- Page 1 WIPS Wireless interactive Presentation Solution (TWP-1000) User’s Manual (Model Name: TWP-1000) Version: 1.0 Date: Mar. 22, 2012 Seite 1 von 58...
-
Page 2: Table Of Contents
Table of Contents 1. Overview ..................... 4 2. Package Contents ..................5 3. USB Token Contents ................5 4. Physical Details ..................6 5. What You Might Need ................8 6. Quick Installation ..................8 7. WiPG-1000 Receiver Device ..............9 8. - Page 3 8.10.17 Exit ....................27 9. DoWiFi for Mac ..................28 Install the application ..............28 Start the application ................ 29 Quick Connect ..................29 Connect to WiFi Network ............... 29 Connect to Receiver Device ............30 Login ....................... 30 Main User Interface ................31 Screen Projection ................
- Page 4 10.5.9 Reboot System ................49 10.5.10 Logout .................... 50 Seite 4 von 58...
-
Page 5: Overview
1.Overview WIPS TWP-1000 is professional wireless presentation gateway. By enabling the Revolutionary “interactive” and “wireless” functions, you can throw your presentations wirelessly from a PC, Mac, iPad, iPhone, or Android devices to a projector! And use your pad, tab or phone to control your PC/Mac, or view the... -
Page 6: Package Contents
Web management including software download and device settings Support WiFi AP-Client Mode 2.Package Contents WIPS TWP-1000 Box WIPS TWP-1000 USB Token Power Adapter (DC +5V, 2.5A) 2 WiFi Antenna 3.USB Token Contents Windows Installer (WIPS Windows Installer) ... -
Page 7: Physical Details
PtG Converter (For MobiShow PtG function) SNMP Manager (For SNMP Management) 4.Physical Details Front Panel Power Button and LED USB Port Description Power Button and LED Power on/off button. LED Indicator: System Loading(Red), Ready(Yellow) USB Port (Front) USB port for USB mouse and keyboard Seite 7 von 58... - Page 8 Rear Panel VGA Connector Audio Jack HDMI RJ-45 Antenna USB Port Power Jack Antenna Description Antenna WiFi Antenna USB Port (Rear) USB port for USB IWB device (HID type) RJ-45 10/100M RJ-45 port VGA Connector VGA connector HDMI HDMI Connector Audio Jack Audio Jack (3.5mm) Power Jack...
-
Page 9: What You Might Need
USB Mouse and Keyboard (Optional, for remote desktop feature) USB HID IWB Device (Optional, for IWB over IP feature) 6.Quick Installation 1) Connect WIPS TWP-1000 device to Projector through VGA port and turn on projector power. Seite 9 von 58... - Page 10 3) Attach the speaker cable to TWP-1000 phone jack for audio output 4) Attach the USB mouse and keyboard to TWP-1000 front USB port for OSD control and remote desktop control 5) Attach the USB IWB cable to TWP-1000 rear USB port for IWB control 7.TWP-1000 Receiver Device...
- Page 11 3) If there is sender connected to TWP-1000 device, it will show the PC-List on standby screen, conference moderator can use the USB mouse/keyboard to select the PC and control it remotely. 4) You can also click the feature Icon to browse the Quick Guide for each feature.
- Page 12 can find the FW version, resolution and WiFi security information. Meanwhile, you can also change the Quick Guide Language (EN/SC/TC/JP/KO) here. 6) System will enter the Screen Saver mode if none is connected, it will restore to standby status immediately when there is any sender connected. Seite 12 von 58...
