- Page 1 Operating instructions and installation guide for Multivision Plus Audio / video switch All rights reserved © FTEmaximal...
-
Page 2: Table Of Contents
Table of contents Multivision Page Installation Safety instructions Unconditional note Included parts Is the delivery complete? Multivision parts Main function Accessories Technical data Fast information What is for what Correct position Multivision set up Remote control system Combinations Connecting the Multivision Remote control Parameters Modulator’s output channel... -
Page 3: Safety Instructions
Multivision Safety instructions Very important Multivision system has to be installed according to the instructions of this manual and the general technical rules. If you do not agree with it, intentional or careless, the manufacturer is out of warranty and responsibility. - Page 4 Safety instructions Multivision Never pull on the cable for the power supply, every time pull the plug directly. Otherwise the cable will be damaged. Have a look that the plug always has strong and safety hold to the socket. Shaky plugs or sockets have a risk of fire disaster. Defects like this must be fast repaired by a professional.
-
Page 5: Included Parts
Multivision Included parts Is the delivery complete? Please check whether in your delivery following items are contained: ☺ Multivision system Two remote controls with batteries ☺ 1,5V LR 6 (Size AA) ☺ Remote infrared receiver ☺ LED cable ☺ Power supply for infrared receiver ☺... -
Page 6: Multivision Parts
Multivision parts Multivision Available parts ☺ 5 inputs (2x RCA + 3x Scart) ☺ Remote control with direct selection of the input. ☺ Remote receiver of infrared signals that let control the equipments from another room. ☺ Adjustable PLL Modulator CH21...CH69 Multivision allows to select between 5 available inputs Scart and RCA connectors. -
Page 7: Accessories
Multivision Multivision parts Accessories Following accessories are available Additional Remote control MMV Art. number: 6000502 The remote control MMV is considered as second remote control exclusively for the adjacent rooms. It can only control modulator output avoiding selection changes at Scart output or disconnections of Multivision. -
Page 8: Technical Data
Multivision parts Multivision Technical features A/V frequency range 20Hz – 15kHz A/V impedance 75Ω (Video), 47kΩ (Audio) A/V input level 1 Vpp (Video), 0.4V (Audio) A/V inputs 2xRCA, 3x21pin Scart A/V outputs 1x 21pin Scart Impedance of modulator 75Ω Output frequency range 470 - 862 MHz Output level of modulator 85 dBµV... - Page 9 Multivision Fast guide What is for what? Front panel of the Multivision POWER Button Multivision On or Stand by STAND BY LED lights up in the stand by mode IR-Sensor Reception eye for the signals of the remote control F4-F8 Manual selection buttons for the inputs AUX1 - VCR A/V-RF Selects manually the input to be programmed Buttons F4-F9 are equipped with bicolour light-emitting diodes (LED) for simple programming, the colour will indicate selected function.
- Page 10 Fast Guide What is for what? IR 5 IR Remote Receptor IR 4 IR 1 IEC-Connector for TV set IR 1 IR 2 LED Indicator for signal IR IR 3 Level adjuster for return channel IR 4 IR-Receiver for IR signal IR 2 IR 5 IEC-Connector for antenna socket...
-
Page 11: Correct Position
Multivision Correct position Setting up Multivision The correct site ..logically, as nearer as possible to main TV set and other A/V signal sources, it will be better. You have to choose a stable position at wich you can lay necessary connecting cables in a comfortable way and plug the Multivision. -
Page 12: Remote Control System
Correct position Multivision IR Remote Reception For the right function of remote control repeater, the choice of LED cable position is very important. Cable length is 1,9 meters. The LED cable transmits the signals generated in remote rooms to control the Multivision as well as the rest of devices that have this function. -
Page 13: Combinations
Multivision Combinations Connecting the Multivision Here is an installation example of the Multivision system. It seems to be complicated but following these instructions you will see that’s very easy to install. All rights reserved © FTEmaximal... -
Page 14: Remote Control
Connection of the inputs R2 - R6 Once all connections with equipments A/V are made, plug the Multivision. Connections R2 (AUX1) and R3 (AUX 2) are used to connect equipments with RCA outputs for instance Handycam or videogames. Input R4 is marked as SAT (satellite receiver) and can be selected from the front panel or remote control with SAT key. -
Page 15: Parameters
Multivision Parameters Necessary adjustments in Multivision system are only 2. Modulator output channel Adjustment of output level in remote receiver Modulator output channel Adjustment of output channel is made by some microswitches placed in the rear panel of Multivision. Make sure that the channel that is going to be selected is free and the one immediately lower and upper are also free. - Page 16 Parameters Multivision Frequency Position 1 Position 2 Position 3 Position 4 Position 5 Position 6 CH21 471,25 CH22 479,25 CH23 487,25 CH24 495,25 CH25 503,25 CH26 511,25 CH27 519,25 CH28 527,25 CH29 535,25 CH30 543,25 CH31 551,25 CH32 559,25 CH33 567,25 CH34 575,25...
-
Page 17: Remote Control Adjustment
Multivision Parameters Adjustment of output level in remote receiver To be sure that signals from remote control repeater arrive at their destination, infrared receiver has an amplifier built in which can adjust the level. As any other amplifier it can cause distortions in signals if level is excessive or not arrive at destination if it’s weak. -
Page 18: Usual Operating
Usual operating Multivision For the functioning of Multivision there are two possibilities: The first and most convenient: to use remote control Second is with buttons in the front panel Your remote control... … transmits necessary signals to make any combination of inputs and outputs in the Multivision through infrared signals. -
Page 19: The Remote Control
Multivision The remote control Selecting input signals... It’s very simple. Upper keypad All you have to do is to press the key of Desired input belonging to the output Lower keypad you wish to program. It’s easier than it seems to be… Upper keypad indicates output SCART (R7) And lower keypad output modulator (R9). -
Page 20: Front Buttons
Buttons on the front Multivision First you have to select wich output is going to be programmed with key F9 (AV/RF): LED lights in red if output is selected by SCART, if it is pressed color will change into green and output will be programmed by modulator, selection is sequential RED = SCART output GREEN = Modulator output Once output to be programmed is selected, press desired input between F4 and... -
Page 21: If Something Doesn't Work
Multivision Self-help If something does not work..before calling technical service... Here are possible solutions to common problems and easy solution. Which is the problem? Possible solution Usually equipments are in small spaces and failures in connectors when moved can be caused.
