MODEL 6001
REVERSE OSMOSIS
High Purity Water
Production System
THREE STAGE Filtration
for the reduction of:
♦
Organic Matter
♦
Total Dissolved Solids (TDS)
♦
Suspended Solids
♦
Chemical Contaminants
♦
Bad Taste and Odors
MEMBRANE PROCESS
for protection against:
♦
Cysts
♦
Bacteria
♦
Virus
♦
Micro-organisms
♦
65 GPD @ 60 PSI -72F
INSTALLATION AND OPERATIONS
MANUAL
YACHT-MATE PRODUCTS, Inc
Ft. Lauderdale FL 1-877-922-4862(YACHTMATE) * (954)769-9564
www.yachtmate.com* E-Mail – sales@yachtmate.com
.
GM-5001 Manual – Revised 6-20-2002
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Galley-Mate 6001
- Page 1 MODEL 6001 REVERSE OSMOSIS High Purity Water Production System THREE STAGE Filtration for the reduction of: ♦ Organic Matter ♦ Total Dissolved Solids (TDS) ♦ Suspended Solids ♦ Chemical Contaminants ♦ Bad Taste and Odors MEMBRANE PROCESS for protection against: ♦...
- Page 2 NO DRINKING WATER SYSTEM SHOULD BE CONSIDERED YOUR PRIMARY SOURCE OF DISINFECTION FOR POTENTIALLY MICROBIOLOGICALLY UNSAFE WATERS. EVEN THOUGH YOUR GALLEY-MATE SYSTEM IS A WATER PURIFICATION APPLIANCE, WE CAN ONLY CLAIM 99.99% REDUCTION OF MICRO- ORGANISMS., THOUGH IN THEORY SMALLER THAN OUR MEMBRANE PORES. FOR WATER DISINFECTION OF STORED FRESH WATER CONTACT FACTORY.
-
Page 3: Starting Your Installation
STARTING YOUR INSTALLATION PREPARATION Determine the location for the installation of the RO Check the following list of components to ensure that system. Avoid locations where the system might come all parts are packed with your system. Note, installation in contact with hot surfaces such as engines, exhaust, requirements will vary from vessel to vessel. - Page 4 PURE WATER FAUCET INSTALLATION Drilling with the Recommended Relton Cutter...
- Page 5 1- PRE –06 2- MEMBRANE –09 3- POST –10...
-
Page 6: Parts Breakdown
FAUCET AND SYSTEM COMPONENTS PARTS BREAKDOWN Standard Faucet Assembly Each Galley-Mate Reverse Osmosis System is packed with a long reach polished chrome faucet. The instruc- tions shown below will cover most variations of the Standard Faucet, which is available in decorator colors, STANDARD SYSTEMS polished brass, gold plated, and brushed antique finishes. -
Page 7: Drain Connections
WATER FEED SOURCE AND REJECT DRAIN CONNECTIONS FEED WATER CONNECTIONS: DRAIN CONNECTIONS: The feed water connection to the Galley-Mate marine All Membrane Purification Systems have one feed water water purification system will vary from vessel to inlet and two outlets, a purified water stream and the vessel, depending on vessel size and type of piping reject drain stream. -
Page 8: Maintenance
ACTIVATION, TROUBLESHOOTING, MAINTENANCE Activating the System For the First Time Connect tank line to tank. Open faucet by lifting handle to Connect the feed line if fed from a chlorinated city allow the air out of the system. Slowly open feed water water source, to the storage tank connection. - Page 9 REMOTE TANK INSTALLATION AS A SPACE SAVING MOVE, VESSELS OFTEN REQUIRE INSTALLATION OF THE GALLEY-MATE SYSTEM IN ENGINE ROOMS, OR QUARTERS BELOW THE GAL- LEY. ON SUCH INSTALLATIONS, RUN THE 3/8” LINE FOR FAUCET UP TO GAL- LEY SINK. FOR A REMOTE TANK INSTALLATION, PLACE A QUICK CONNECT “T”...
- Page 10 Reverse Osmosis (RO) is the technology of membrane separations of fluids. When water is processed through the Galley-Mate RO System, it is important to know that the system is not an ordinary filter, with one inlet and one outlet. Your RO has one inlet and two outlets. One outlet is comprised of a pure water out- let that takes your high purity water to a storage tank, and then to a dispensing faucet.
