Data-Tronix DT-05PTWR300MB User Manual

Ieee802.11 b/g/n 300mbps wireless router
Hide thumbs
Table of Contents

Advertisement

Quick Links

DT-05PTWR300MB
IEEE802.11 b/g/n 300Mbps Wireless Router
USER'S GUIDE
Version l.0

Advertisement

Table of Contents
loading

Summary of Contents for Data-Tronix DT-05PTWR300MB

  • Page 1 DT-05PTWR300MB IEEE802.11 b/g/n 300Mbps Wireless Router USER'S GUIDE Version l.0...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Chapter l. Introduction 1.1 0verview 1.2 Features 1.3 Environment 1.4 Package contents 1.5 System Requirements Chapter 2. Hardware Installation 2.1 Interface description 2.2 Hardware connection guide Chapter3. Setup guide 3.1 TCP/IP Configuration 3.1.1 Network Configuration for DHCP 3.2 Quick setup of PPPoE for ADSL sharing 3.3 0peration Modes 3.4 Internet Settings...

  • Page 3: Chapter L Introduction

    Chapter l Introduction 1.1 0verview The DT-05PTWR300MB is a high performance wireless broadband router that integrates Wireless AP, NAT-Router, 4 port Ethernet switch and a Firewall. It supports 802.11 b/g/n to supply 300Mbps of wireless bandwidth. The unit can be set to bridge or gateway mode and provide one 10/100Mbps WAN port to connect to the internet and four 10/100Mbps switch LAN ports to expend your LAN.

  • Page 4: Environment

    Can backup and re-load current settings of the device. Can monitor the status of the device and the statistics of the communications through web setup software Firmware upgrade support of root files upgrade, Uboot upgrade, and Factory Settings upgrade 1.3 Parameters and Environments .

  • Page 5: Chapter 2. Hardware Installation

    Chapter 2. Hardware Installation 2.1 Interface description 2.2 Hardware connection guide The chart is for reference only.

  • Page 6: Chapter3. Setup Guide

    Chapter 3. Setup guide 3.1 TCP/IP Configuration 1 . Click the Start button, then click Control Panel. 2. Double click the Network icon and select the Create a new connection in the Network window. Follow the network wizard instructions until conclusion, then skip to step 6. If you have installed TCP/IP protocol before, please skip to step 6.

  • Page 7: Quick Setup Of Pppoe Foradsl Sharing

    Windows XP 1. Select Network Connections in the Control Panel. 2. Right-click Ethernet Local Area Connection, then click Properties. 3. In the “General” tab, select Internet Protocol (TCP/IP), click Properties. 4. The Internet Protocol (TCP/IP) Properties window appears. 5. Click the Obtain an IP address automatically button. 6.
  • Page 8 3. Select Gateway operation mode as in figure4 4. Click the Configuration Menu - Internet Settings - WAN, Select PPPoE (ADSU for WAN connection type, then input your ADSL User Name and Password you received From your ISP into the corresponding fields, as follows, then click the Apply button.
  • Page 9 5. Click Wireless Settings – Basic and Input your Network Name (SSID). Keep other default parameters indicated in figure 6, then click Apply. 6. Setup wireless access security to prevent unauthorized access: Options are: WPA/WPA 2/WPA-PSKIWPA2-PSK Security Note for WPA Algorithms: TKIP is only for 54Mbps, Input a Password in the Pass Phrase table, then click Apply.

  • Page 10: 0Peration Modes

    7. Connect the WAN port of this Router with the LAN port of the ADSL modem, then reboot the Router and ADSL modem. You can share the internet connection. For the settings of the ADSL modem please refer to its user's guide. 3.3 0peration Mode Please refer to fig 4 in 3.2.3, you can set this device to Bridge or Gateway mode.
  • Page 11 IP Address: Enter the IP address assigned by your ISP. Subnet Mask: Enter the Subnet Mask assigned by your ISP. Default Gateway: Enter the Gateway assigned by your ISP. Primary DNS Server: Enter the Primary DNS IP address assigned by your ISP. Secondary DNS Server: Enter the Secondary DNS IP address assigned by your ISP.
  • Page 12 3.4.1.3 PPPoE(ADSL) mode If you connect to the Internet through a DSL line, check with your ISP if they use PPPoE, If they do, select PPPoE. Refer to figure 5 in 3.2.4 (page 7). Enter User Name and Password from the ISP, You can select one Operation mode from following three: Keep Alive: Always online;...

  • Page 13: Dhcp Clients List

    Set the IP Address and Subnet Mask to your internal network settings. Unless you have specific internal network needs, these should be no reason to change the values. DHCP Type: Can be set to Disable or Server mode. If the Server mode is selected, configure your computers to automatic IP allocation mode.

