Summary of Contents for Hi Resolution HRT008IP
- Page 1 IP DOME CAMERA HRT008IP User Manual HR0913/ver.1.0 www.hrcctv.com...
- Page 2 User Manual HRT008IP NORME GENERALI DI SICUREZZA - L’immissione sul mercato dopo il 1° luglio 2006 di prodotti non conformi al DLgs 151 del 25-07-05 (Direttiva RoHS General safety recommendations RAEE) è amministrativamente sanzionato. Sicurezza delle persone - Safety warnings...
-
Page 3: Table Of Contents
User Manual HRT008IP Sommario Intrduction..........................4 Part Name and Function ................4 1.1.1 Power Indication Light Working Status Illustration................4 1.1.2 Network Indication Light Working Status Illustration ................4 1.1.3 RESET Button Function ......................5 Installation Procedure ................. 5 1.2.1 Without Bracket ........................5 1.2.2... -
Page 4: Intrduction
User Manual HRT008IP 1. INTRDUCTION PACKAGE CONTENTS • IP camera------------------------------1 • Bracket----------------------------------1 • Micelle-----------------------------------1 • Plastic board---------------------------1 • Screws and anchors-----------------4 • Plate screws------------------------2+1 • Network cable-------------------------1 • Power cable----------------------------1 • User Manual----------------------------1 1.1 PART NAME AND FUNCTION You can refer to the following figure for IP camera part name. -
Page 5: Reset Button Function
User Manual HRT008IP 1.1.3 RESET Button Function You can click this button to restore factory default setup. After the power indication light became green, press this button for at least five seconds, you can see the system automatically reboot. After rebooting, the system restored factory default setup 1.2 INSTALLATION PROCEDURE... -
Page 6: With Bracket
User Manual HRT008IP 1.2.2 With Bracket • You can install the IP camera with the bracket together on the wall or ceiling. Connect the bracket to the IP camera and then lock firmly. You can adjust the IP camera to the corresponding angle and then lock the button firmly . -
Page 7: Ip Camera Power Cable Connection
User Manual HRT008IP 1.3 IP CAMERA POWER CABLE CONNECTION Connect the power adapter to the IP camera power port. You can see the power indication light becomes Connect network cable to the network port Note: This series IP cameras has built-in micro phone. You can also connect to external micro phone or speaker (optional). -
Page 8: System Requirement
User Manual HRT008IP 1.4 SYSTEM REQUIREMENT This series IP cameras has the following system requirement. • Processor Pentium 800MB or higher（Pentium 4, 2.4 GHz or higher recommended ） • 256 MB or higher • Display card resolution 1024×768 or higher/16-bit color or higher/16M display memory or higher/DirectX9.0c or higher •... -
Page 9: Technical Specification
User Manual HRT008IP 1.5 TECHNICAL SPECIFICATION Model Parameter HRT008IP 1/6” CMOS Pixel 300000 pixels Resolution 380 TV line Lens spec Fixed focus: 2.9mm/F2.0 Angle: 51° Illumination 1 Lux/F2.0 50dB Gamma Correction 0.45 Gain control Auto Auto Electronic shutter Auto 1 / 25 ~ 1 / 15000 Video compression H.264... -
Page 10: Wire Network
User Manual HRT008IP 1.6 WIRE NETWORK 1.6.1 Connect to LAN via internet port You can connect the IP camera to the LAN via hub or switcher . 2. CONTENTS OF CD-ROM • HR-EPSS BASIC: central management software basic version. •... -
Page 11: Usage Through The Web
User Manual HRT008IP 4. USAGE THROUGH THE WEB The camera is equipped with web server function for connecting to local or remote PC through internet explorer. 4.1 NETWORK CONNECTION Before web client operation, please check the following items: • Network camera network connection is right . - Page 12 User Manual HRT008IP After installation, the interface is shown as below. .Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. After you logged in, you can see the main window This main window can be divided into the following sections.
-
Page 13: Quick Guide To The Choice Of Software
User Manual HRT008IP 5. QUICK GUIDE TO THE CHOICE OF SOFTWARE 5.1 HR-EPSS BASIC Install the HR-EPSS Basic (Pro Enterprise Surveillance System Basic) to use the following functions: • Live playback IP devices Multiple IP devices Plans to display time •... -
Page 14: Hr-Mobile Pss
User Manual HRT008IP Install the HR-EPSS Business (Enterprise Business System Surveillance Pro) on a PC / Server in order to centralize all IP devices. The business version can be used in server mode, in which all IP devices will be added and managed in Client mode, so it’s enough connect to the server in order to handle all IP devices that it manage. -
Page 15: Www.hrcctv.com Pag
User Manual HRT008IP After you login screen looks like. Each of the devices connected to the server will be showed in list. Connecting to the device you want to see Live images recorded. If is connected camera IP, you can also control the movement. - Page 16 User Manual HRT008IP Technical specifications can be modified without any preliminary notice This manual may not be reproduced in whole or in part (except brief quotations in articles or magazines), without the 'written permission of HR EUROPE. HR EUROPE s.r.l.
