ALASKA APT-14 User Manual

Personal & vehicle gps tracker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Personal & Vehicle GPS Tracker
APT-14

User Manual

Please read this user guide carefully before installation and operation!
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APT-14 and is the answer not in the manual?

Questions and answers

Related Manuals for ALASKA APT-14

Summary of Contents for ALASKA APT-14

  • Page 1: User Manual

    Personal & Vehicle GPS Tracker APT-14 User Manual Please read this user guide carefully before installation and operation!
  • Page 2 APT-14 User Manual Contents: 1) Introduction 2) Features 3) Specification 4) User interface 5) Getting started 6) Operation 7) Displaying location 8) Advanced SMS functions 9) SMS instruction examples 10) GPRS settings 11) Important points 12) Troubleshooting 13) Appendix Important This product is not to be used for covert surveillance.
  • Page 3 This is an ultra compact, affordable and easy to use solution. The Alaska Go Everywhere APT-14 is the latest real-time personal tracking and security device using cutting edge GPS/GSM technology and mapping from Google Earth.
  • Page 4 APT-14 User Manual 2. Features • No monthly subscription, contract or service charges • Supports 2 way talking via supplied earphone and microphone! • Compact size, easy to hide. Dimensions: 7.7cm x 5cm x 2.9cm • Location co-ordinates and speed request by mobile phone SMS and Google Earth •...

  • Page 5: Specifications

    APT-14 User Manual 3. Specifications Hardware Description Embedded GSM 900/1800/1900Mhz GSM module Embedded 850/900/1800/1900Mhz (optional) GPRS TCP/UDP GPS Chipset Latest GPS SiRF-Star III chipset GPS Sensitivity -158Db GPS Frequency L1, 1575.42 MHz C/A Code 1.023 MHz chip rate Channels 20 channel all-in-view tracking...

  • Page 6: User Interface

    APT-14 User Manual Humidity 5% to 95% Non-condensing Dimension 76 mm × 46 mm × 25 mm Rechargeable and replaceable 1300 mAh battery (3.7V), Voltage 5V for charging input. Charging connector DC 5V (USB port) Standby Up to 36 hours 3 LEDs showing Power, GPS and GSM status, plus other operational status.
  • Page 7 When this button is pressed, the unit will send its SOS button location information to the preset phone number by SMS, at the same time, APT-14 will dial this preset phone number. You can assign a phone number to the Quick Call B Call B button button .when this button is pressed, APT-14 will dial...

  • Page 8: Getting Started

    Wall Charger A fixed wire optional accessory (AH-W14P) is available for in car applications. (5.2) Charge battery Before you can use the APT-14, you must FULLY charge the battery by USB cable for at least 2 hours with the power off.

  • Page 9: Operation

    No matter where you are, when you want to know the position of your tracker, send a SMS or make a telephone call to your APT-14. It will report its location back to you by SMS. Compose a message in the following format, and then send it to the APT-14...
  • Page 10 .Tracking function will continually report the tracker’s position until it gets the stop command. In this continuous tracking mode, APT-14 will send one position message at a preset time interval. Step 1: Compose a message in the following format, and then send it to APT-14: ----- W+Pin-code+,+002,+XXX (Note: XXX Unit: preset minutes interval.
  • Page 11 In this example ,the SMS is Set Time (005 Min) OK This SMS confirms that APT-14 is in tracking mode now and preset time interval is 5 minutes. Step 3: APT-14 will send back position SMS at present time interval.
  • Page 12 (b) Press the Call Key B, you can hang up the call or cancel the SOS call (c) After pressing the SOS key, APT-14 does not go into a normal mode until you press Call key B to cancel the SOS call (d) About area number In different countries ,the area number may different.
  • Page 13 (6.8) Dial the preset phone number by Call B or Call C: Press the Call B button/ Call C button once, APT-14 will call the preset phone number of Call B/Call C and talk using the supplied earphone/mic. If you want to complete this call, you can hang up the calling by pressing the Call B/C button.
  • Page 14 (7.3) You can get the latitude & longitude data by sending “W+Pin-code+, +000” SMS command Code to the GPS Tracker APT-14. Input the latitude and longitude that you receive from SMS and click on search button. The Google earth will display the location map for you.
  • Page 15 APT-14 User Manual Step 3: Now you can find the exact position of the tracker.
  • Page 16 APT-14 User Manual (7.4) Or you can use local map software on Car Navigation Device, just input the Position Data.
  • Page 17 APT-14 User Manual...
  • Page 18 Call C button; = 1, only send alert SMS to the preset number When this button is pressed, = 2, only Call the preset APT-14 will dial the preset number number. = 3, Send alert SMS ,then Call the preset number...
  • Page 19 - 32 cent - 40.05 second B=1, position SMS format is NMEA 0183 Format For example: $GPRMC,072414.000,V,3114.37 63,N,12131.3255,E,0.00,0 .00,050805,*00 C=0, APT-14 does NOT hung up when one call incoming . C=1, APT-14 hangs up after 4~5 rings when call incoming D=0,...
  • Page 20 APT-14 User Manual F=0, Unit does NOT send the notice SMS to the SOS preset number when the GPS signal is weak F=1, APT-14 will send notice SMS to the SOS preset number when the GPS signal is weak G=0,...

  • Page 21: Gprs Communication Settings

    SMS to “13866668888”. (6) Send Instruction “W******,005,30” Meaning: when the speed is up 30 km/h, the APT-14 will send one Alert SMS the mobile phone linking to SOS alert 10. GPRS communication settings Step 1: Make sure that the SIM card in your APT-14 supports GPRS functionality...
  • Page 22 The length of XXXXX is in 5 digits XXXXX=00001, means time interval is 10s example:W000000,014,00003 SMS meaning: Make APT-14 send a GPRS package every 30 seconds APT-14 will response one SMS to confirm the setting . “set GPRS Timer ok/00003” Like...

  • Page 23: Important Points

    (b) Check whether the SIM card is installed. (c) Whether there is enough credit in the SIM card and that the voicemail function is disabled. (d). Check whether the SIM card in your APT-14 supports SMS function, (including send SMS and receive SMS) (e).
  • Page 24 APT-14 User Manual Appendix - Worldwide APN (Access Point Name) List...
  • Page 25 APT-14 User Manual...
  • Page 26 APT-14 User Manual...
  • Page 27 APT-14 User Manual...
  • Page 28 APT-14 User Manual...
  • Page 29 APT-14 User Manual IB. 1 revision January 2010 Customer support: support@alaskauk.com www.alaskauk.com www.alaska.dk www.youtube.com/alaskauk...
