External Features
This section describes the external features of your 1-Port USB Print Server.
Front View
Power
LED
There are three green LED indicators on the front panel:
LEDs
PW
LAN
USB
Component
USB Port
Steady light confirms that the Print Server is powered
on.
Steady light confirms that the print server has a good
connection to your network.
When it blinks (briefly dark), the print server is
receiving/ transmitting data from/to the network.
Steady blinking (briefly dark) is initiated when the
printer is printing, otherwise, it remains dark.
The USB port allows you connecting the print server
to a printer with USB connector.
- 8 -
LAN LED
USB LED
Description
Description
