Legend LDVD5.1A User Manual

Dvd/divx player
Hide thumbs

Advertisement

Quick Links

Download this manual
LDVD5.1A
USER'S MANUAL
DVD/DIVX PLAYER

Advertisement

loading
Need help?

Need help?

Do you have a question about the LDVD5.1A and is the answer not in the manual?

Questions and answers

Summary of Contents for Legend LDVD5.1A

  • Page 1 LDVD5.1A USER'S MANUAL DVD/DIVX PLAYER...
  • Page 3 The important safety instruction shall include where applicable, the following information and warnings. 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings.

  • Page 4: Power Line

    The lightning flash with arrow head symbol within an equilateral triangle is intented to alert the user to the presence of uninsured "dangerous voltage" within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 5: Damage Requiring Service

    DAMAGE REQUIRING SERVICE Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following condition: a) When the power-supply cord or plug is damaged. b) If liquid has been spilled or objects have fallen into the produc c) If the product has been exposed to rain or water.

  • Page 6: Water And Moisture

    WATER AND MOISTURE Do not use this product near water for example. Near a bathtub, Wash bowl, Kitchen sink or laundry tub. In a wet basement or near a swimming pool and the like. ACCESSORIES Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may tail, causing serious injury to a child or adult and serious damage to the product.
  • Page 8 Please carefully check if all these following attachments are all ready after opening the gift box. If not, please consult with agency or retailer.
  • Page 9 DVD player is an advanced appliance for home entertainment and learning. Its various indicators are far superior to any other video playing devices. Its output video is sharp and real. It can provide Dolby Digital (5.1 channel) sound with high fidelity, surround effect . The player can play many different formats of discs, such as DVD, super VCD, DVCD, CD, MP3.
  • Page 10 Progressive SCAN D I G I T A L LDVD5.1A POWER SURROUND LISTED AUDIO/VIDEO FDA/DHHS APPARATUS VIDEO VIDEO MODEL LDVD5.1A ~90-240V POWER 90-240V~ 50/60Hz CLASS 1 LASER PRODUCT 50/60Hz APPAREIL A LASER DE CLASS 1 LOSS PRODUCT TO LASER CLASS 1...
  • Page 12 Once your DVD player is connected with your TV and the power supply plugs of various devices have been plugged into the power sockets, and the batteries have already been inserted into the remote control, you are ready to operate the DVD player. Turn on the power supply to the TV.
  • Page 13 1. Press OPEN/CLOSE button, The playback will end. Wait for the tray to eject and take out the disc. 2. Press OPEN/CLOSE button to close the tray. 3. Press POWER button to turn off the power supply to the player. Notes: (1) If the screen is not full or the edges are covered or there is black and white image during the playback, please make the system setup by selecting the relevant TV signal...
  • Page 14 With DVD, press MENU button to call the list of tracks on the disc, then you can press UP, DOWN button to select the tracks, then press ENTER button to play. With non DVD discs, when PBC is on, press PLAY button, the list of tracks will appear, then you can input the track number directly to play.
  • Page 15 2. Press the number button to input the track or chapter codes. For example, if an user would like to play chapter 5 on the disc, then play chapter 4 finally chapter 2 , just press the number buttons "5"and "4" and "2", (you can press "CLEAR" button to cancel the number input).
  • Page 16 Press SETUP button, the screen will display the following system setup menu. At this time press UP, DOWN button to move the blue band to the specified menu, press ENTER button to show the submenu. In the submenu, you can press RIGHT button to enter a submenu on the right hand corner on the screen.
  • Page 17 2. Press RIGHT button to enter the submenu on the right hand corner of the screen. If you would like to setup the SCR SAVER to be OFF, press the button to locate the blue band on OFF, then press ENTER button. 3.
  • Page 18 Step 1: To turn off mixed output mode (if the mode has been turned off, the step can be ignored). The operations are as follows: 1. Press SETUP button so that the system setup menu appears on the TV screen. Press DOWN button to move the blue band to SPEAKER SETUP and press ENTER button with the following pictures apear on the TV screen.
  • Page 19 3. Press RIGHT button to enter the submenu on the right hand corner of the screen. Make sure the blue locates the ON, then press ENTER button. 4. Press LEFT button to exit the submenu on the right hand corner of the screen. Press DOWN button to allow the blue band to locate REAR, press RIGHT button to enter the submenu on the right hand corner of the screen.

  • Page 20: Fast Forward Button

    Listed in this chapter are the functions of the remote control buttons and their methods of operations so that the user can refer to them for reference. Please refer to the relevant sections in chapter 4 and 5 for the detailed operations of most buttons. 11.1 PLAY/PAUSE button When the player is in the state of stop, pause, slow motion, fast forward, fast reverse, pressing PLAY button can resume the player to normal playback.
  • Page 21 11.13 REPEAT button When playing a DVD disc, pressing the button once will repeat the current chapter when it ends; pressing REPEAT a second time will repeat the content under the current title; pressing REPEAT a third time will cancel the repeat play function. 11.14 ZOOM button During playback, pressing the button can zoom out the image, pressing it once enlarges the image by two times, pressing it twice can enlarge the image by four times, pressing it...
  • Page 22 Title: The longest section of a picture, a music piece or a movie on a DVD. Each title is assigned a title number enabling you to locate the l\title you want. Track: The sections of a picture or a music piece on a VCD or CD, each track is assigned a track number enabling you to locate the track you want.
  • Page 24 www.legenddigital.com...
