Page 1 User’s Manual Fire Alarm Back-up UPS1481 UNIT Emergency Power Systems Doc #. 6002-1646 Revision X8 Installation and Operating Documentation...
Page 2 OnLine Power FIRE ALARM BACK-UP UPS1481 UNIT, Congratulations on selecting one of the fine products from On-Line Power, the Leader in Power Protection Technology. Our wide product offering includes Uninterruptible Power Systems (UPS), Power Conditioners, Automatic Voltage Regulators and Specialty Transformers (e.g. computer-grade, medical- grade).
Page 3 OnLine Power On-Line Power, Inc. Proprietary Reproduction or Distribution forbidden NOTICE: THIS DOCUMENT CONTAINS PROPRIETARY This document contains proprietary and confidential information of On-Line Power, Inc. (”On-Line Power”). In consideration of the receipt of this document, the recipient agrees not to copy any of its contents, nor disclose them to or allow them to be used by any person not currently a On-Line Power employee or an employee of the recipient having a need to know, without the express written consent of On- Line Power, and further agrees to surrender this document to On-Line Power when...
Page 4 OnLine Power THIS DANGER SYMBOL IDENTIFIES A CONDITION OR ACTION WHICH WILL RESULT IN SEVERE INJURY OR DEATH TO AN INDIVIDUAL OR SEVERE DAMAGE TO EQUIPMENT OR OTHER PROPERTY. This Caution symbol identifies a condition or action which may result in minor injury to an individual or minor damage to the equipment or other property.
Page 5: Table Of Contents
OnLine Power SECTION SECTION 1 OPERATION INTRODUCTION BENEFITS PRODUCT FEATURES CUSTOMERS CONNECTIONS Fire Alarm Back-up UPS1481 SIZING OUTPUT LOADS OPTIONS SECTION 2 PREINSTALLATION SITE P LANNING AND PREPARATION 2-1-1 LOCATION CONSIDERATIONS PRE-INSTALLATION ELECTRICAL CONNECTIONS 2-3-1 REMOTE SIGNALING CONNECTIONS STORAGE SECTION 3 OPERATION START-UP PROCEDURES OPERATION...
Page 6 OnLine Power DATE APRIL 4, 2004 FEB 22, 2005 OCT 30, 2006 NOV 03, 2006 MAY 21, 2007 JUN 21, 2007 Nov. 15, 2007 MAY 30, 2008 PAGE PAGE X7 X8 X7 X8 X7 X8 5 - 9 X7 X8 12 –...
Page 7: Operation
OnLine Power SECTION 1 OPERATION — INTRODUCTION The Fire Alarm Back-up UPS1481 provides an exceptional level of load protection and monitoring capabilities. The critical load is provided with conditioned, regulated, computer grade power at all times. There is complete electrical isolation between the input and output voltage of the UPS.
Page 8: Product Features
OnLine Power systems, from electrical interference. The Fire Alarm Back-up UPS1481 protects these systems from power problems associated with poor quality AC power including complete power Outages. Electrical disturbances can come from practically anywhere: from the incoming power lines and even from within a building.
Page 9 OnLine Power Optional Output Isolation Transformer — This transformer is provided when the input and output voltages are different, or multiple output voltages are required or an isolation at output is required. The power to the primary of this transformer is selected either from UPS via output static switch and from utility input via bypass static switch.
Page 10 OnLine Power (6002-1646) REV.X8...
Page 11 OnLine Power FUNCTIONAL BLOCK DIAGRAM (CONTINUED) INPUT INPUT CONTACTOR C.B. INPUT FILTER (OPTION) INPUT POWER T.B. STEP CONT- tvss ACTOR COIL FULL BRIDGE RECTIFIER P4/J4 BATT BATT C.B. FILTER CKT UNIT GND EXTERNAL BATT C.B. (6002-1646) REV.X8 THE FUNTIONAL BLOCK DIAGRAM OF U.P.S FILTER DRIVER Q3/4...
Page 12: Customers Connections
OnLine Power CUSTOMERS CONNECTIONS 1-4-1 Input Power Connection by Customer (with no input C/B option) Connect input (Hot) at TB-1 Connect input Hot / Neutral at TB1-2 Connect input ground at TB1-3 INPUT PROTECTOR CUSTOMER Input wirings for various input voltages are same. When input cirucit breaker is used, input CB1 is installed in inside of the UPS.