  • Page 14: Wireless Settings

    3.5 Wireless Settings This device can let all wireless nodes (PC, Smart Phone, etc.) equipped with a IEEE802.11/b/g/n wireless network adapter connect to your Intranet. 3.5.1 Basic Settings You should configure at minimum the Wireless settings for communication, such as Network Name (SSID) and Channel.

  • Page 15: Wireless Access Security Setup

    knowledge about wireless LAN. These settings should not be changed unless you know what effect the changes will have on your Access Point. Beacon Interval: Beacon frames are transmitted by an access point at regular intervals to announce the existence of the wireless network. The default behavior is to send a beacon frame once every 100 milliseconds (or 10 per second).

  • Page 16: Wps Setting(For Applicable Units)

    3.5.3.2 WPA/WPA-PSK/WPA2/WPA2-PSK WPA provides significantly stronger wireless data encryption than WEP. Refer to fig. 7 in 3.2.6(page 8). You can choice a Security Mode from: WPA/WPA-PSK/WPA 2/WPA 2-PSK then choice a WPA Algorithm from: TKIP or AES. TKIP is only for 802.11 b/g (54Mbps max). For faster connection speeds greater than 54Mbps, select AES or TKIP WPA algorithms.

  • Page 17: Wireless Station List

    WPS: Enable or Disable the WPS function. The default is Disable. WPS mode: You can set the WPS mode in WPS Progress section, There are two modes for your selection: PIN code or PBC (Push-Button Configuration). PIN mode: If you select the PIN mode WPS, you must know the PIN code of the client node and input the PIN into the PIN field.

  • Page 18: Mac/Ip/Port Filtering

    3.6 Firewall The system provided firewall functions include: MAC/IP/Port filtering, Content Filtering, Port Forwarding, System Security and DMZ, to help prevent your network from a hacker attack or to limit some clients' access. 3.6.1 MAC/IP/Port Filtering Select Firewall, then MAC/IP/Port Filtering from the main menu to enter the page as indicated in figure 19.

  • Page 19: System Security

    1. Select Virtual Server Settings to Enable; 2. Enter the IP address of the Virtual Server into the IP Address field; 3. Enter the Port range you want to forward into the Port Range field; 4. Select a Protocol of TCP, UDP, or TCP&UDP; 5.

  • Page 20: Content Filtering

    1. You can Deny or Allow Remote management from the WLAN. 2. You can Enable or Disable Ping form the WAN. 3. You can Enable or Disable Stateful Packet Inspection (SPI). 3.6.5 Content Filtering You can set the Web content filter, Web URL filter, and Web HOST filter with this function.

  • Page 21: Administration Management

    3. Webs Host Filter: If you want limit clients from accessing a certain Host on the Web, input the Keyword of the Host into the Keyword field in the Add a Host (keyword) Filter table, then click Apply. If you want to delete a previously listed Host, select the Host in the Current Website Host Filters table, then click the Delete button.

  • Page 22: Firmware Upgrade

    1. Input the DDNS server name in the Dynamic DNS Provider field. 2. Input the Account, Password and DDNS name provided by the DDNS provider. 3. Click the Apply button to save it. 3.7.2 Firmware Upgrade You can upgrade the firmware including : Root file system (root_ulmage), Boot loading Code (uboot.img) and Factory EEPROM settings from this submenu.

  • Page 23: Status

    1 . Backup Settings : Click the Export button in the Export Settings table, save the system settings into a file, the default file name is RT2880_Settings.dat. 2. Restore Settings: Click the Browse button in the Import Settings table, select the file you did the backup before from your local computer, then click the Import button in the import settings table.

  • Page 24: Faq's

    Chapter 4. FAQ’S 1. Why can't I search for any wireless AP (SSID) in the Wireless connection interface of my wireless adapter in Windows ? Answer: If you choose Windows, configure your wireless LAN, and ensure the Wireless Zero Configuration Service is started . Click the Start button and choice Settings, then click Control Panel, Double click Management Tool icon, then double click the Services icon, Choose Wireless Zero Configuration service, then start it.

  • Page 25: Warranty

    DATATRONIX 1-Year Limited Warranty DATATRONIX. (the "Company") warrants to the Original Purchaser that the item purchased is free from defects in workmanship or material under normal use. This warranty starts on the date of shipment of the hardware to the Original Purchaser.

  • Page 26: Troubleshooting

    Further troubleshooting assistance can be found on-line at www.datatronix.biz in addition to support from Datatronix sales engineers at (610) 429-1821, Press 3, then press 2. LEGAL NOTICES FCC STATEMENT PART 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
