(section 5.0) and maintained (section 6.0) by a competent person. Please read and understand these instructions prior to installing your Cameo electric shower. Particular attention should be paid to the section headed IMPORTANT INFORMATION (section 2.0). Following installation and commissioning the operation of the heater should be explained to the user (section 6.0) and these instructions left with them for...
1.0 TECHNICAL SPECIFICATION 1.1 CONNECTIONS Inlet connection -15mm ext. diameter (copper or push fit stem elbow) Water entry point - bottom and rear Cable entry point - bottom and rear ELECTRICAL Model 240v 230v Nominal Power Rating 7.2kW 6.6kW 7.2kW 30 amp 28.75 amp MATERIALS...
2.0 IMPORTANT INFORMATION Your shower is designed and tested to the very highest standards and complies fully with all of the relevant British and European standards for safety and reliability. The shower is manufactured in an ISO 9001: 2000 -registered factory - your assurance of a quality product.
Page 5
2.11 WARNING! DO NOT USE the shower if the HOSE IS DAMAGED in any way; for instance if the outer covering has parted to reveal the inner tube. A damaged hose can suddenly restrict the flow and result in extremely hot water being emitted from the showerhead. A damaged hose could completely block the outlet of the shower;...
3.0 SITING AND PLUMBING Spend some time planning exactly where to site the shower heater and riser rail. Bear in mind the height of people who will be using it. THINGS YOU MUST DO Check that the water pressure to the shower is adequate. If in doubt, consult a competent plumber.
Page 7
highest parked position, the handset is not more than 610mm above the bottom of the heater and in its lowest position it is no lower than 305mm -see Fig. 3. If the handset can reach to within 25mm (1”) of the spillover level of the bath, shower tray, wash basin, WC or bidet, then to prevent the possibility of back-siphonage of used water (Water Regulations Guide G15.14/R15.14) you must either:...
4.0 ELECTRICAL INSTALLATION WARNING This appliance must be earthed. The installation, supply cable and circuit protection must conform to BS7671 ‘Requirements for electrical installations’ (IEE Wiring Regulations). The following notes are for guidance only: The shower heater must only be connected to a 230/240V ac supply.
Page 9
For all installation arrangements work back from the shower to the consumer unit. Before making the final connections, check the circuit for continuity and insulation resistance. 4.10 It is recommended that a residual current device (rcd), formerly known as an earth leakage circuit breaker (elcb), with a tripping current of 30mA, is incorporated in the circuit.
5.0 CONNECTING TO SERVICES PREPARATION Remove the fixing screw which holds the front cover onto the backplate of the shower heater. Carefully remove the cover. The control knob is an integral part of the cover - do not attempt to remove it see Fig.
CABLE ENTRY Cable entry can be from the rear (preferred see fig. 9) or from the bottom. The backplate has cut out positions to suit 2 sizes of cable. When opting for bottom entry make cut out to suit cable before fitting backplate to the wall - see Fig.
Page 12
PLUMBING 5.9 Decide where to connect to the water mains for your feed to the shower. Ensure that the pipe you have selected is not a gas pipe (they can look similar) or a hot water pipe or from a cold water storage tank (unless you have sufficient head - see point 3.2 &...
FITTING THE HOSE Sealing washer 5.22 Secure one end of the hose to the handset and screw the other end of the hose to the shower heater outlet. Ensure that the Handset black sealing washers are fitted. Hose ELECTRICS 5.23 Design your system as outlined Figure 15 fitting the hose on pages 6 to 10.
Page 14
5.35 Turn control knob in the cover until the indicator is between ‘START’ and ‘STOP’. 5.36 Place the cover onto the backplate. 5.37 Secure the cover to backplate using screws provided. COMMISSIONING NOTE: The first operation of the shower is intended to ensure the heater unit contains water before the unit is switched on.
6.0 USER INFORMATION 6.1 To turn on and set temperature: 1. Turn on your isolating switch. 2. Turn water control knob anticlockwise to allow water to flow until “power on” neon illuminates; the shower is then heating. WARMER - DECREASE FLOW - TURN KNOB CLOCKWISE. COOLER - INCREASE FLOW - TURN KNOB ANTICLOCKWISE.
FAULT FINDING In the unlikely event of a problem consult the trouble shooting chart below. For your particular system follow the suggested remedies in the order given. If you are unable to remedy the problem CONTACT YOUR INSTALLER IN THE FIRST INSTANCE.
Page 17
"protected" neutral bar of the unit 6. Water emerges PRD has operated 1. Switch off immediately at isolating switch from bottom of 2. Isolate water supply to shower unit the unit 3. Contact Heatrae Sadia Service Department...
7.0 SPARE PARTS The following comprehensive list of spare parts is available for your He- atrae Sadia shower. Please refer to the rating label on the side of your heater before ordering to ensure the correct spare part is obtained. DO NOT REPLACE WITH PARTS NOT RECOMENDED BY HEATRAE SADIA, AS THIS WILL INVALIDATE YOUR GUARANTEE AND MAY REN- DER THE INSTALLATION DANGEROUS.
Page 19
Regulations in force at the time of Installation, and that all necessary controls and safety valves have been fitted correctly. Any valves and controls are of the Heatrae Sadia recommended type and specification. The unit has not been modified or tampered with in any way, and has been regularly maintained as detailed in the Installation and User Instructions.