Page 13 OnLine Power 1-4-2 OUTPUT POWER CONNECTION BY CUSTOMER FOR SAME INPUT AND OUTPUT VOLTAGE UNIT @ WITHOUT OUTPUT XFMR. 120V IN/OUTPUT UNIT OUTPUT PB2/1 (OPTION) UPS CABINET 240V IN/OUTPUT UNIT TO CUSTOMER LOAD OUTPUT 120V PB2/1 120V (OPTION) UPS CABINET (6002-1646) REV.X8 TO CUSTOMER LOAD 120V OUT...
Page 14 OnLine Power 1-4-3 OUTPUT POWER CONNECTION BY CUSTOMER FOR DIFFERENT INPUT / OUTPUT VOLTAGES USING OUTPUT XFMR. 240V/120 OUTPUT UNIT OUTPUT PB2/1 157V 240V 120V 120V 120V (OPTION) FOR EACH OUTPUT VOLT 120V OUTPUT UNIT TO CUSTOMER LOAD SAME AS (1) (6002-1646) REV.X8 TO CUSTOMER LOAD 120V...
Page 15: Fire Alarm Back-Up Ups1481 Sizing
OnLine Power WITH EXTRA AUX. OUTPUT CIRCUIT BREAKERS FOR VARIOUS OUTPUT VOLTAGES. OUTPUT The Fire Alarm Back-up UPS1481 SIZING Each model of the Fire Alarm Back-up UPS1481 is designed to supply a maximum load which is given by its kVA (1000’s of volt-amperes) and KW rating. It is very important that the load is within the rating of the FIRE ALARM BACK-UP ups1481 to ensure that the connected loads will be properly supported.
Page 16: Output Loads
OnLine Power The total load to be powered by the Fire Alarm Back-up UPS1481 must not exceed its rating. If the total load is exceeded, the Fire Alarm Back-up UPS1481 monitoring will sense an overload condition and a summary alarm will occur. The overload condition must be corrected by increasing the kVA rating of the Fire Alarm Back-up UPS1481.
Page 17: Site Planning And Preparation
OnLine Power SECTION 2 SITE PLANNING AND PREPARATION The Fire Alarm Back-up UPS1481 is designed for installation indoors and meets NEMA specifications for operating temperature, humidity, and utility voltage. These cabinets are corrosion resistant and rugged. The footprint of the Fire Alarm Back-up UPS1481 is less than 6 square feet.
Page 18 OnLine Power SITE PLANNING SPECIFICATIONS FOR KVA UNIT MODEL INPUT IkW / kVA NUMBER VOLTAGE WR3.0A58FPT1 WR3.0B58FPT1 WR3.0D58FPT1 WR5.0A58FPT1 WR5.0B58FPT1 WR5.0D58FPT1 WR7.5B58FPT1 WR7.5D58FPT1 WR010B58FPT1 70.0 WR010D58FPT1 10.0 WR012B58FPT1 12.5 WR012D58FPT1 12.5 WR015B58 FPT1 15.0 WR015D58FPT1 15.0 WR3.0A01FPN1 WR5.0A01FPN1 NOTE: FP DENOTES – FIRE PROTECTION Fire Alarm Back-up UPS1481 SERIES. (6002-1646) REV.X8 TABLE 2-1 INPUT...
Page 19 OnLine Power UL1481 MICRO-CHIPS & OTHER COMPONENT’S LIST INPUT MODEL OUTPUT KW / NUMBER VOLTAGE WR3.0A58FPT1 120/240V WR3.0B58FPT1 120/240V WR3.0D58FPT1 120/240V WR5.0A58FPT1 120/240 WR5.0B58FPT1 120V/240 WR5.0D58FPT1 120/240 WR7.5B58FPT1 120/240 WR7.5D58FPT1 120/240V WR010B58FPT1 120/240V WR010D58FPT1 120/240 WR012B58FPT1 120/240 WR012D58FPT1 120/240 WR015B58FPT1 120/240 WR015D58FPT1 120/240V...
