Summary of Contents for PLX Devices Legion
-
Page 1: User Manual
User Manual devices inc. Patents Pending © PLX Devices Inc. 2013 All Rights Reserved... -
Page 2: Table Of Contents
Intelligent OLED Display Operating Legion Charging Your Devices Charging Your Legion Toggling Menus About Legion Menus Sleep Mode Turning Your Legion ON and OFF Product Care and Maintenance Storage Battery Use and Safety Disposal Troubleshooting Resetting Legion Problem Charging Your Device... -
Page 3: Introduction
LiPo batteries can result in fire. Read ALL instructions before use. Do not use this product and its accessories in any way other than specified by PLX Devices Inc. PLX Devices Inc. is not liable for accidents or damage caused by misuse of this product. -
Page 4: Overview
Overview Accessories Included Accessories Charging Cable Additional accessories that may be purchased at www.plxdevices.com Large and Small Carrying Case 6-In-1 Charging Cable devices inc. www.plxdevices.com... -
Page 5: Intelligent Oled Display
Shows the amount of time (days:hours:minutes) remaining until Legion becomes fully charged. Shows the health of your battery. Legion keeps track of your battery’s wear and tear. Shows the number of charge cycles, battery age, and battery temperature. -
Page 6: Operating Legion
1. Connect the Micro USB end of the Retractable Cable into Legion’s Micro USB Charge In Port. 2. Insert the USB Male A end of the Retractable Cable into a power source. NOTE: Other cables can be used to charge Legion as long as the cable can connect to Legion’s Micro USB Charge In Port. -
Page 7: Toggling Menus
Time to Discharge will be displayed if nothing is plugged into Legion or if Legion is charging a device. This simply tells you how much time is left before your Legion battery needs to be charged. Time to Charge will be displayed if Legion is being charged. -
Page 8: Turning Your Legion On And Off
However, if Legion is OFF and you connect a device you would like to charge, it will not automatically turn ON. If Legion is ON and being charged, you may press and hold the button to turn off the screen and Legion will continue charging. -
Page 9: Product Care And Maintenance
The battery in Legion is not intended to be replaced by the consumer. If you believe the battery is damaged or needs to be replaced, contact technical support at www.plxdevices.com for inspection and replacement informa- tion. -
Page 10: Disposal
See Crash Damage under the Disposal section for the proper disposal process. Disposal Proper disposal of your Legion and its battery is an important aspect of product care and safety. To properly dispose the product, follow your municipal battery disposal guidelines. Visit your local electronics/hardware store for general instructions on proper disposal of mobile electronic devices with LiPo batteries. -
Page 11: Troubleshooting
NOTE: Legion can charge devices while in Sleep Mode. 3. If Legion is unable to turn ON or if the voltage reading is less than 3.4 V, recharge Legion’s battery. Legion is unable to charge devices if the battery power is too low. -
Page 12: Problem Charging Your Legion
4. If Legion does not turn ON, or if Legion is ON but is still not charging, perform a Factory Setting Reset. 5. If Legion does not turn ON, or if Legion is ON but still does not charge, there might be a problem with Legion’s hardware. -
Page 13: Technical Specifications
Patents Pending Technical Specifications Legion 5500mAh Battery Lithium Polymer 5500mAh Charge Output USB Female A 5.0V Single 1A (5500mAh) Charge Input Micro USB 5.0V Display High Contrast OLED 128 x 32 Pixels Human Interface 1 Push Button Operating Temperature 0 – 45 Deg Celsius Storage Temperature -10 –... - Page 14 PLX products with any other device(s) must be done at your own risk. LIMITED WARRANTY – PLX Devices Inc. warrants this product to be free from defects for 1 year from the date of purchase. If applicable, non-serviceable items are excluded from stated warranty. Serviceable goods must be determined by PLX Devices to be defective before any warranty or replacement is issued.
