CountyLine L213-335001 Owner's Manual

CountyLine L213-335001 Owner's Manual

Wheeled string trimmer

Advertisement

OWNER'S
MANUAL
TSC SKU#
1039311
Vendor#
ST67522BS-TSC
Starting Serial Number
L213-335001
IMPORTANT
Read and follow all Safety
Precautions and Instructions before
operating this equipment.
19133 REV 13-335
Assembly
Operation
Service and Adjustment
Repair Parts
Distributed by: TRACTOR SUPPLY COMPANY
Wheeled
String Trimmer
200 POWELL PLACE
BRENTWOOD, TN 37027
Made In The
USA
www.Tractor Supply.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L213-335001 and is the answer not in the manual?

Questions and answers

Summary of Contents for CountyLine L213-335001

  • Page 1 OWNER’S Wheeled MANUAL String Trimmer TSC SKU# 1039311 Vendor# ST67522BS-TSC Starting Serial Number L213-335001 IMPORTANT Read and follow all Safety Precautions and Instructions before operating this equipment. 19133 REV 13-335 Assembly Operation Made In The Service and Adjustment Repair Parts...
  • Page 2: Limited Warranty

    LIMITED WARRANTY The manufacturer’s warranty to the original consumer purchaser is: This product is free from defects in materials and workmanship for a period of two (2) years from the date of purchase by the original consumer purchaser. We will repair or replace, at our discretion, parts found to be defective due to materials or workmanship.
  • Page 3: Safety Instructions

    Safety Instructions This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. • Read, understand and follow all instructions in the manual and on the trimmer before starting.
  • Page 4: Slope Operation

    Slope Operation Slopes are a major factor related to loss of control and slip accidents, which can result in severe injury. All slopes require extra caution. If you feel uneasy on it do not trim it. • DO: Trim across the face of a slope and not up and down. •...
  • Page 5 The operation of any mower can encounter foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine. The operation of any mower produces sound waves that are damaging to the human ear.
  • Page 6: Handle Adjustment

    Assembly Contents of Box: • Trimmer Parts bag containing: • Manual • Engine manual • Safety goggles • Bottle of engine oil • Trimmer Line • Cable Clip Tools Required: • ½” wrench Installation of handles: • Remove loose fasteners from lower handles. •...
  • Page 7: Operation

    Preparing Unit For First Use • Fill engine crankcase with oil. A 20oz. bottle has been provided with this unit. A new unit requires 18-20oz. DO NOT OVERFILL. • Fill the engine fuel tank with gasoline. GASOLINE SHOULD BE ADDED OUTSIDE IN A WELL-VENTILATED AREA.
  • Page 8 Installing Trimmer Line Important! Use the proper length of line. Using a line too long for the unit will cause stalling and unacceptable operation. Use 18” Trimmer Line Part Number P3618CL • Loosely fold trimmer line in half. • (1) Place loop of line against outside of loop on the trimmer head. •...
  • Page 9 Trimmer Maintenance Make sure your trimmer is in safe working condition by keeping the following guidelines in mind every time you use your trimmer. • Keep trimmer in good operating condition and keep all guards and shields in place. DO NOT operate this trimmer if any of the shields and guards are missing.
  • Page 10: Assembly

    Assembly See Page 11 Item # Part # Description Item # Part # Description Engine - Briggs & Stratton 10397 Handle - Bail NB253 Bolt - Serr Flange, 5/16-18 X1 1/4ZY Gr5 10578* Handle - String Trimmer, Upper NB170 Nut - Serr Flange 5/16-18 ZY Case Hrd NB587 Bolt - Carriage, 5/16-18 X 1 3/4 ZY Gr 2 2063 Pulley - Engine;...
  • Page 11: Trimmer Head Assembly

    Trimmer Head Assembly Item # Part # Description NB595 Nut - Lock Jam, 5/8-11 2 Way Grade A 2049 Pulley - Blade, 4.5" NB149 Washer - 5/8 ID X 1 OD 14 GA ZY B985/8 Bearing - Trimmer 19110* Weldment - Trimmer Neck 18846 Shaft - Trimmer NB586...
  • Page 12 Each trimmer has its own model number. Each engine has its OWNER’S own model number. The model number for the trimmer will be found on the left hand side of the motor base. The model MANUAL number for the engine will be found on the top of the blower fan housing.
