AT6SD

KEYBOARD

CONTROLLER

Instruction manual

(ref. Mi 3146)

Please read carefully and completely this manual before install the product

and keep for future reference

Table of Contents

Need help?

Do you have a question about the AT6SD and is the answer not in the manual?

Questions and answers

Summary of Contents for ACI Farfisa AT6SD

Page 1 AT6SD KEYBOARD CONTROLLER Instruction manual (ref. Mi 3146) Please read carefully and completely this manual before install the product and keep for future reference...
Page 2: Table Of Contents
CONTENTS 1. Advisement ………………………………………………………. 4 2. Confirming the Contents of the Package ……………………... 6 3. Main Features and Functions …………………………………. 7 4. Appearance and Function Key ………………………………… 8 5. Functions and Operations ……………………………………. 10 1) Initial Setup of Keyboard 2) Choice of Camera 3) Joystick and the Manual operation of Camera 4) Camera Setup (How to enter into OSD menu) 5) Preset Point...
Page 3: Advisement
1. Advisement CAUTION WARNING Always use the unit indoors. • The unit should never be used outdoors, or in any place where it will be Always have the unit installed by the store it was purchased from. exposed to rain or other extremes of moisture. •...
Page 4: Confirming The Contents Of The Package
3. Main Features and Functions 2. Confirming the Contents of the Package Synopsis 1) Control keyboard unit 1EA. This controller is for exclusive use for pan / tilt / zoom dome camera and speed dome camera. This is able to control a maximum of the 255 cameras, and several controllers are able to control a camera at the same time.
Page 5: Appearance And Function Key
2) Setting method of Junction box 4. Appearance and Function Key - Camera controls 1 1) Controller function button This is the input and output terminal. Connect 485+ to data + and 485– ALL Button AUX (Auxiliary) Buttons GROUP Button to data –.
Page 6: Functions And Operations
2) Choice of camera 5. Functions and Operations Main keyboard is setup for normal products. So sub keyboard needs to be setup. (If you want to use sub keyboard, please ask to the supplier of it.) First, switch “on” of dome camera, let the keyboard supply with electricity.
Page 7 4) Camera setup (How to enter into OSD menu) 5) Preset Point - OSD (On Screen Display) control The controller makes to memorise 64 sets of the individual preset This controller can be used to control speed dome camera, ptz dome position for each camera.
Page 8 - Swing speed (Moving speed of swing) 6) Swing Keypad 1-64 + ENT This function can setup of making repetitive movement of pan or tilt • Swing time: The standby time (dwell time) before starting from A or swing between 2 preset point set. When setup pan swing between B (sec.).
Page 9 - Group operation and stop 9) Spiral Function • Execution: Keypad 1-6 + GROUP Keypad 7 + MENU + ON/OFF • Stop: GROUP or Joystick This function will be supported only at speed dome camera: the fixed pan speed and tilt speed is operated at the same time that can make a If you try to stop the group of working dome camera, press “Group”...
Page 10: Maintenance And Mending
12) Brightness control of LCD 6. Maintenance and Mending Keypad 20 + MENU + Joystick up/down + CLR If the surface of the controller unit becomes dirty, turn off the power and wipe the surface with a soft, dry cloth. This function is controlling the brightness of LCD and being able to be used where there is the difference of brightness.
Page 11: Connections
7. Connections (Junction box) 8. General Specifications 1) Controller FOR PROPER OPERATION Never install the unit yourself. Item Specification • The unit should be installed by trained personnel. In/ Output terminal Modular jack I/F between Junction box Working temperature 0 °C - 40 °C -5 °C ∼...
Page 12 4) Camera control interface 6) Constitution of pin between controller and Junction box Item Specification (modular jack) Asynchronous serial interface 1 Start bit Controller Ö Ö Junction box Pin No. 8 Data bit RX-TXD Synchronization system & word lenght No Parity B +9V 1 Stop bit RX-RXD...
Page 13: Quick Reference
Mark of OSD Menu ž ž [F/F]/Joystick OSD Menu enter [F/N] OSD Menu escape ACI srl Farfisa Intercoms Via E. Vanoni,3 - 60027 - OSIMO - AN - Italy Tel. (+39) 071 7202038 - Fax (+39) 071 7202037 Email: info@acifarfisa.it http://www.acifarfisa.it...
