CONGRATULATIONS! We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. The entire range of products is built in compliance with the following directives: 89/106EEC(Construction Products), 89/366EEC(EMC Directive),2004/108 CE (EMC Directive), 2006/95 CE (Low Voltage Directive), EN 14785,EN60335-2-102,EN 61000-3-3, EN 50366, EN 55014-1, EN 55014-2,...
Page 4
the stripped parts of the wires. These must not escape from the terminal board in any situation, thus preventing possible contact with the live parts of the wire. Installation must be carried out by authorized staff who must provide the buyer with a declaration of conformity for the system and will assume full responsibility for final installation and as a consequence the correct functioning of the installed product.
majolica, it is recommended to use a soft, dry cloth. If a detergent or liquid is used, the latter could penetrate inside the crackles, highlighting the same. 2 Brief Introduction 2.1 Ordinary Notice The instruction book on installation, using and maintenance is an important part for the product. The...
Page 6
SINOLION LIMITED. Otherwise, the manufacturer will not burden any responsibility according to related specifications. It can only use original parts of SINOLION LIMITED. If the products are sold to other user, make sure to sell the product together with the instruction book.
220-240V, 50HZ. It will cause irregular operation or damage the electrical equipments if more than 10% of voltage variation is existed. The equipment shall be placed in a house with proper power supply. 10% voltage variation will cause ignition and using problems. It is also necessary to install a circuit breaker on the upstream.
Page 8
Model SL-0002 Heat output (min, max) 2.5-9KW Heated area (M2) Combustion efficient more than Electrical input in Watt (Min.) 0.34A-70W Electrical input in Watt (Max.) 1.17A-270W Controlled combustion system with fume temperature Recovery system Flue gas temperature Flue gas mass flow 5.5g/s Required flue draught 0.09 mbar...
4. Wood Pellet 4.1 Pellet The fuel used is called pellets; this will allow you to obtain full pleasure from the heat of the flame, without having to manually feed the combustion. Their measurements are 6mm diameter and their maximum length is 20mm.
5. Remote Control Fig 5 The following is about the function of each button on the remote control. 1:Start-up button 2: Start automatic mode. 3: Display area: including ventilation level display, function level display, ambient temperature display and auto mode display. 4: Ventilation set button 5: Power set button 6, 7: Ambient temperature set button: To set ambient temperature in auto mode, you can use...
6 Pellet Stove ON and OFF 6.1 Pellet Stove ON Before using the Pellet Stove, check whether all parts are in places. Remove all glass adhesive materials and labels at the same time to prevent existed permanent marks. Operation: (1)Connect power cord. 3...
Page 13
6.2 Pellet Stove OFF Operation (1) Press button (1) one time The screen will display ON or START. If it does not display ON or START, press button 6 repeatedly until it displays ON or START. (Fig 7 and 8, 029 in the lower pictures mean the ambient temperature is 29 degree). Fig 7 Fig 8 (2) The screen displays OFF, as in Fig 9.
Note: It is better to unplug power cord after the Pellet Stove stopped for at least 4 hours so it has cooled off completely.. 7 Control Panel and Rear Panel 7.1 Control Panel Two main command buttons are used for ventilation and power setting. Press corresponding buttons to set Pellet Stove.
Page 15
(6)Menu selection button: main menu button 6. Press button 6 repeatedly to set date, time, mode, procedure and other display windows. (7)display area (8)Infra-red sensor: Take remote control using remote control. It shall aim at the infrared sensor when using remote control. (9)Ventilation level indicator: Lev 1 is the min level and Lev 6 is the max level.
Page 16
7.3 Rear Panel The following information is on icons on rear panel: (16)Power switch0/1: Before start-up , switch to position 1. (17)Power socket of Pellet Stove 20-240V/50Hz: power cord socket (18)RESET: material-stuck reset switch( with plastic cap), It is a protecting device, At 125 degrees, the sensor in the fuel conveyor system activates the alarm and stops the feeding of pellets , or when the feeding motor is in normal operation condition, then the feeding motor is stopped running.
8 Procedure Setting 8.1 Main Menu After connecting with the power, power switch of Pellet Stove is at position “1”. Start the Pellet Stove, and the screen will display “STAR”. If it does not display STAR”, press button 6 repeatedly until STAR is displayed.
Page 18
8.2 LED Display Information The following description is on LED display information: Fig 13 Display information in Fig 13 above: STAR: Start-up condition, 029 displayed by LED display is the current ambient temperature. Press button 1, and the screen displays Star. ON: Normal condition,,...
Page 19
Fig 15 Display information in Fig 15 above: LIU: It displays the level in operation mode. 00 means in 0 level. MODE: It displays operation mode setting. 01 means in Auto mode (Fig 22), and 00 means in Manual Mode (Fig23).
Page 20
8.4 Date Setting Operation (1) Press button 6 until word ‘DATE’ is displayed on the screen, see below Fig 17 (2) Press button 15 one time, ‘5’ shining (3) Press button 3 or 4 to modify date (4) Press button 15 one time to complete the modification. The date can be set in a range of 1- 7. As in Fig 17, current set date is Friday.
