Summary of Contents for Angel Water A-100

  • Page 1 Angel A-100 Owner’s Manual Manufactured by: ANGEL WATER, INC. 214 S Hager Ave Barrington, Illinois 60010 Phone: 847-382-7800 • Fax: 847-382-1991 • Email: info@angelwaterinc.com Web: www.angelwaterinc.com ©2001-2009...
  • Page 2: Table Of Contents

    This owner’s manual is designed to assist owners and TABLE OF CONTENTS installers with the operation, maintenance and installation of your new water softener. It is our sincere hope that this manual Job Specification Sheet ..........Page 2 is clear, concise and helpful to both owner and installer.
  • Page 3: Soft Water Basics

    SOFT WATER BASICS Hardness Excess amounts of calcium and magnesium in water produce hardness. A water softener removes the majority of calcium and magnesium to produce softened water. Hardness is measured in terms of grains. (This grain weight is derived from the average weight of a dry grain of wheat.) When your water is tested the grain hardness is calculated and expressed as grains per gallon (gpg).
  • Page 4: Pre-Installation Check List

    To prevent these through proper air gap. unnecessary, and expensive repairs that are not covered under Bypass Valves: Always provide for the installation of a bypass warranty, Angel Water, Inc. recommends installing an in-line filter valve. system ahead of softeners.
  • Page 5: Installation Instructions

    INSTALLATION INSTRUCTIONS (All electrical & plumbing should be done in accordance to all local codes) • drain line flow control fitting. Leave at least 6” between the Do not use Vaseline, oils, other hydrocarbon lubricants or spray silicone anywhere. A silicon lubricant may be used drain line control fitting and solder joints when soldering pipes on black o-rings but is not necessary.
  • Page 6: Programming

    PROGRAMMING General Information The Angel Water, Inc. Series 100 control valve is the “brain” of your water softener. It consists of the valve body and powerhead with solid state microprocessor. The display panel (see Figure 7) consists of the LED display, power light, and five push buttons which are used in displaying and programming the water softener settings.
  • Page 7: Displays/Settings

    SET TIME OF DAY Step 1 Step 1 - Press SET CLOCK. Step 2 - Current Time (hour): Set the hour of the day using buttons. Step 2 AM/PM toggles after 12. Press NEXT to go to step 3. Step 3 - Current Time (minutes): Set the minutes of day using buttons.
  • Page 8: Manual Regeneration

    USER DISPLAYS/SETTINGS General Operation When the system is operating one of two displays will be shown. Pressing NEXT will alternate be- tween the displays. One of the displays is always the current time of day. The second display is gallons remaining. This is the number of gallons that will be treated before the system goes through a regeneration cycle.
  • Page 9: Water Softener Disinfection

    WATER SOFTENER DISINFECTION The materials of construction of your water softener will not under such trade names such as Clorox, Linco, Bo Peep, support bacterial growth nor will these materials contaminate a White Sail and Eagle Brand Bleach. If stronger solutions are water supply.
  • Page 10: Trouble Shooting

    TROUBLE SHOOTING PROBLEM CAUSE CORRECTION 1. ERROR followed by code number Error Code 1001 - Unable to recognize A. Control valve has just been serviced A. Press NEXT and REGEN for 3 seconds or start of regeneration unplug power source jack from PC Board (black wire) and plug back in to reset control valve Error Code 1002 - Unexpected stall B.
  • Page 11 TROUBLE SHOOTING PROBLEM CAUSE CORRECTION 8. Loss of resin. A. Backwash controller missing. A. Install backwash controller. B. Faulty distributor tube assembly. B. Check distributor tube assembly for cracks or holes. C. Air in water supply system. C. 1. Check for leaks in brine lines, fittings, or air check. Repair or replace.
  • Page 12: Parts Diagrams

    Angel Water, Inc. A-100 SERIES CONDITIONER & BRINE TANK ASSEMBLIES Item Description Part # Control Center-Metered 104211 Specify Size (see pages 13-17 for detailed components) Top Diffuser 101539 3&4 Mineral Tank Assembly Item 3 only Item 4 only Not Shown...
  • Page 13 FRONT COVER AND DRIVE ASSEMBLY ITEM NO. ORDER NO. DESCRIPTION When replacing the battery, align Correct positives and push down to fully seat. Battery 103460 Blue Cover Assy w/A100 Label Battery replacement is Orientation 3 volt lithium coin cell 101610 Drive Assy.
  • Page 14 INJECTOR CAP, INJECTOR SCREEN, INJECTOR, PLUG AND O-RING DESCRIPTION QTY. ITEM NO. ORDER NO. 101375 Injector Cap 102159 O-ring 135 102457 Injector Screen 102319 Injector Assy. Z Plug-Filter 101825 Injector Assy. A Black 101826 Injector Assy. B Brown 101827 Injector Assy. C Violet 101828 Injector Assy.
  • Page 15 DRAIN LINE - 3/4” QTY. ITEM NO. ORDER NO. DESCRIPTION 101414 Elbow Locking Clip Polytube Insert, 5/8” 101871 Optional Nut, 3/4” Drain Elbow 102131 Optional Drain Elbow 3/4” Male Assy 101618 Drain Elbow 3/4” Male Assy-No Vent Optional 101619 102153 O-ring 019 102406 DLFC Retainer Assy.
  • Page 16: Bypass Valve

    WATER METER AND METER PLUG ITEM NO. ORDER NO. DESCRIPTION QTY. Nut 1” QC 102141 102051* Meter Assy. 102687 Turbine Assy. 102165 O-ring 215 102321 Meter Plug Assy.** *Order number 102051 includes 102687 and 102165, which are item numbers 3 & 4. **Only used if metering is not to be done (time clock units) The nuts and caps are designed to be unscrewed or tightened by hand or with the special plastic wrench.
  • Page 17: Installation Fitting Assemblies

    INSTALLATION FITTING ASSEMBLIES QTY. QTY. ITEM NO. ORDER NO. DESCRIPTION ITEM NO. ORDER NO. DESCRIPTION Nut, 1” Quick Connect Nut, 1” Quick Connect 102141 102141 102437 Split Ring 102437 Split Ring 102165 O-Ring 215 102165 O-Ring 215 Fitting, 3/4” & 1” PVC Solv. 90 106761 Fitting, 1 PVC Male NPT Elb.
  • Page 18 Angel A-100 SERIES SYSTEM SPECIFICATIONS ED -“ELECTRONIC DEMAND” MODEL A100-24ED A100-32ED A100-32-10ED A100-48ED A100-64ED A100-96ED A100-128ED A100-160ED A100-192ED FACTORY PRESET MINUTES Backwash-1; Min Brine; Min.** Backwash-2; Min Fast Rinse; Min Refill-Minutes -High Efficiency 12.0 16.0 20.0 24.0 -Low Salting 10.7 16.0...
  • Page 19 TABLE 4 - BACKWASH NORMAL LENGTH SOFTENER Down Flow Softener* Factory Settings Grains Capacity/Lb NaCl 3500 to 2501 Backwash Normal Regenerate Backwash Normal Rinse Total TABLE 6 - PROGRAMMING OPTIONS Reserve Regeneration Days Gallons Type Override Reserve capacity automatically estimated. Regeneration occurs when gallons capacity falls below the reserve capacity at AUTO NORMAL...
  • Page 20: Warranty

    A100 SERIES Water Softeners Limited Warranty Angel Water, Inc., warrants to the original consumer purchaser that the A100 Series and the parts listed below will be free from defects in material and/or workmanship from the date of the original installation for the following time periods: Angel Water Conditioning Inc.
