
matching
Line Output
Please read this manual thoroughly before making connections and turning on the power. Following the instructions in this
manual will enable you to obtain optimum performance from your new PA Cassette Player + Tuner.
Please retain this manual for future reference.
UPA-550FM
PA CASSETTE PLAYER + TUNER
MIC-1
MIC-2
MIC-3
REW
FF
AC / 12V DC
with varactor tuning, high sensitivity and excellent thermal
: 2 Track Monaural
: 4.75 cm / sec.
: 100 sec. Approx. (C-60)
: 0.35% Nominal
: Within +3% -2%
: 75 Watts RMS (Max)
: 50 Watts RMS at 10% THD
: 45 Watts RMS at 5% THD (Rated)
: 3 × Mic 0.6mV (Lo-Z) / 4.7k
: 1 × Aux 100mV / 470k
: 50Hz - 15,000Hz ±3dB
: >55dB
: Bass: ±10dB at 100Hz
: Treble: ±10dB at 10kHz
& 100V
: 400mV / 2.7k
PA CASSETTE PLAYER + TUNER
UPA-550FM
BASS
TREBLE
0
0
2
2
2
2
4
4
4
6
6
6
8
8
8
-10
+10
-10
+10
TUNING
TAPE
FM
MIC-3
MIC-2
88 MHz
108 MHz
MIC-3/TAPE
MIC-2/FM
4
6
4
6
PLAY
STOP/EJECT
PAUSE
2
8
2
0
10
0
10
FM - RADIO TUNER
Tuner Freq. Range
GENERAL
Power Supply
Semiconductors
Dimensions
Weight
* This unit is connected to 240V tap when leaving the factory.
Owing to continuous product up gradation, design & specifications are
subject to change without notice.
Specifications claimed are subject to permissible production tolerances.
45W RMS / 75W Max.
4
6
MON
ON
8
POWER
MIC-1/AUX
4
6
8
2
8
0
10
: 88MHz - 108MHz
: AC - 220-240V 50/60 Hz*
: DC - 12-14 V Car Battery
: 18 Transistors
: 9 Diodes
: 2 Zener Diodes
: 2 LEDs
: W340 × H145 × D270 mm
: 7.3 kg approx.
Advertisement
Table of Contents
Summary of Contents for Unisound UPA-550FM
- Page 1 PA CASSETTE PLAYER + TUNER 45W RMS / 75W Max. UPA-550FM UPA-550FM PA CASSETTE PLAYER + TUNER BASS TREBLE MIC-1 TUNING MIC-2 TAPE POWER MIC-3 MIC-2 88 MHz 108 MHz MIC-3/TAPE MIC-2/FM MIC-1/AUX MIC-3 PLAY STOP/EJECT PAUSE AC / 12V DC FEATURES Heavy duty, rugged front loading Tape Deck Mechanism with Auto-stop, Pause, FF and REW functions.
-
Page 2: Speaker Connections
• Front & Rear Panel Controls & Features UPA-550FM PA CASSETTE PLAYER + TUNER BASS TREBLE MIC-1 TUNING MIC-2 FUSE TAPE POWER MIC-3 MIC-2 88 MHz 108 MHz MIC-3/TAPE MIC-2/FM MIC-1/AUX MIC-3 PAUSE PLAY STOP/EJECT AC / 12V DC 9 10... -
Page 3: Using The Tone Controls
100V Line When it is desired to connect speakers or driver units at a distance over 50 meters, it is recommended that the 100V line output be used together with line matching transformer for each speaker. This prevents excessive power loss in the speaker cables. -
Page 4: Trouble Checks
• Maintenance & Trouble Checks TROUBLE CHECKS MAINTENANCE The following trouble checks will help to correct the most To get long trouble free service, maintenance is essential. common problems encountered with a cassette player. After some use the Head, Capstan, Pinch Roller etc. that come in contact with the tape, become dirty due to dust or The auto stop mechanism activates and the tape stops magnetic material on the tape.
Need help?
Do you have a question about the UPA-550FM and is the answer not in the manual?
Questions and answers
How to connect speaker to my UPA 550
To connect a speaker to the Unisound UPA-550FM:
1. Use the low impedance speaker terminals provided with impedance taps of 4, 8, or 16 ohms.
2. Connect speakers directly to these terminals if the distance is less than 50 meters.
3. Use 23/36 gauge or thicker cable for the connection.
4. Ensure the total impedance of all connected speakers is equal to or greater than the value specified on the terminal strip.
Alternatively, use the 100V line output for long-distance speaker connections.
