Summary of Contents for Lemair FR-90V
- Page 1 Lemair Model FR-90V INSTRUCTION MANUAL freezer freezer...
- Page 2 Thank you for your purchase of this Freezer. This instruction manual explains the features and functions of the device. There is a troubleshooting section towards the end of the manual which should be referred to in case of any unexpected device behaviour. Guide to use the instruction book The following Symbols will be found in the text to guide you through the instructions Safety Instructions...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS These warnings are provided in the interests of your safety. Ensure that you have read and understood them all before installing or using the appliance. If you are unsure about any of these warnings, contact Customer Support for assistance. -
Page 4: Table Of Contents
TABLE OF CONTENTS For the User For the Installer Door Reversal Important Safety Instructions Description of the Appliance Installation Requirements Ventilation Requirements Levelling Using Your Appliance Before Use Thermostat Controls To Start The Appliance The Freezer Compartment Freezing Fresh Food Frozen Food Storage Hints and Tips Normal Operating Sounds... -
Page 5: Description Of The Appliance
Description of the Appliance Thermostat Control Storage Baskets door Level Adjusters Thermostat Control NORMAL SUPER... -
Page 6: Using Your Appliance
USING THE APPLIANCE This appliance is designed for Do not use detergents, abrasive domestic use only, specifically for the powders, highly perfumed cleaning storage of edible foodstuffs. products, wax poblishes or products containing alcohol. This appliance is designed to operate in ambient temperatures (surrounding air To Start the Appliance temperature) between 16 C and 32 C. -
Page 7: The Freezer Compartment
The Freezer Compartment symbol means that your freezer will Frozen Food Storage store frozen food at -18 C (-0.4 F) or colder, The appliance has the following net storage allowing for long term frozen food storage and volume: 82 litres. freezing of fresh food. -
Page 8: Hints And Tips
HINTS AND TIPS Normal Operating Sounds &Always leave warm food to cool down to &You may hear faint gurgling or bubbling room temperature before placing in the sounds when the refrigerant is pumped freezer. through the coils or tubing at the rear, to &Food which is to be frozen (when cool) the cooling plate/evaporator or the fixed should be placed in the fridge before being... -
Page 9: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal Cleaning Clean the inside and the baskets with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Wipe clean and dry thoroughly. Do not use detergents, abrasive powders, highly perfumed cleaning products, wax polishes or cleaning products containing bleach or alcohol. -
Page 10: Troubleshooting
TROUBLESHOOTING BEFORE contacting a service agent, check the following points: Symptom Solution Check that there is power at the socket. No power to the appliance Check that the fuse has not blown. Check that the ambient temperature is within the freezer's operating limits of 16 C to 32 C. -
Page 11: Door Reversal
Door Reversal This refrigerator has been built with the door hinges on the right. If you wish to change the opening direction, follow the instructions below: 1. Remove the upper hinge cover ( 6 ) first. 2. Remove the two screws (1) that hold the upper hinge (5) (right side) to the frame. Take away the upper hinge (5). -
Page 12: Installation Requirements
Installation Requirements To ensure correct operation, this appliance must not be located where the temperatures will fall below 16 or rise above 32 . Avoid the following location: unventilated kitchen, outhouse, conservatory, garage. For correct operation this appliance must be installed: In a dry location.
