Chapter 5. Lenovo V580 and V580c

This chapter presents the following product-specific service references and parts information:
• "Specifications" on page 37
• "Status indicators" on page 38
• "Fn key combinations" on page 41

Specifications

This topic lists the physical features for the Lenovo V580 and V580c models.
Processor
• Windows 7: To view the processor information of your computer, click Start, right-click Computer, and
then click Properties.
• Windows 8: From desktop, move the cursor to the top-right or bottom-right corner of the screen to
display the charms. Then click Settings ➙ PC info.
Memory
• Double data rate 3 (DDR3) synchronous dynamic random access memory (SDRAM)
Storage device
• 2.5-inch (7 mm height or 9.5 mm height) hard disk drive
• mSATA solid-sate drive
Note: If the computer is equipped with both a hard disk drive and an mSATA solid-state drive, do not
use the mSATA solid-state drive as a bootable device. The mSATA solid-state drive is used for "cache"
function only.
Display
• Size: 15.6 inches (396 mm)
• Resolution:
– LCD: 1366-by-768
– External monitor: Maximum 2048-by-1536
• Integrated camera (on some models)
• Built-in microphones
Keyboard
• 6-row Lenovo keyboard
• Fn key
• Recovery button
Interface
• Combo audio jack (stereo headphone or headset)
• Two USB 2.0 connectors
