USER MANUAL
Table of Contents
Main Control Menu.......................................................................................................... 6
Fixture Addressing.......................................................................................................... 6
Manual Mode......................................................................................................................7
Save Scene ........................................................................................................................7
Save Chase ........................................................................................................................7
Insert Step in Chase.........................................................................................................7
Delete Step in Chasse.....................................................................................................7
Run a Chase.........................................................................................................................8
USB Function......................................................................................................................7
Cleaning & Maintenance................................................................................................9
Parts List.............................................................................................................................. 9
. 3
.. 4
.. 5
...
...... 5
.8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mega Lite MC2010-Q-Loader
Summary of Contents for Mega Lite MC2010-Q-Loader
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information Specifications .. 4 Main Power Connection .. 5 DMX-512 Connection ..5 Main Control Menu......................6 Fixture Addressing......................6 Manual Mode........................7 Save Scene ........................7 Save Chase ........................7 Insert Step in Chase......................7 Delete Step in Chasse.....................7 Run a Chase.........................8 Strobe Function USB Function........................7... -
Page 3: Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Replace power supply only with the specified type and rating. 2. Do Not install the unit to close to a heat source. 3. Make sure cable are properly secured away from unit. 4. -
Page 4: Specifications
Specifications Part Numbers Fixture MC2010-Q-Loader Mechanical Specifications DMX Channels: RDM: Control the DMX Addresses of the fixture Chases: 16 Chases Fixtures: 16 Fixtures 10 Channels each Chase Control: Chase can run by Manual, Sound and Auto mode: 11.12 USB: Data backup and system update: Support... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 100V or 240V automatically Replace power supply only with the specified type and rating. The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz Cable (USA) Cable (EU) -
Page 6: Main Control Menu
Main Control Menu The control comes pre-loaded with a program to be used with standard 3 channel RGB LED lighting fixtures. Other programs www.mega-lite.com/prolight/dmxcont/qloader are available and can be loaded via our website at You can also create your own programs by using the programming section of the manual. 10 11 12 13 10: Del/Clr 1: Fixture button 1-16... -
Page 7: Manual Mode
Manual Mode Using Faders Select the desired fixture or fixtures from 1 to 16 adjust the faders to represent the desired look if the fixtures has more than 5 faders in the profile press Page B to activate faders 6 to 10 Using Presets Select the desired fixture or fixtures from 1 to16 select the desired color from the scenes or chase from the Chase options... -
Page 8: Run A Chase
Run a Chase Up to 16 scenes can be opened at the same time. Press the corresponding scene button to turn On, and again to turn Off. Auto Mode 1. Press a desired Chase button 2. Press the Run Mode button until the Auto mode indicator light is on. 3. -
Page 9: Cleaning & Maintenance
Load Show from USB 1. Insert USB flash drive 2. Press and hold the Run Mode and the button at the same time until display reads Load. 3. Press the Fixture button 1-16 as the show you want to load. Note: If green indicator light is on there is an existing file in the USB. -
Page 10: Warranty Information
Warranty Information Limited Warranty Unless otherwise stated, your product is covered by a one year parts and labor limited warranty. Dichroic filters and glass gobos are not guaranteed against breakage or scratches to coating. It is the owner s responsibility to furnish receipts or invoices for verification of purchase, date, and dealer or distributor.
