Summary of Contents for Patterson RC
- Page 1 OPERATION & MAINTENANCE MANUAL VIL VERTICAL INLINE PUMPS Types RC, CC, and CS PATTERSON PUMP COMPANY A SUBSIDIARY OF THE GORMAN-RUPP COMPANY PO Box 790 9201 Ayersville Road Toccoa, Georgia 30577 Telephone: 706-886-2101 Fax: 706-886-0023...
- Page 2 SAFETY PRECAUTIONS WARNING Do not operate this equipment in excess of its rated speed or other than in accordance with the instructions contained in this manual. The equipment has been found satisfactory of the conditions for which it was sold, but its operation in excess of these conditions may subject it to stresses and strains which it was not designed to withstand.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION I: General Information ................1 SECTION II: Storage & Protection................1 SECTION III: Installation 3-1 Location....................2 3-2 Mounting ....................2 3-3 Piping ....................2 3-4 Wiring and Controls................2 SECTION IV: Operation 4-1 Starting....................2 4-2 Shutdown ...................3 SECTION V: Maintenance....................4 SECTION VI: Repairs &... -
Page 4: Section I
SECTION I GENERAL INFORMATION This manual covers the installation, operation and maintenance of Patterson Pump vertical inline pumps. The pump is a centrifugal, single stage close-coupled type. When properly installed and when given reasonable care and maintenance, centrifugal pumps should operate satisfactorily for a long period of time. -
Page 5: Installation
SECTION III INSTALLATION Location: Several factors should be considered when selecting a location for the pumping. The unit should be accessible for both inspection and maintenance. Headroom should be provided for the use of crane, hoist or other necessary lifting devices. The pump should be located as close as possible to the liquid supply so that the suction line is short and direct. -
Page 6: Shutdown
If the pump operates on a suction lift and no foot valve is provided, use a vacuum pump or ejector operated by air, steam, water, etc. to evacuate air from the pump case and suction line by connecting the ejector to the priming connection on top of the pump case. -
Page 7: Maintenance
Mechanical seal (should be no leakage) Drain lines are working properly Co up li ng inte gr i ty (T yp e RC on l y) Operate the pump Ad d gre ase to mo to r an ti- fr ic tion b ear in gs Refer to motor manufacturer s instructions. -
Page 8: Repairs & Replacement
Mechanical seal (65) may now be removed. Type RC - To Remove Mechanical Seal 1. Remove bolting holding rigid coupling (314) to motor shaft (10) and pump shaft (6). 2. Remove bolting holding gland (17) to volute cover (11). -
Page 9: Inspection
Clean all metal parts with a solvent. Use a bristle brush (not metal or wire) to remove tightly adhering deposits. A fiber scraper may be used to remove the gasket and shellac from casing flange. Blow dry with clean dry compressed air. CAUTION: Never use hydrocarbon liquids (oil or solvent) to clean mechanical seal parts Use of oil or solvent... -
Page 10: Locating Operation Difficulties
LOCATING OPERATING DIFFICULTIES In the majority of cases, operating difficulties are external to the pump and the following causes should be carefully investigated before undertaking repairs: No Water Delivered Pump not primed indicated by no pressure on discharge. Speed too low indicated by low pressure on discharge. - Page 11 Pump Overloads Driver Speed too high. Head lower than rated, hence, pumping too much water. (This is valid for low specific speed pumps). Mechanical defects: stuffing boxes too tight, shaft bent, rotating element binds. Rubbing due to foreign matter in the pump between the case rings and the impeller. Pump Vibrates Misalignment.
-
Page 12: Recommended Spare Parts
RECOMMENDED SPARE PARTS FOR VIL PUMPS, Types RC, CC, and CS Reference: Assembly Section for the Pump Type INTERMITTENT DUTY Number Description Casing Ring Shaft Sleeve (Type CC only) Mechanical Seal Gasket (casing) CONTINUOUS DUTY Number Description Impeller Shaft (Types RC and CS only) -
Page 16: Notes
Notes...
