Page 1: Installation Instructions
BOL5 Model Installation Instructions Owner’s Manual READ THIS MANUAL CAREFULLY BEFORE BEGINNING INSTALLATION Installer: Permanently attach manual to the wall. - Page 2 Connect the power cord to a properly grounded outlet only. Do not in any way alter or remove the grounding pin. Photo Eye System must be installed properly. Boss Operators recommend Photo Eye System is installed on every garage door for your added protection. Opening doors must not close and Closing doors must open. See test procedure page 13 and page 16.
-
Page 3: Product Features
Product Features Motor: Permanently Lubricated, thermally protected, heavy duty motor with Automatic reset. Opener Lights: Turn on and off automatically with 2.5 minutes illumination for your safety and convenience. Sensing System: A built-in sensing system detects obstructions during door operation. If in the Downward (close) travel mode, the Opener will sense an obstruction and reverse to the full open position. - Page 4 Door Test Before beginning installation of the operator please complete the following test to insure that your door is balanced and in good working condition. A poorly balanced door could cause severe personal injury and damage to the opener. Always have a qualified garage door service person make any needed adjustments and/or repairs to your door before proceeding with installation.
- Page 5 Components Identification and Inventory (01) Power Head (02) Header Bracket (03) Door Bracket (04) Door Arm: Straight (05) Door Arm: Curved (06) Warning Label (07) Rail Assembly (08) Trolley Fastener (parts in screw bag) Identification (01) Hex Bolt 5/16”18x1 (4pcs) (02) Lag Screw #12x1”...
- Page 6 Assembly 01 STEP 1. Remove packing materials. STEP 2. Insert trolley (see fig.2). STEP 3. 2 . 1/4” -20Hex Flange Nuts (4) Connect rail to power head. Align rail and power head and slide rail over drive shaft & retaining lugs. Fasten with 4 nuts.
- Page 7 Assembly 02 STEP 5. Header Wall Install head bracket. The height is seen in fig.5 Head bracket position is higher than header wall and mark the horizontal line. Track The minimum headroom clearance is 15cm. 5cm Clearance High Point of Door Door Travel Support...
- Page 8 Assembly 03 STEP 9. Open the door to the full open position. Allow 5cm of space between the rail and the door" 5cm Clearance Full Open STEP 10. Assemble track to fix the opener (perforated steel angle and hex head machine bolts not supplied) Perforated Steel Angel (Not Sup- plied)
- Page 9 Assembly 04 STEP 13. Trolley Mount trolley to curved arm and fix it with clevis pin short and hitch pin. (Please note that at this point the Trolley should be in the rail. The purpose of this diagram is only act as a visual aid) Hitch Pin Clevis Pin Short...
- Page 10 Assembly 05 STEP 17.(OPTIONAL) Put signal wires through the hole on the up right side." STEP 18.(OPTIONAL) Pull out the signal wires from hole of the front side"...
-
Page 11: Down Limit
Adjustment 01 Antenna Photo Eye Setting Wicket Door Auto Close Timer Photo eye +24v Wall Box Common Flashlight Push Button DOWN FORCE DOWN LIMIT ***Auto Close Timer function only works when Photo Eye System is installed. Please refer to instructions included with the Photo Eye System.***... - Page 12 Adjustment 02 Identification of icons and their functions Door at close Door at open position" position" Push Button Transmitter Unplug Plug At full speed Half speed in (open / close) Program mode (open / close) Inch movement Memory is empty Light off Light on (LED / the bulb)"...
- Page 13 Adjustment 03 STEP1. Door should be in closed position. On first startup memory is blank (limits are not pre set) STEP7. At required limit position. Press limit button. OK light flashes & LED goes out. “Up” limit setting complete. STEP2. Plug in.
- Page 14 Adjustment 04 STEP13. STEP11. Press any button on transmitter. OK LED blinks once and beeps twice. Transmitter is now set. BEEP$2"" Force mode (auto learning of sensitivity): When in this mode door will travel up at full speed and stop at up limit for 2 seconds. " ""...
-
Page 15: Testing The Safety Reverse System
Testing the Safety Reverse System Warning: Failure to Test Reversing System Could Result in Death or Serious Injury. Test This System Once A Month. To test the Opener Reversing Feature at floor level place a solid object 5cm thick on the ground so that the center of the door will come into contact with it. -
Page 16: Final Installation
9. On doors with extension type springs, safety restraint cables have been installed through the springs. 10. There is surge protection on the power line to the opener. ***Boss Operators recommend photo eyes to be installed on all garage doors for added safety*** Coach Screws are supplied with the door for fitting to timber. -
Page 17: After The Installation
After the Installation 1. Never permit children to play with or operate the garage door opener either from the wall station or the remote controls. Keep radio transmitter locked in the car. Misuse of the push button or transmitter could result in serious injury or even death. -
Page 18: Manual Setting
Manual Setting Setting the Force Manually (FOR INSTALLERS ONLY) STEP1. Press “FORCE” button. Up LED is on. You are now in “FORCE UP” setting mode. "" To enter “FORCE DOWN” setting mode press “FORCE” again within 5 seconds. STEP2. To change the force setting. To increase or decrease one increment press up or down button once. - Page 19 Rail and Hardware Parts List A-11 A-10 A-12 Housing Assembly Dome Cover Light Socket Energy Saving Bulb Motor Programming Board Programming Board Cover RPM Reader Transformer A-10 Chassis A-11 Power Cord A-12 Carriage Bolt/Nut...
- Page 20 Rail and Hardware Parts List B-20 B-14 B-10 B-18 B-23 B-22 B-19 B-21 B-12 B-17 B-13 B-16 B-11 B-15 Motor Shaft Adaptor Bearings Drive Shaft Retainer Drive Sprocket Assembly Head End Bracket Curved Door Arm Sprocket Brace Straight Door Arm Rail B-10 Trolley Plate B-11 Emergency Pull-Cord w/ Knob...
-
Page 21: Warranty
The manufacturer reserves the right to modify any existing or future products without incurring any obligation to in corporate such modification to products already manufactured or to which this Warranty may relate. Warranty only applies if this product has been installed to the Manufacturers recommendation ( in the opinion of Boss Garage Door Operators). - Page 22 Date: Description: Authorized Customer’s Personnel: Signature: (Installation, maintenance, service)
-
Page 23: Service Log Book
Authorized Dealer: (name, address, telephone number) SERVICE LOG BOOK This log book contains technical references and records of installation, maintenance, repairs, and alterations carried out and must be made available for inspection by authorized bodies. Customer: (Name, address, and reference person ) Description of the door: (Model, type) f i t...
