For Parts Call K&T 606-678-9623 or 606-561-4983
IMPORTANT MANUAL
OPERATOR'S MANUAL
MODEL:
HD1842
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
www.mymowerparts.com
Do Not Throw Away
02478
WARNING:
Read this Man u al and follow all Warnings and
Safety Instructions. Fail ure to do so can re sult
in serious in ju ry.
195506 11.4.04 RD
Printed in U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD1842 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Poulan Pro HD1842

Summary of Contents for Poulan Pro HD1842

  • Page 1 WARNING: MODEL: Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so can re sult HD1842 in serious in ju ry. LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com 195506 11.4.04 RD...
