Casio 3136 Operation Manual

MA0804-EA
About This Manual
General Guide
• Press C to change from mode to mode.
• In any mode (except when a setting screen is on the display), press B to illuminate
the display for about two seconds.
Timekeeping Mode
Timekeeping
Month – Day
Day of week
PM indicator
Hour : Minutes Seconds
To set the time and date
1. While in the Timekeeping Mode, hold down A until the second's digits flash on the
display, which indicates the setting screen.
2. Press C to move the flashing in the sequence shown below.
Seconds
Day
3. While the seconds setting is selected (flashing), press D to reset it to 00. If you
press D while the seconds setting is in the range of 30 to 59, the seconds are
reset to 00 and 1 is added to the minutes. If the seconds setting is in the range of
00 to 29, the minutes count is unchanged.
• While the DST* setting is selected (DST on indicator is flashing), press D to
toggle it on (On) and off (OF).
• The DST on/off setting you select for the Timekeeping Mode affects the World
Time Mode.
• While the city code setting is selected, use D and B to scroll through the
available codes until the one you want to use as your home time city is displayed.
• For full information on city codes, see the "City Code Table".
4. While any other setting is selected (flashing), press D to increase it or press B to
decrease it. Holding down D or B scrolls at high speed.
5. Press A to exit the setting screen.
• The day of the week is set in accordance with the date automatically.
• The date can be set within the range of January 1, 2000 to December 31, 2099.
• The watch's built-in full automatic calendar makes allowances for different month
lengths and leap years automatically. Once you set the date, there should be no
reason to change it except after replacement of the watch's battery.
* See "Daylight Saving Time (DST) Setting" for details about the DST setting.
Backlight Precautions
The backlight uses an EL (electro-luminescent) panel that causes the entire display to
glow for easy reading in the dark. In any mode (except when a setting screen is on the
display), press B to illuminate the display for about two seconds.
• The electro-luminescent panel that provides illumination loses power after very long
use.
• The illumination provided by the backlight may be hard to see when viewed under
direct sunlight.
• The watch may emit an audible sound whenever the display is illuminated. This is
due to vibration of the EL panel used for illumination, and does not indicate
malfunction.
• The backlight turns off automatically whenever an alarm sounds.
• Frequent use of the backlight shortens the battery life.
Operation Guide 3136
• Depending on the model of your watch, display text
appears either as dark figures on a light background or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
• Button operations are indicated using the letters shown
in the illustration.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
World Time Mode
Press .
Use the Timekeeping Mode to set and view the current
time and date.
• Pressing A in the Timekeeping Mode will display the
currently selected Home City.
• Press D to toggle between 12-hour and 24-hour
formats.
• With 12-hour format, times between midnight and noon
are indicated by AM, while times between noon and
midnight are indicated by PM.
• The AM and PM indicators do not appear when you are
using 24-hour format.
DST City code Hour
Minutes
Month Year
• If you do not perform any operation for a few minutes while a setting screen (with
flashing digits) is on the display, the watch exits the setting screen automatically.
• If you do not perform any operation for a few minutes in the Alarm Mode, the watch
reverts to the normal timekeeping screen automatically.
Alarm Mode Stopwatch Mode
World Time
World Time shows the current time in 30 cities (29 time
Mode indicator
zones) around the world.
• All of the operations in this section are performed in the
City code
World Time Mode, which you enter by pressing C.
To view the time in another city code
In the World Time Mode, press D to scroll through city
codes (time zones).
• For full information about city codes, see the "City Code
Table".
• If the current time shown for a city is wrong, check your
Timekeeping Mode time and Home City code settings
Current time in the zone
and make the necessary changes.
of the selected city code
Daylight Saving Time (DST) Setting
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To toggle a city code time between Standard Time and Daylight Saving Time
1. In the World Time Mode, use D to display the city code
DST indicator
(time zone) whose Standard Time/Daylight Saving Time
setting you want to change.
2. Hold down A for about one second to toggle between
Daylight Saving Time (DST indicator displayed) and
Standard Time (DST indicator not displayed).
• The DST indicator will appear on the display whenever you display a city code for
which Daylight Saving Time is turned on.
• Note that the DST/Standard Time setting affects only the currently displayed city
code. Other city codes are not affected.
Alarms
You can set five independent Daily Alarms. When an
Mode indicator
alarm is turned on, the alarm tone sounds when the alarm
time is reached.
You can turn on an Hourly Time Signal that causes the
watch to beep twice every hour on the hour.
• There are six screens in the Alarm Mode. Five are for
daily alarms (indicated by numbers from
x5 ), and one is for the Hourly Time Signal (indicated by
SIG ).
• All of the operations in this section are performed in the
Alarm time
(Hour : Minutes) Alarm Mode, which you enter by pressing C.
Alarm number
Countdown
Timer Mode
x1 through
1
