6000 Broadcast Audio Delay
User's Guide
Revision A07, 14 November 2005
Symetrix part number: 5360000A05
Subject to change without notice.
Copyright 2002-2005, Symetrix, Inc. All rights reserved.
AirTools™ is a registered trademark of Symetrix, Inc.
All other trademarks referenced in this User's Guide are the property of their
respective holders.
Mention of third-party products is for informational purposes only and consti-
tutes neither an endorsement nor a recommendation. Symetrix assumes no
responsibility with regard to the performance or use of these products.
Under copyright laws, the content of this User's Guide remains the property
of Symetrix, Inc.
6408 216th St. SW, Mountlake Terrace, WA, USA • Tel (425) 778-7728 • Fax (425) 778-7727 • Web www.airtoolsaudio.com
Advertisement
Table of Contents
Summary of Contents for Broadcast 6000
- Page 1 6000 Broadcast Audio Delay User’s Guide Revision A07, 14 November 2005 Symetrix part number: 5360000A05 Subject to change without notice. Copyright 2002-2005, Symetrix, Inc. All rights reserved. AirTools™ is a registered trademark of Symetrix, Inc. All other trademarks referenced in this User’s Guide are the property of their respective holders.
-
Page 3: Important Safety Instructions
User Serviceable Parts. There are no user damaged, liquid has been spilled or objects have fallen serviceable parts inside the AirTools 6000. In case of into the apparatus, the apparatus has been exposed to failure, customers inside the U.S. should refer all servicing rain or moisture, does not operate normally, or has been to the Symetrix factory. -
Page 4: Table Of Contents
Remote panel LED indicator pinouts ....................14 ....................15 Typical remote panel switch wiring Typical remote panel LED wiring ....................15 C Automation wiring ______________________________________________________ 16 Automation connector pinout ....................16 D Block Diagram ______________________________________________________ 17 6000 Broadcast Audio Delay PAGE ii User’s Guide... -
Page 5: Introduction
40 seconds while keeping the audience unaware of the break. When the COUGH button is pushed, the 6000 plays from memory while the button is held in. As soon as the button is released, the 6000 automatically begins to refill the memory. -
Page 6: Summary Product Description
Further description of this feature is provided in chapter 5. • The DELAY numerical readout shows the length of delay time built up by the 6000 in tenth of a second incre- ments. -
Page 7: Rear Panel View
See chapter 4 (Installation) for details on the detachable (IEC) power cable. • The REMOTE CONTROL AND INDICATOR interface provides a way to connect to the AirTools RC-6000 or a user supplied remote control and/or indicator panel. See Appendix B for details. -
Page 8: Installation
Mounting in an equipment rack The 6000 occupies one rack space (1U) in a standard equipment rack with a width of 19" (48.3 cm), a depth of 7.8” (19.8 cm), and a height of 1.75” (4.45 cm). Allow at least 4” (10.16 cm) behind the unit for the protrusion of connectors. -
Page 9: Analog Audio Output Connections
The 6000 has been designed to operate at standard nominal broadcast signal levels of either 0 VU = +4 dBu or 0 VU = +8 dBu. To provide even more flexibility, the 6000 can also operate at -10 dBu and 0 dBu. The 6000’s operating level can be adjusted by navigating to the NOMINAL INPUT and/or OUTPUT LEVEL pages in the setup menus on the LCD display. -
Page 10: Remote Control & Indicators Connector
The sync pulses can be used to automate the start and exit for the 6000’s delay. Another use would allow for a DJ to automate the exit of the delay to coincide with a commercial break allowing the DJ to go on break without having to wait for the delay exit in real time. - Page 11 CURRENT DELAY LATE: 30 mS LATE: 60 mS LATE: 90 mS LATE: 120 mS LATE: 150 mS LATE: 180 mS LATE: 210 mS LATE: 240 mS LATE: 270 mS LATE: 300 mS 6000 Broadcast Audio Delay PAGE 7 User’s Guide...
-
Page 12: Operation
It is recommended that the 6000 remain in the OPERATE mode at all times. Typically, the 6000 would be placed in the BYPASS mode only if the unit were to malfunction. By design, a loss of mains (AC) power to the 6000 will force the 6000’s audio bypass relays to route the incoming signal directly to the 6000’s output. -
Page 13: The Cough Button
6000 time to build up to enough seconds of delay to cover the audio to be dumped then when he momentarily hits the DUMP button an obscenity may get on the air. The user has the choice of setting the 6000 to DUMP a FIFTH, FOURTH, THIRD, HALF or the WHOLE memory. -
Page 14: Troubleshooting
• Check input signal levels and input level control settings. The input may be too low in level. If so, boost the signal from your console or input source. • Is the input signal already noisy? Listen "up stream" from the 6000 to determine if you are feeding it a clean signal. -
Page 15: Warranty And Service
6000 Broadcast Audio Delay PAGE 11 User’s Guide... -
Page 16: Servicing The 6000
Servicing the 6000 If you have determined that your 6000 requires repair services and you live outside of the United States please contact your local AirTools™ dealer or distributor for instructions on how to obtain service. If you reside in the U.S. -
Page 17: A Specifications
Architects and engineers specifications The Broadcast Audio Delay shall be a stereo model whose output is delayed by as much as 40 seconds, thereby allowing the operator to delete or "dump" unwanted audio. The Broadcast Audio Delay shall occupy one rack space (1U). -
Page 18: B Remote Indicator & Control Interface Wiring
Remote Indicator & Control Interface wiring Many of the 6000’s most important control buttons and LED indicators may be wired to a user supplied panel via the DB-25 multi-pin male connector on the 6000’s rear panel. The following tables detail the pin functions. -
Page 19: Typical Remote Panel Switch Wiring
Typical remote panel LED wiring HALF WHOLE EXIT START DUMP COUGH Note: The numbers within the circles refer to pins on the 6000’s rear panel DB-25 connector which is labelled REMOTE INDICATOR & CONTROL INTERFACE. 6000 Broadcast Audio Delay PAGE 15 User’s Guide... -
Page 20: C Automation Wiring
LED 1 (A1) LED 2 (A2) LED 3 (A3) LED 4 (A4) LED Return Automation Auto In 1 Button Auto In 2 Closures Auto In 3 Auto In 4 Auto In Ground 6000 Broadcast Audio Delay PAGE 16 User’s Guide... -
Page 21: D Block Diagram
Appendix Block Diagram 6000 Broadcast Audio Delay PAGE 17 User’s Guide... - Page 22 6408 216th St. SW, Mountlake Terrace, WA, USA • Tel (425) 778-7728 • Fax (425) 778-7727 • Web www.airtoolsaudio.com Copyright 2002-2005, Symetrix, Inc. All rights reserved. AirTools™ is a registered trademark of Symetrix, Inc. All other trademarks referenced in this User’s Guide are the property of their respective holders. Under copyright laws, the content of this User’s Guide remains the property of Symetrix, Inc.
