- Page 1 JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 1 Safety and operating manual Pedestrian Lawnmowers JCB 46S COMBI ORIGINAL INSTRUCTIONS JCB, SO53 3LE www.JCBDIY.com Customer Helpline 0845 6005526...
- Page 2 JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 2 Identification label, main components and symbols Identification label 1. Conformity mark according to directive 2006/42/CE 2. Type of machine 3. Weight in kg 4. Operating engine power and speed 5. Acoustic power level according to directive 2000/14/CE 6.
-
Page 3: Operation
JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 3 Safety Regulations - To be followed carefully A) TRAINING in place. 12) Do not change the engine governor settings or overspeed the 1) Read the instructions carefully. Get familiar with the controls engine. - Page 4 JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 4 Assembly Instructions Tools required, not supplied Fittings supplied NOTE - The machine can be supplied with some parts already assembled. WARNING - Unpacking and completing the assem- Ref. Description Q.ty bly should be done on a flat and stable surface, with...
- Page 5 JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 5 Assembly Instructions Attach the top of the handle (B) using the bolts (2), washers (3), knobs (4) and nuts (5) supplied, as shown. Fit the cable clamp (C) as shown and secure the control cables.
-
Page 6: Description Of Controls
JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 6 Description of controls Throttle trigger The throttle (where fitted) is controlled by the lever (1) and positioned as shown on the relative plate. a. Slow b. Fast c. Choke Blade brake lever... - Page 7 JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 7 Operation IMPORTANT: Preparing the machine Before starting the engine for the first time, carefully read the instructions as set out in the engine handbook. This machine cuts lawns in various modes; before start- ing work, prepare the machine based on how the lawn is CAUTION! Check oil level before starting.
- Page 8 JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 8 Operation Starting the engine To start, follow the instructions in the engine manual, pull the blade brake lever (1) against the handle and firmly pull the starter cable knob (2). Grass cutting The lawn will look better if it is always cut to the same height and in alternate directions.
-
Page 9: Maintenance
JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 9 Maintenance IMPORTANT – Regular, careful maintenance is off in time due to the abrasive action of the cut grass; essential for keeping the safety level and original in this case, intervene promptly by touching up the performance of the machine unchanged in time. -
Page 10: Environmental Protection
JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 10 Environmental protection Environmental protection should be a priority of consid- sions for the disposal of pakaging, oils, petrol, batter- erable importance when using the machine, for the ben- ies, filters, damaged parts or any elements which efit of both social coexistence and the environment in have a strong impact on the environment;... -
Page 11: Specifications
JCB rsb 46S_11-171503977/0:JCB rsb 46S_11-171503977/0 7-12-2010 10:16 Pagina 11 Specifications Maximum noise and vibration levels Engine......Honda GCV 135 Operator ear noise pressure level (according to Dimensions (L x W x H) cm . -
Page 12: Warranty Statement
• trade or hire use one the product of our unswerving focus on innovation, • repairs attempted by anyone other than an authorised quality and engineering. JCB lawn mowers are built to agent give you the same world beating standards of perform- •...
