Amp’ed RF Technology BT-210 User Manual

Product Specification

Description
The BT-210 Bluetooth USB Adapter is a perfect
solution for those looking for easy, all-in-one,
Bluetooth connectivity.
Our design eliminates the need for a system to apply
its processing and memory resources to running the
BT-210 since it already has its own microprocessor,
memory, and firmware!
Customized firmware
interaction, power optimization, security, and other
proprietary features may be supported and can be
ordered pre-loaded and configured.

Additional Documentation

 abSerial User Guide
 abSerial Reference Guide
 BT-11 Datasheet
©2010 Amp'ed RF Technology Inc
11/12/10
for peripheral device
1879 Lundy Ave, Suite 138, San Jose, CA 95131, USA
www.ampedrftech.com
Amp'ed RF Technology, Inc.
Features
 Bluetooth Radio
- Fully embedded Bluetooth v2.1+EDR with profiles
- Class 1 radio
- Complete RF ready module
- Wireless data communications
- Integrated chip antenna
- 128-bit encryption security
- Range up to 120m LOS
- FCC & Bluetooth qualified
 ST Micro Cortex-M3 microprocessor up to 70MHz
 Memory
- 256K bytes flash memory
- 48K bytes RAM memory
 Data Rate
- 2M bps maximum data rate
- Multipoint capability up to 7 slaves
 Serial Interface
- COM port, up to 921K baud
- USB v2.0
 User Interface
- AT command set (abSerial)
- Firmware upgrade over UART
(phone) 408 213-9530
(fax) 408 213-9533
BT210 Datasheet
Page 1 of 6
