Steelmaster SS350 Operator's Manual

350mm dry metal cutting saw (240v)

Advertisement

Quick Links

STEELMASTER
®
Model
SS350
350mm Dry Metal Cutting Saw
OPERATOR'S MANUAL
WARNING!
,
.
TO REDUCE THE RISK OF INJURY
USER MUST READ AND UNDERSTAND INSTRUCTION MANUAL
EYE PROTECTION
HEARING PROTECTION
NEVER PLACE
LINE VOLTAGE
REQUIRED
REQUIRED
FINGERS NEAR
PRESENT
CUTTING AREA.
BEWARE OF
ROTATING
MACHINE PARTS
MODEL SS350 (240V)
S
r e
a i
# l
D
a
e t
f o
P
r u
h c
a
e s

Advertisement

loading
Need help?

Need help?

Do you have a question about the SS350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Steelmaster SS350

  • Page 1 350mm Dry Metal Cutting Saw OPERATOR’S MANUAL WARNING! TO REDUCE THE RISK OF INJURY USER MUST READ AND UNDERSTAND INSTRUCTION MANUAL EYE PROTECTION HEARING PROTECTION NEVER PLACE LINE VOLTAGE REQUIRED REQUIRED FINGERS NEAR PRESENT CUTTING AREA. BEWARE OF ROTATING MACHINE PARTS MODEL SS350 (240V)
  • Page 2: Table Of Contents

    350mm Dry Metal Cutting Saw Congratulations on your purchase of your SteelMaster brand Dry Metal Cutting Saw. TABLE OF CONTENTS L i m i t e d Wa r r a n t y ....... 2 G e n e r a l S a f e t y R u l e s a n d S p e c i f i c I n s t r u c t i o n s .
  • Page 3 only 15 amp extension cord not exceeding 15 Metres. 15 amp extension cord not exceeding 15 Metres.
  • Page 4 ������� ������ ����� ����������� ��������������� ������������������������������������������������������������������������������������������������������� � �������������������������������������������������������������������� � �������������������������������������� �������������������������������������������������� ��������������������������������������������������������������������������������������������������������������� � ����������������������� ������������������������������������������������������������������� ������������������������������������������������������������������� ����������������������������������������� � ���������������������������������������������������������������������� ������������������������������������������������������������ ��� ������������������������������������������� � �������������������������������������������������������� ��������������������������������������������������������������� ����������������������������������������� � ��������������������������������������������� ������������������������������������������������� ������������������������������������������������������� � ��������������������������������������������������� � ���������������� ������������������������������������������������������������������������������������������ �������������� � ������������������������������������������������������������������������������ ������������������������������������������������������������� ����������������������������������������������������� �...
  • Page 6 SPECIFIC SAFETY RULES (continued) - DANGER! — Keep hands and body away from and to the side of the blade. Contact with blade will result in serious injury. - WARNING! — To reduce the risk of injury, check lower guard. It must close instantly! Keep free hand away from blade at all times during operation.
  • Page 7 SPECIFIC SAFETY RULES (continued) C A U S E S A N D O P E R AT O R P R E V E N T I O N O F K I C K B A C K Kickback is a sudden reaction to a pinched, bound or misaligned saw blade, causing an uncontrolled workpiece to lift up and out of the saw toward the operator.
  • Page 8: Functional Drawings

    FUNCTIONAL DRAWINGS Caution! Always unplug saw before changing blades, servicing or adjusting saw. Swivel Guard IGHT Blade Guard Auxiliary Trigger Switch and Handle Lock Vise Wheel Handle Cast Iron Base Blade Drive Chip Collector Tray Mounting Bolt Blade Lock Carbon Brushes (Inside Cover) Metal Cutting Saw Blade...
  • Page 9: Exploded View

    EXPLODED VIEW...
  • Page 10: Part S L I S

    PARTS LIST . y t . y t SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/0 SS350/...
  • Page 11 ASSEMBLY Your SteelMaster® brand saw is shipped complete and protected inside its shipping box. Remove all contents from the box and inspect to ensure no damage was incurred during shipping. Your 350 Metal Cutter package should also include the following:...
  • Page 12: O P E R A T I O

    OPERATION WHAT YOU SHOULD KNOW BEFORE SAWING WARNING! NEVER START THE SAW WITH CUTTING EDGE OF SAW BLADE CONTACTING WORK SURFACE # 115 DO NOT RETRACT BLADE GUARD ITEM MANUALLY GUARD RETRACTS AUTOMATICALLY 65,66, 154 ALWAYS CHECK BLADE DOWN STOP BOLT LOCK NUT AND BOLT CAP ITEM FOR CORRECT...
  • Page 13 OPERATION (continued) FOR BEST PERFORMANCE, EMPTY THE CHIP COLLECTOR BOX OFTEN. EMPTYING THE CHIP COLLECTOR BOX WARNING! ALWAYS DISCONNECT THE SAW FROM POWER SOURCE BEFORE CHANGING BLADES CLEARING CHIPS OR MAKING ADJUSTMENTS 1. Turn the Chip Collector Box retaining thumbscrew (see below). 2.
  • Page 14 MAINTENANCE WARNING! ALWAYS DISCONNECT THE SAW FROM POWER SOURCE BEFORE CHANGING BLADES CLEARING CHIPS OR MAKING ADJUSTMENTS CHANGING SAW BLADES Swivel Guard Refer to the diagram to the right. 1. Place saw on a level, secure surface. 2. Move the swivel guard (item #130) by loosening the thumb screw (item #134) and rotating it to expose the blade retaining bolt.
  • Page 15: Tr O U B L E S H O O T I N G C H E C K L I S

    TROUBLESHOOTING CHECKLIST 350mm METAL CUTTING SAW CAUTION! ALWAYS DISCONNECT THE SAW FROM POWER SOURCE BEFORE TROUBLESHOOTING SERVICE WORK SHOULD ONLY BE PERFORMED BY A SERVICE TECHNICIAN QUALIFIED & COMPETANT TO PERFORM SUCH TASKS 1. Machine will not turn on Inspect power cord for damage. Check & replace if needed.* •...
  • Page 16: S P E C I F I C A T I O N

    For cutting mild steel to 25.4mm SSBL350-MS For cutting thin steel to 6mm SSBL350-TS For cutting aluminum to 25.4mm SSBL350-AL For cutting stainless steel to 13mm SSBL350-SS YOUR STEELMASTER DISTRIBUTOR Industrial Tool & Machinery Sales email: sales@industrialtool.com.au / web www.industrialtool.com.au ©1/08...