-
Page 13: Dowifi For Windows
TWP-1000 box through WiFi. 2) Open your browser and enter the IP address shown on the left corner of projector screen to access the WIPS TWP-1000 web home page. (Default IP: 192.168.100.10) 3) Download the client software for “Windows 7/Vista / XP” and install on your (Ps. -
Page 14: Start The Application
4) Launch WIPS client and connect to TWP-1000 receiver. (Make sure your personal firewall allows WIPS TWP-1000 software to pass through.) 8.2 Start the application 5) Click WIPS icon on desktop to execute the application, or launch the application from PnS token directly. -
Page 15: Quick Connect
1) WIPS will memorize the last successful connection profile and open the quick connect dialog, you can enter the code and press the “Connect” button to connect this TWP-1000 directly. 2) If you want to connect to another TWP-1000 receiver, please press the “Rescan” button. 8.4 Connect to WiFi Network 1) WIPS will search the available WiFi Network and list the TWP-1000 WiFi Device. -
Page 16: Connect To Receiver Device
8.5 Connect to Receiver Device 1) WIPS will search and list the TWP-1000 receiver Device. You can select the target receiver device and press the “OK” button to connect the selected receiver device. 2) You can press the “Refresh” button to search again. -
Page 17: Main User Interface
2) If you want to connect to another receiver or cancel the login, please press the “Cancel” button. 8.7Main User Interface Menu Area Status Indicator Control Area for Screen Projection Feature Seite 17 von 58... -
Page 18: Screen Projection
8.8 Screen Projection 1) Click the “Play” button for full or split screen, you can project the main screen on to the display immediately, click the “Pause” button, you can freeze you projection screen, and click the “Stop” button to stop projecting your screen. -
Page 19: Audio Projection
Project to Split #1 Project to Split #2 Project to Split #3 Project to Split #4 Stop projecting Pause projecting Enable the Windows Magnifier function 8.9 Audio Projection 1) When you are doing the full screen projection, you can also choose to project the audio to WP-1000 receiver for the multimedia or video scenario. -
Page 20: Menu
8.10 Menu 1) Press “Menu” button from the main UI, you will find the menu to enable the additional feature or to change the application options. Item Description Show Receiver Information Show Receiver Information on desktop Web Admin Open web admin page Search Receiver Search another receiver device Launch SidePad ->... -
Page 21: Show Receiver Information
About About this application Exit Exit the application 8.10.1 Show Receiver Information 1) Click “Show Receiver Information”, it will display the Receiver Information, such as WiFi Name, IP Address and code on the upper of desktop, it will close automatically after 30 seconds or you can also click on the area to close this window manually. -
Page 22: Search Receiver Device
8.10.3 Search Receiver Device 1) Click “Search Receiver Device”, it will disconnect from current receiver and search the receiver again. Seite 22 von 58... -
Page 23: Launch Sidepad -> Mirrorop Receiver
8.10.4 Launch SidePad -> MirrorOp Receiver 1) Open the main menu of the TWP-1000 application(Win/Mac), and choose the item, “Launch SidePad -> MirrorOp Receiver (SidePad)” Note: You have to download the “MirrorOp receiver” on your Android/iOS device, then connect the Android/iOS to WP-1000 device through WiFi and Launch “‘MirrorOp Receiver”. -
Page 24: Enable Browserslides
8.10.5 Enable BrowserSlides 1) Click the “Enable BrowserSlides”, it will start to broadcast your slides to the browser on connected mobile devices. Note: Audience need to connect to WP-1000 WiFi Network, open the browser and click the “BrowserSlides” button to start receiving the slides. 8.10.6 Select Projection Desktop (Win XP/Vista/7) 1) Click the “Select Projection Source”... -
Page 25: Projection Quality
8.10.7 Projection Quality 1) Click the “Projection Quality”, choose “Normal” for faster projection speed with lower screen image quality, and “Best” for clear screen image quality but slower projection speed. 8.10.8 Projection Latency Control 1) The Projection Latency Control provides the option to support “Auto” latency control and “Shortest (Application Mode)”. -
Page 26: Enable Usb Iwb Bridge
8.10.9 Enable USB IWB Bridge 1) Click the “Enable USB IWB Bridge”, it will enable the USB IWB Bridge feature. 2) When you start the full screen projection, it will bridge the IWB device to your PC wirelessly. Note: You have to install the USBoIP driver first. You can find the driver from USB token. -
Page 27: Advanced Screen Capture
8.10.10 Advanced Screen Capture 1) Click the “Advanced Screen Capture”, you will be able to see tip windows and other layered windows (include the main UI) on the connected display. However, the mouse cursor may blink from time to time when you are projecting your PC screen! Disable “Advanced Screen Capture”. -
Page 28: Send Audio To Display
8.10.11 Send Audio to Display 1) Click “Send Audio to Display” to start the audio projection feature. It will mute your local speaker during the projection and restore it when it closes the application. 2) Note: For Windows XP system, you have to install the Audio driver. (VAC.exe) You can find the driver from USB token. -
Page 29: Auto Wifi Connect
1) Click “Auto WiFi Connect” to enable the WiFi connect feature through TWP-1000 application. 8.10.14 Make WIPS TWP-1000 Token 1) Click “Make WIPS TWP-1000 Token” to make a USB WIPS TWP-1000 Token, you can insert a USB thumb drive and follows the wizard to make the Token. Seite 29 von 58... -
Page 30: Copy Application To Desktop
8.10.15 Copy Application to desktop 1) Click the “Copy Application to desktop”, it will copy the application to your desktop immediately even you don’t have the system privilege Seite 30 von 58... -
Page 31: About
8.10.16 About 1) Click “About” to show system information. It includes product model name, Client version, IP address and other information. Seite 31 von 58... -
Page 32: Exit
TWP-1000 box through WiFi. 2) Open your browser and enter the IP address shown on the left corner of projector screen to access the WIPS TWP-1000 web home page. (Default IP: 192.168.100.10) 3) Download the client software for “Mac” and install on your PC. - Page 33 4) Launch TWP-1000 client and connect to TWP-1000 receiver. Seite 33 von 58...