Page 20: Pre-Installation
OnLine Power Pre-Installation The Fire Alarm Back-up UPS1481 is designed for indoor installations. All customer connections are brought through knockouts located on the top or side of the Fire Alarm Back-up UPS1481. The Fire Alarm Back-up UPS1481 consists of one (1) integrated cabinet — housing both the electronics and batteries (depending on KVA).
Page 21: Remote Signaling Connections
OnLine Power Verify that the main input circuit breaker, battery circuit breaker, and output circuit breaker(s), if provided are in the “OFF” position. See illustration 1-2 for the locations of the circuit breakers. See under Section 2-5, Storage for accessing the inside of the unit. Run the power wires up through the center area of the Fire Alarm Back-up UPS1481.
Page 22: Storage
The Fire Alarm Back-up UPS1481 Series will be stored for several months or longer, it should be serviced by charging the batteries for 24 hours at regular, three-month intervals. While in storage, service the unit using the procedures in this section. (6002-1646) REV.X8 IBM PC Serial Port to 2 to 3 to 5 -30°...
Page 23 OnLine Power During long-term storage, the batteries are subject to aging and deterioration. If after visual inspection, the batteries need to be replaced contact your OnLine Power dealer or the OnLine Power factory directly to obtain new batteries. The UPS is stored in its original packaging, unpack UPS using unpacking procedures outlined in Section 2-3-1.
Page 24: Operation
OnLine Power SECTION 3 3-1 Start-Up Procedures Verify that the main input circuit breaker, battery breaker, and output circuit breaker(s), if provided, are in the “OFF” or “down” positions. Refer to illustration 1-2 for the locations of the circuit breakers. It during the start- up procedures anything unusual occurs, immediately turn off the Input circuit breaker, and contact OnLine Power at (800) 797-7782 for technical assistance.
Page 25: Operation
OnLine Power At this point in time, the Fire Alarm Back-up UPS1481 should be providing AC line power. The Fire Alarm Back-up UPS1481 is not operating in the normal mode, turn off the input circuit breaker. Contact OnLine Power at (800) 797-7782 for technical assistance. Recheck that the output voltage is 120/240 VAC.
Page 26: Theory Of Operation
OnLine Power 3-2-2 Turning off the Fire Alarm Back-up UPS1481 : Turn off the Output Breaker(s), if provided. Turn off the Battery Breaker. Turn off the Input Breaker, if provided. Theory of Operation Illustration NO TAG is a simplified block diagram of the Fire Alarm Back-up UPS1481. This diagram provides an excellent tool in identifying the major building blocks within the Fire Alarm Back-up UPS1481 .
Page 27 OnLine Power Optional Output Isolation Transformer (TI) — The transformer performs a number of critical functions. First, it provides excellent common mode and normal mode noise isolation of the load from the input or inverter power. Secondly, it provides voltage transformation and tight regulation of the output voltage while the Fire Alarm Back-up UPS1481 is operating from its internal inverter or directly from utility via bypass circuitry.
Page 28 OnLine Power COMPONENT’S LOCATION & LIST (6002-1646) REV.X8...
Page 29 OnLine Power COMPONENT’S TABLE (6002-1646) REV.X8...
Page 30 OnLine Power (6002-1646) REV.X8...
Page 31 OnLine Power ITEM 18 (CONTINUED) (6002-1646) REV.X8...
Page 32: Appendix A: Extended Battery Run Chart
OnLine Power APPENDIX A: EXTENDED BATTERY RUN CHART Battery 7050- 7050- 7050- kitPart# LoadKV 0.75 Minutes -015 -015 -015 Batt.AH 8x25 8x25 8x25 Cabinet Minutes -030 -030 -030 Batt.A.H 8X25 8X25 8X25 Cabinet Minutes -060 -060 -060 Batt.A.H 8X25 8X25 8X35 Cabinet Minutes...
Page 33 OnLine Power OTHERS ARE CALCULATED VALUES BASED ON THE BATTERY MANUFACTURER'S DATA FOR BACK UP TIME. APPENDIX B – Optional Main Input & Main Output Breakers for various models (*All Values are typical as reference only) TABLE B-1: External Output Breaker (Standard KAIC) 120 Vac 40 Amps, 120 VAC, 1 Pole, 14 KAIC...
