Summary of Contents for DVIGear DVI-5314c

Page 1 User Guide DVI + Audio 1x4 Splitter / Repeater DVI-5314c...
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE PRODUCT SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 PRODUCT LIABILITY .
Page 3: Product Safety
Every effort has been made to ensure that this product is free of defects. DVIGear cannot be held liable for the use of this product or for any direct or indirect consequential damages arising from its use. It is the responsibility of the users of this product to check that it is suitable for their requirements and that it is installed correctly.
Page 4: Introduction
1 .0 INTRODUCTION The DVI-5314c is a high performance digital repeater with one (1) DVI input and four (4) independent, re-clocked DVI outputs. All inputs and outputs are HDMI v1.3 compatible, enabling full interoperability with both DVI and HDMI sources and displays.
Page 5: Specifications
+10 dB correction @ 825 MHz Maximum Input Cable Length 12.5 meters using DVIGear SHR™ Series copper cables Maximum Output Cable Length 10 meters using DVIGear SHR™ Series cables, longer if using DVIGear (ACE™) Input /Output Connectors DVI Input 1x 29-pin female DVI connector...
Page 6: Package Contents
Note: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact your reseller or DVIGear immediately. Please have the Model Number, Serial Number, and Invoice Number available for reference when you call.
Page 7: Operating The Unit
5 .0 OPERATING THE UNIT To use the DVI-5314c splitter, first connect a DVI-D or a DVI-HDMI cable from the DVI or HDMI source device to the input of the splitter. Next, connect the outputs of the splitter to their destination devices (typically displays or projectors).
Page 8 On the front of the unit there is an EDID selection switch. This switch controls what EDID information the splitter will report to the source device. The EDID information provided to the source can either be EDID from one of the connected displays (AUTO EDID Mode) or from an on-board memory chip that contains a library of the most commonly used resolutions (INT EDID Mode).
Page 9 information. In the event none of the outputs has an HDMI display connected, the splitter will use the EDID of the first DVI display that is connected as the “reference EDID” for the source device. The default factory setting for the EDID switch setting is AUTO. This setting works best for most applications.
Page 10: Troubleshooting
HDCP Repeater functionality. Note: For troubleshooting HDCP links, it can be very helpful to have a test generator that can turn HDCP On and Off manually. DVIGear’s DVI-7050a HDMI Test Generator is a good solution for this requirement.
Page 11: Limited Warranty
The liability of DVIGear with respect to any defective products will be limited to the repair or replacement of such products. In no event shall DVIGear be responsible...
Page 12 Your Digital Connectivity Experts Toll Free 888.463.9927 DVIGear, Inc. Phone 770.421.6699 1059 Triad Court, Suite 8 770.234.4207 Marietta, Georgia 30062-2258 www.dvigear.com DVI-5314c-UG-01 / March.2013...