-
Page 34: Start The Application
1) TWP-1000 will memorize the last successful connection profile and open the quick connect dialog, you can enter the code and press the “Connect” button to connect this WP-1000 directly. 2) If you want to connect to another TWP-1000 receiver, please press the “Rescan” button. 9.4 Connect to WiFi Network 1) TWP-1000 will search the available WiFi Network and list the TWP-1000 WiFi Device. -
Page 35: Connect To Receiver Device
“Manual” button to enter the receiver IP address manually and connect. 9.6 Login 1) When it connects to a “Code” protection enabled TWP-1000 receiver, you have to enter the “Code” and press the “Connect” button to login the receiver. (You can find the CODE from the right-upper of OSD standby screen) -
Page 36: Main User Interface
2) If you want to connect to another receiver or cancel the login, please press the “Cancel” button. 9.7 Main User Interface Menu Area Status Indicator Control Area for Screen Projection Feature Seite 36 von 58... - Page 37 9.8 Screen Projection 1) Click the “Play” button for full or split screen, you can project the main screen on to the display immediately, click the “Pause” button, you can freeze you projection screen, and click the “Stop” button to stop projecting your screen.
-
Page 38: Audio Projection
9.9 Audio Projection 1) When you are doing the full screen projection, you can also choose to project the audio to TWP-1000 receiver for the multimedia or video scenario. 2) To enable or disable the audio projection feature, please change the setting from TWP-1000 menu. - Page 39 Item Description Show Receiver Information Show Receiver Information on desktop Web Admin Open web admin page Search Receiver Search another receiver device Launch SidePad -> Launch SidePad sender MirrorOp Receiver Enable BrowserSlides Enable BrowserSlides feature Projection Quality Change projection quality Projection Latency Control Change projection latency option Send Audio to Display...
-
Page 40: Show Receiver Information
9.10.1 Show Receiver Information 1) Click “Show Receiver Information”, it will display the Receiver Information, such as WiFi Name, IP Address and code. Seite 40 von 58... -
Page 41: Web Admin
9.10.2 Web Admin 1) Click “Web Admin”, it will open the browser and connect to the receiver web admin page automatically. (You can find the details of web admin page from another chapter.) 9.10.3 Search Receiver Device 1) Click “Search Receiver Device”, it will disconnect from current receiver and search the receiver again. -
Page 42: Launch Sidepad -> Mirrorop Receiver
9.10.4 Launch SidePad -> MirrorOp Receiver 1) Open the main menu of the TWP-1000 application(Win/Mac), and choose the item, “Launch SidePad -> MirrorOp Receiver (SidePad)” Note: You have to download the “MirrorOp receiver” on your Android/iOS device, then connect the Android/iOS to TWP-1000 device through WiFi and Launch “‘MirrorOp Receiver”. -
Page 43: Projection Quality
9.10.6 Projection Quality 1) Click the “Projection Quality”, choose “Normal” for faster projection speed with lower screen image quality, and “Best” for clear screen image quality but slower projection speed. 9.10.7 Projection Latency Control 1) The Projection Latency Control provides the option to support “Auto” latency control and “Shortest (Application Mode)”. -
Page 44: Send Audio To Display
USB token. 9.10.9 Auto WiFi Connect 1) Click “Auto WiFi Connect” to enable the WiFi connect feature through TWP-1000 application. 9.10.10 About 1) Click “About” to show system information. It includes product model name, Client version and other information. -
Page 45: Web Management
10. Web Management 10.1 Home Page 1) Make sure your PC connect to WIPS TWP-1000 box successfully. 2) Enter the receiver IP address on browser; you can find the IP address on the projector screen. (Default IP is 192.168.100.10) 10.2 Download 1) Select “Download”... -
Page 46: Conference Control
2) Enter password and then press [Login]. (default password: moderator) 3) After login, you can see a User List on the screen which indicates all of users connected to WIPS TWP-1000 box. 4) There are three columns, “Computer Name”, “Play Control” and “IP Address”. - Page 47 , Play Split #2 ,Play Split #3 , Play Split #4 and Stop 6) Uncheck the “Allow Control from this page only”, it will disable the centralized control and user can project the screen to TWP-1000 freely. Seite 47 von 58...