Page 34 OnLine Power TABLE B-3: Input Breaker Ampacity (Standard KAIC) 120 Vac 50 Amps, 120 VAC, 1 Pole, 14 KAIC OLP P/N: 2025-784 70 Amps, 120 VAC, 1 Pole, 14 KAIC OLP P/N: 2025-997 12.5 TABLE B-4: Input Breaker Ampacity (hIGH KAIC) 120 Vac 50 Amps, 120 VAC, 1 Pole, 42 KAIC...
Page 35 OnLine Power APPENDIX C: LCD DISPLAY MENU & TROUBLSHOOTING GUIDE Two screens (A, B) are updated continuously for units without optional output transformer. Three screens (A, B, C) are updated continuously for units with optional output transformer. Start-up Screen When input power is applied for the unit, LCD panel lights up and displays OnLine Power UPS Project If LCD display panel is not lit, unit has a problem.
Page 36 OnLine Power SCREEN B: The screen appears as below. OUTPUT: ______V Line 1 INPUT : ______V Line 2 DC BUSS: ______V Line 3 BATT: ________V Line 4 4. Indicates output voltage and power in watts, when output transformer is not used. It indicates primary voltage of the output transformer (T1) (120 VAC, typically) when T1 is used.
Page 37 OnLine Power (6002-1646) REV.X8...
Page 38 OnLine Power APPENDIX D: SPECIFICATION POWER RATING (KW) VOLTAGE (VAC) INPUT MAXIMUM CURRENT TOLERANCE FREQUENCY (Hz) POWER FACTOR OVERCURRENT PROTECTION NUMBER OF WIRES POWER CONNECTION OUTPUT RATING (KVA/KW) VOLTAGE (VAC) VOLTAGE REGULATION FREQUENCY (Hz) WAVESHAPE HARMONIC DISTORTION CREST FACTOR POWER FACTOR STEADY-STATE CURRENT OVERLOAD PROTECTION...
Page 39 OnLine Power POWER RATING (KVA/KW) BATTERY BATTERY RUN TIME BATTERY TYPE NOMINAL DC VOLTAGE OVERCURRENT PROTECTION PACKAGING MONITORING AND COMMUNICATIONS LCD SCREEN INDICATORS RELAY INTERFACE CONTACT RATING INTERFACE CONNECTION ENVIRONMENTAL USRGE WITHSTANDABILITY OPERATING TEMPERATURE OPERATING RELATIVE HUMIDITY ALTITUDE COOLING PHYSICAL SIZE WxHxD in.
Page 40 OnLine Power (6002-1646) REV.X8...
Page 41 OnLine Power (6002-1646) REV.X8...
Page 42 OnLine Power BATTERY CABINET "B" LEVEL LEVEL B" CABINET BATTERY )QTY:10) SYSTEM LEVEL LEVEL LEVEL LEVEL "B" OR "C" BATTERY (QTY 16) SYSTEM CABINET (6002-1646) REV.X8 BATT C.B 120VDC BUSS BATT C.B 192VDC BATT UPS CAB BATT UPS CAB...
Page 43 OnLine Power LEVEL LEVEL LEVEL LEVEL "C" CABINET BATTERY (QTY:20) SYSTEM UPS CONTROL CABINET "A" LEVEL LEVEL 96VDC 3KW/5KW (8X35AH) BATERRY SYSTEM ONLY (6002-1646) REV.X8 VDC BUSS BATT C.B UPS CAB BATT C.B 192VDC BUSS BATT...
Page 44 OnLine Power BATTERY CABINET "B" LEVEL LEVEL B CABINET BATTERY (QTY: 8 ) SYSTEM (6002-1646) REV.X8 96VDC BATT C.B UPS CAB BATT...
Page 45 OnLine Power (6002-1646) REV.X8...
Page 46 OnLine Power (6002-1646) REV.X8...
Page 47 OnLine Power (6002-1646) REV.X8...
Page 48 OnLine Power (6002-1646) REV.X8...
Page 49 OnLine Power (6002-1646) REV.X8...
Page 50 OnLine Power (6002-1646) REV.X8...