Page 21
图 18 8.6 Appointment Time Setting 8.6.1 Appointment time can be set from Monday to Sunday every week. Three appoint times can be set every day. Note: The time only can be set as 24 hour (from 01 to 24); Appointment time cannot have clashing time settings (i.e.
Page 22
8.6.3 Appointment time operation (1) Press button 6 until word ‘PROG’ is displayed on the screen, B118 means version (2) Press button 3 one time, below displayed (3) Press button 15 one time, ‘00’ shining (4) Press button 3 or 4 to modify minute (5) Press button 15 one time to confirm the minute (6) ‘10’...
Page 23
appointment times cannot be set at 00:00. 8.6.4 If the user does not intend to use appointment time, press button 5 and the indicator 11 will be OFF, which means the appointment time is shut off. The user can also set the appointment at 00:00 if he does not intend to use appointment time.
Page 24
(4) Display “TEMP” (5) Press button 15 one time (6) “30” will be shining and can be modified (7) Press button 3 or 4, setting temperature what you want (8) Press button 15 one time, modified finished (9) Press button 6 for 10 times, until “MODE” display on the screen (10) Display “MODE”...
Page 25
8.9 Buzzer Setting Operation (1) Press button 6 until word ‘BUSS’ is displayed on the screen, see below Fig 26 (2) Press button 15 one time, ‘01’ or ‘00’ shining (3) Press button 3 one time to modify (4) Press button 15 one time to complete the modification. Note: The first line: BUSS means buzzer The second line: 00 means ON, 01 means OFF...
Page 26
8.10 Language Setting Operation (1) Press button 6 until word ‘LANG’ is displayed on the screen, see below Fig 27 (2) Press button 15 one time, ‘00’ or ‘01’ or ‘02’ shining (3) Press button 3 or 4 to modify (4) Press button 15 one time to complete the modification.
10 Cleaning and Maintenance 10.1 Notes Make sure the Pellet Stove is turned off and power supply is powered off before cleaning it. Clean the machine after the Pellet Stove is cooled. The Pellet Stove you used is adopted pellet fuel, and solid fuel is often used. Therefore, to ensure normal operation and excellent performance of the machine, common operation control and cleaning is necessary.
Page 29
cloth when the Pellet Stove is cooled. Note: It normal for smoke and dust and combustion residue left on the glass every day. Fig 30 Fig 31 Fig 32 Fig 33 Fig 34 Fig 39 10.4 Remote Control Battery Replacing When the infrared remote control cannot transmit signals (Light-emitting diodes), it must replace batteries in it.
Page 30
11 Smoke and the Chimney requirements Accidents are frequently caused by the smoke or chimney problems in the house. We propose the following suggestions to adjust the task of procedure installation and check whether smog produced by combustion is eliminated. The smoke discharge has shall comply with the specifications in UNI7129/92, UNI10683 and EN14785.
Page 31
low pressure combustion room, it will cause a slight pressure when the smoke is discharged from the smoke channel. To ensure the smoke exhausting system, e.g. steep pipe, is sealed and normal, it shall use red silicone to seal all connection points (which can bear 350 ℃). Pipeline coating shall use insulation materials (rock, clay fibbers), or it can also use the insulated piping system, so that internal part of the exhausting pipe can be checked and cleaned.
Page 32
12 Technical advice 12.1 Installation and Operation Suggestions 1 Never disconnect power supply. If the power is disconnected, it may cause smoke leaking into the room, which is very dangerous. Meanwhile, the machine cannot be turned off and power cannot be shut off. 2 It is prohibited to install the machine separately on the wall.
Page 33
12.2 Common Problems and Solution Abnormal Condition Cause Solution Pellet cannot drop into brazier. Pellet in the container is used up. Feed wood pellet Outsourcing materials are existed in the Clear outsourcing materials machine, such as nail, nylon, or small wood block at the bottom of container.
Page 35
SL002000095 C065BM00126 Left Panel SL002000123 C065BM00143 Ash Pan SL002000097 C065BM00128 Below Door SL002000164 Smoke Exhaust Fan SL002000098 C065BM00129 Below Cover Plate SL002000121 C065BM00140 Baffle SL002000122 C065BM00141 Brazier SL002000174 90 Temperature Switch SL002000069 C065BM00118 Handle Assembly SL002000133 Silicon Handle SL002000135 C065BM00152 Adjusting Foot SL002000096 C065BM00127...
Page 37
SL002000181 Reset Indicator SL002000180 Gear Motor Indicator SL002000179 Reset Button SL002000178 Power Switch SL002000177 Power Socket SL002000176 Rear Aluminium Panel SL002000088 Stainless Steel Hinge SL002000047 C065BM00112 Hopper Assembly SL002000168 Air Switch SL002000171 Ignitor SL002000167 Silicon Tube SL002000116 C065BM00135 Air Switch Bracket SL002000160 C065BM00154 Smoke Fan Frame Assembly...
Page 38
