Sintron Technology Corp
VMT-635 User Guide
V M T-635
Intel Platform, Low Power, High Performance
Design, TFT LCD and 10/100/1000 base-T
Ethernet.
User Guide Version 1.2
Address: 2880 Zanker Rd, Suite 207, San Jose CA 95134 U.S.A.
Web Site: www.sintroncorp.com Tel: 408-800 - 1413 Fax: 510-952 - 8282

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VMT-635 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sintron VMT-635

  • Page 1 Sintron Technology Corp VMT-635 User Guide V M T-635 Intel Platform, Low Power, High Performance Design, TFT LCD and 10/100/1000 base-T Ethernet. User Guide Version 1.2 Address: 2880 Zanker Rd, Suite 207, San Jose CA 95134 U.S.A. Web Site: www.sintroncorp.com Tel: 408-800 - 1413 Fax: 510-952 - 8282...
  • Page 2: Fcc Statement

    FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.  This device must accept any interference received, including interference  that may cause undesired operation. This equipment has been tested and founded comply with the limits for "a"...
  • Page 3: Copyright Notice

    Copyright Notice Copyright © 20 11 Sintron Technology Corp. , ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
  • Page 4 Check List Before using this Vehicle Mount PC , please make sure that all the items listed below are present in your package  1 x V M T-635 Vehicle Mount Terminal  1 x Power adapter (Optional)  1 x Power cord (Optional) ...
  • Page 5: Safety Precautions

    Safety Precautions  Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
  • Page 6 Safety and Warranty Please read these safety instructions carefully. Please keep this user’s manual for later reference. Please disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. For pluggable equipment, the power outlet must be installed near the equipment and must be easily accessible.
  • Page 7 Revision History Version Date Note Author  2011.07.31 First Version Pippo Huang  2011.09.06 Revised Andy Tseng  2011.10.11 Revised Andy Tseng - 6 -...
  • Page 8: Table Of Contents

    Contents CHAPTER 1 GENERAL INFORMATION ..........1 1-1 Introduction ....................1 1-2 V M T-635 Specifications ..................2 CHAPTER 2 GETTING STARTED ............4 Input / Output Devices ................4 2-1-1 V M T-635 Input / Output Devices ............4 Starting the V M T-635 &...
  • Page 9: Chapter 1 General Information

    Chapter 1 GENERAL INFORMATION 1-1 Introduction V M T-635 with fanless, low power but high performance platform design, 8.4” TFT panel with LED backlight, WLAN integration, great ability for anti-shock & vibration, IP65 protection and anti-corrosion coating with aluminum alloy housing. Both of great mobility and robust design are fitting the demands for every harsh environment applications such as logistics, transportation/ fleet management, heavy vehicles, utility and also outdoor usage.
  • Page 10: M T-635 Specifications

    1-2 V M T-635 Specifications Specifications Processor Intel Atom N450 1.66GHz 1 x 200-pin SODIMM, System Memory Max 2GB DDR2 667 1 x CF Card Processor Storage HDD (SATA interface) System SSD (SATA interface) Windows XP pro Windows XP Embedded Windows CE 6.0 8.4”...
  • Page 11 Power Input Voltage 9 - 30V DC Management Power Consumption 35W typ. Operating -15~60℃ (Default) Temperature -30~70℃ (Optional) Relative Humidity 10~95%(Non-condensing) 30G (11ms duration) Shock Environmental 1G (operating with HDD) Vibration 3G (operating with CF card) Dust & Water IP65 Protection...
  • Page 12: Chapter 2 Getting Started

    ♀♂ Chapter 2 Getting Started 2-1 Input / Output Devices 2-1-1 V M T-635 Input / Output Devices The following figure shows the I/O arrangement of the V M T-635. The backside of the chassis contains most of the connectors. USB-compatible devices can be plugged directly into USB 1, 2 the USB 2.0 port.
  • Page 13: Starting The V M T-635 & O/S Installation

    2-2 Starting the V M T-635 & O/S Installation Connect the power to DC/DC adapter, and connect the power cord to the DC Power inlet. Press the power on switch to start the V M T-635. Press “DEL” to enter the CMOS setting and check the BIOS setup. You may install your own O/S if it is not installed.
  • Page 14: Driver Installation

    2-3 Driver Installation The V M T-635 comes with a User’s Manual and Driver CD that contains most of the drivers and utilities of your needs. 1. Following the step by step to install Driver (Please refer Vehicle TerminalV M T-635Driver) include: Graphic, Chipset, VGA, Audio and LAN.
  • Page 15: The Amt Touch Driver Installation

    3-2 The AMT Touch Driver Installation AMT Touch driver software provides a consistent software interface among all AMT Touch screens and controllers. For Driver Installation, please install the “PenMount Universal Driver” for Windows XP Professional,Embedded. Just follow the step by step to install the driver.
  • Page 16 Click “PenMount Monitor” Step.1 Click “Control Panel” function key to go to next step. Step.2...
  • Page 17 Click “PenMount 6000 USB” function key to go to next step Step.3 Click “Standard Calibration” function key to go to next step Step.4...
  • Page 18 Setp 5 Correct 5 point locations on screen with the V M T-635. Screen display as follows.
  • Page 19: Install Summit Driver

    3-3 The Summit WIFI Driver Installation 3-3-1 Install Summit Driver Summit wireless card software provides driver and client utility. For Driver Installation, please install the “ ” for Windows XP Professional, Embedded. Just follow the step by step to finish the driver installation.
  • Page 20 Step 3 Click “Scan” to select your AP, and Enter the password...
  • Page 21 Step 4 Click “Main” and choose the AP which your connected...
  • Page 22: Known Issues

    KNOWN ISSUES North Bridge Chipset Configuration Video function configuration Flat Panel Type This item allows you to select 800x600 18bit...