-
Page 48: Browserslides
10.4 BrowserSlides 1) Press the “BrowserSlides” button to enter the BrowserSlides page. 2) Enter the password if necessary. (Default password: Same as Code) 3) Start to receive the projecting slides. 10.5 Admin 1) Click [Admin] and then enter the password to login web admin page. (Default Password: admin) Seite 48 von 58... -
Page 49: System Status
Default Gateway：default gateway Wireless MAC address：wireless MAC address Wire MAC address：wire MAC address Connection Status: Projecting status: “Waiting for projecting” or “Projecting” Total Users: It shows how many users login to WIPS TWP-1000. Seite 49 von 58... -
Page 50: Device Setup
10.5.2 Device Setup 1) Click [Device Setup] button, it will show the device setting items, Choose <VGA> or <HDMI> output option <Resolution>: HDMI: 720p, 1080i, 1080p VGA: UXGA(1600*1200), WXGA+(1440*900), WXGA(1360*768, 1280x768, 1280x800) ,XGA(1024*768), and SVGA(800*600). The default value is XGA(1024*768). ... -
Page 51: Network Setup
TWP-1000 box is connected to a LAN that already has a DHCP server present, the WIPS TWP-1000 box takes an IP address assigned to it by the server. When the WIPS TWP-1000 box is connected to a LAN that does not have a DHCP server, the TWIPS TWP-1000 box becomes the DHCP server in the network. - Page 52 SSID Broadcast: The default value is “Enable” Channel: to set fixed channel or Auto. The “Auto” means after power on WIPS TWP-1000, it will scan all of wireless channel and select clear one channel automatically. Encryption: you can select “Disable” or one of WEP/WPA/WPA2 64bit or 128bit in ASCII or HEX string.
-
Page 53: Osd Setup
10.5.4 OSD Setup 1) Click [OSD Setup] button, you can change the standby Logo image Change Logo Image <Reset to default>: Restore to default Logo image. <Image File Upload>: Upload the customized Logo Image. Seite 53 von 58... -
Page 54: Change Passwords
10.5.5 Change Passwords 1) Click [Change Password] button, you can change the password setting. (Length: up to 8 characters) <Enter New Password>: enter new password you want to change for each category. <Confirm New Password>: Confirm the new password again. ... -
Page 55: Reset To Default
2) System Configuration Import and Export Export: Export the system configuration to a configuration file Import: Import the system configuration file to TWP-1000 3) Firmware Upgrade A. Firstly, you have to get latest firmware image file from your vendor. B. Click <Browse> to specify file name you want to upgrade. -
Page 56: Browserslides Setup
E. After a few minutes, a complete message shown on the screen. F. Restart WIPS TWP-1000 box to take effect. Warning: Don’t power off WIPS TWP-1000 while firmware upgrade in progress, otherwise will cause your Box doesn’t work and have to return device to your vendor for fixing. -
Page 57: Reboot System
Code” or “Use the following Code” 10.5.9 Reboot System 1) Click [Reboot System] button, you can restart the system <Reboot>: reboot system automatically. Seite 57 von 58... - Page 58 10.5.10 Logout 1) Click [Reboot System] button, you can logout the TWP-1000 Seite 58 von 58...
