RF-Link WHD-5001 User Manual

Model: WHD-5001
Wireless HD A/V sender
2.Package Contents
Check to make sure that all units shown as below are enclosed.
If something missed, please contact your dealer.
1. 5.0GHz Transmitter x1
UHF:433.92MHz
3. IR Blaster x1
5.Power Adapters x2
USA Type
2
2. 5.0GHz Receiver x1
4. HDMI Cable x1
6. Antenna x6
Contents

1.Important Safety Information....................................... 1

2.Package Content........................................................2

3.Panel Control And Function......................................... 3

4.Setup Guide...............................................................4
5.Optimizing System Performance
1.Important Safety Information
To prevent fire or shock hazard, do not expose this product to rain and
moisture. For example: do not use near a bathtub, washbowl, kitchen
sink, or laundry tub, in a wet basement, or nearby a swimming pool. To
avoid electric shock, do not take apart this product, provided as an
accessory. This product should be operated only under power supply.
Do not overload wall outlets and extension outlets as this can result in
the risk of fire or electric shock.
FCC Statement
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Note:
This equipment has been tested and found to comply with the limits regulated
by FCC and CE. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction, may cause harmful interference to
radio communications. The change or modifcations not expressly approved by
the party responsible for compliance could void the user's authority to operate
the equipment. T o comply with the FCC RF exposure compliance requirements,
no change to the antenna or the device is permitted. Any change to the antenna
or the device could result in the device exceeding the RF exposure requirements
and void user's authority to operate the device.
1
3.Panel Control and Function 2.Package Contents
List of functions
Transmitter unit
1
2
1. Dipole antenna
2. Power/Link LED indicator
3. IR windows
4. On/Off switch
5. IR Blaster jack(Transmitter only)
6. HDMI connector
7. Power adapter jack
3
..................................
Receiver unit
1
2
3
4 5 6 7
5
