SunGrabber
- SOLAR POOL HEATER -
INSTALLATION AND OPERATION MANUAL
How Does the SunGrabber
TM
Why is SunGrabber
TM
Your Best Choice?.....................................
What's Needed to Install Your SunGrabber
TM
...............................................
Heating Your Pool.............................................................
ATTENTION: THIS MANUAL PROVIDES A DETAILED STEP-BY-STEP PROCEDURE FOR THE INSTALLATION OF THE SUNGRABBER
POOL HEATING SYSTEM. THE DIRECTIONS SHOULD BE FOLLOWED PROPERLY AND ONLY RECOMMENDED SUNGRABBER
AND HARDWARE SHOULD BE USED IN ORDER TO PROVIDE A TROUBLE FREE SYSTEM. READ THIS MANUAL COMPLETELY BEFORE
STARTING. IF YOU HAVE ANY INSTALLATION PROBLEMS OR QUESTIONS, CONSULT YOUR LOCAL SUNGRABBER
CONFORM TO LOCAL BUILDING CODES.
CAUTION: SOLAR COLLECTORS ARE OFTEN INSTALLED ON THE ROOF OF BUILDINGS OR RESIDENTIAL HOMES. UNLESS YOU ARE
FAMILIAR WITH WORKING ON ROOFS AND HAVE THE PROPER LADDERS AND SAFETY EQUIPMENT FOR SUCH WORK, YOU SHOULD HIRE
SOMEONE WITH THE NECESSARY EXPERIENCE TO DO THE INSTALLATION. FAILURE TO OBSERVE SAFE PRACTICES ON A ROOF OR OTHER
ELEVATED STRUCTURE MAY RESULT IN FALLING, LEADING TO SERIOUS INJURY. WHEN INSTALLING COLLECTORS ON THE GROUND, DO
NOT BUILD A RACK SUPPORT THAT CAN ALLOW CHILDREN TO ACCESS THE POOL.
IN-GROUND
TABLE OF CONTENTS
System Work?...............................
TM
..........................
Page 2
Page 2
Troubleshooting.........................................
Page 3 & 4
Frequently Asked Questions........................
Page 4-7
Customer Support.....................................
Page 8
Warranty..................................................
TM
TM
....................
Page 8
Page 8
Page 9
Page 9
Page 9
TM
SOLAR
TM
COMPONENTS
DEALER. ALWAYS
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sungrabber IN-GROUND
Summary of Contents for Sungrabber IN-GROUND
- Page 1 Heating Your Pool………….……………………………………...… Page 8 Warranty……………………..…………………... Page 9 ATTENTION: THIS MANUAL PROVIDES A DETAILED STEP-BY-STEP PROCEDURE FOR THE INSTALLATION OF THE SUNGRABBER SOLAR POOL HEATING SYSTEM. THE DIRECTIONS SHOULD BE FOLLOWED PROPERLY AND ONLY RECOMMENDED SUNGRABBER COMPONENTS AND HARDWARE SHOULD BE USED IN ORDER TO PROVIDE A TROUBLE FREE SYSTEM. READ THIS MANUAL COMPLETELY BEFORE STARTING.
- Page 2 30 years ago, and today takes great pride in being the largest and oldest manufacturer in the world. Backed by the longest and best warranty in the industry, your SunGrabber is state-of-the-art in solar pool heating technology, and will provide years of FREE HEAT for your pool! In fact, when sized and installed correctly, a SunGrabber can raise your pool temperatures up by 10°F, and extend your swimming season.
- Page 3 Box Contents Item Quantity Description Item Quantity Description 2’ x 20’ in-ground solar panel 2’ x 20’ in-ground solar panel 36” mounting straps 60” mounting straps 2” x 1/4” mounting screws 2” x 1/4” mounting screws 1 1/2” rubber coupler 1 1/2”...
- Page 4 1 additional per system) P/N 261-2 Panel Add-on Kit P/N 262 Panel Repair Kit For more information on accessories, please contact your nearest SunGrabber dealer or visit us on the web at www.sungrabber.com INSTALLING YOUR SUNGRABBER The ideal location for your SunGrabber...
- Page 5 INSTALLING YOUR SUNGRABBER (CONTINUED) HORIZONTAL INSTALLATION ON SHINGLE ROOF [P/N’S 260-1, 260-2, 260-5, 260-6] CAUTION: VERTICAL INSTALLATION OF THESE MODELS WILL VOID THE WARRANTY 1. Determine the location of your panel(s). Lay out your system so that it declines slightly (a minimum of 1/4 inch of fall every 10 feet) toward the bottom corner of the panel that feeds from your pool equipment.
- Page 6 INSTALLING YOUR SUNGRABBER (CONTINUED) VERTICAL INSTALLATION ON SHINGLE ROOF [P/N 270-2, 272-2, 280-2, 280-3] ATTENTION: HORIZONTAL INSTALLATION OF THESE MODELS IS ACCEPTABLE 1. Determine the location of your panel(s). Lay out your system so that it declines slightly (a minimum of 1/4 inch of fall every 10 feet) toward the bottom corner of the panel that feeds from your pool equipment.
- Page 7 INSTALLING YOUR SUNGRABBER (CONTINUED) REQUIREMENTS FOR ROOF TYPES OTHER THAN SHINGLE ROOF (CONTINUED) Cedar Shake Roofs: If the cedar shakes are installed on top of a plywood surface, use a galvanized metal flashing (approximately 4” x 4”) under each shake where the mounting screw will penetrate. Center the flashing under the penetration location before installing the screw.
-
Page 8: Troubleshooting
Turn by-pass valve and pool pump off, and allow 30 to 40 minutes for drainage. Undo the isolation valves, remove the VRV, and allow the system to drain. Reattach your VRV. SunGrabber panels are designed to be left in place through the winter months as long as they are drained. - Page 9 Question: I left my solar panel full of water through the winter and now some of the tubes are leaking. Can it be repaired? Answer: Yes it can. You will need to order our “Panel Repair Kit” from your local dealer. It is very important that your SunGrabber is properly winterized each year.
- Page 10 Notes...
- Page 11 Notes...
- Page 12 SunGrabber 866-SUNGRAB • 866-786-4722 435 Otterson Drive Chico, CA 95928 www.sungrabber.com P/N 07347C 3/06...
