Nexto Extreme User Manual

Portable photo/video storage standalone, battery powered storage for cameras and camcorders

Advertisement

eXtreme
Portable Photo/Video Storage
Standalone, Battery Powered Storage for Cameras and Camcorders
English
1P ~ 30P
Deutsch
31P ~ 58P
한국어
59P ~ 84P
User Guide
Version 08/08
www.nextodi.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Extreme and is the answer not in the manual?

Questions and answers

Summary of Contents for Nexto Extreme

  • Page 1 Portable Photo/Video Storage Standalone, Battery Powered Storage for Cameras and Camcorders ● English 1P ~ 30P ● Deutsch 31P ~ 58P ● 한국어 59P ~ 84P User Guide Version 08/08 www.nextodi.com...
  • Page 2: Table Of Contents

    Thank you for purchasing this Nexto-eXtreme product. Nexto-eXtreme allows you to save photo and video files from digital cameras and camcorders to the large amount of storage space of the Nexto-eXtreme, without using a computer. The camera and camcorder can then be used to record new data.
  • Page 3: Product Description

    The Nexto-eXtreme device uses a 2.5" Serial ATA (SATA) hard drive. Data stored on the Nexto-eXtreme can later be copied to a computer – any computer that recognizes USB or eSATA drives, including PCs and Macintoshes. Nexto-eXtreme can also be used as a computer backup device.
  • Page 4: Device Diagram

    ④ Recessed Reset key, to be pressed with a tooth pick, or similar tool; turns off the Nexto-eXtreme device in the event of a hardware or software malfunction. ⑤ "DC IN" connection for AC power adapter unit (wall plug).
  • Page 5: The Nexto-Extreme Interface

    Unauthorized conversion and/or modification of the product is forbidden. Turning the Nexto-eXtreme On/Off Press and hold the control (COPY) key for 2 seconds in order to turn the Nexto-eXtreme on • Never open the product (except to install a hard drive.) This device is not user serviceable.
  • Page 6: The Built-In File Browser

    (such as USB drives.) You may also copy files from memory cards or other devices and hold the Control (COPY) key for more than one second.) to the Nexto-eXtreme’s hard drive. You may select a file or a folder to copy or delete. [NEXTOEX] At the first line of the folder tree, there is the “Exit”...
  • Page 7: Using Nexto-Extreme With Digital Cameras

    Memory slot (or "USB OTG" connection) onto the Nexto internal hard drive. Or, you can copy data from the internal hard drive onto a memory card or a USB flash drive.
  • Page 8 Copying Data from a Digital Camera or Camcorder to the Nexto-eXtreme Copying Data from a USB Flash Drive or Card Reader to the Nexto-eXtreme using a USB cable USB Flash Drive or USB Card Reader 1. Connect the USB host adapter cable to the “USB OTG” port on the bottom of the Nexto-eXtreme unit.
  • Page 9: Using The Nexto-Extreme As A Hard Drive

    1. Turn your computer on. Wait until the operating system has completely booted. See the diagram below. 2. Turn the Nexto-eXtreme on. 3. Connect the Nexto-eXtreme "USB OTG" port via the USB cable with a free USB2.0 port on eSATA your computer. A USB1.1 port can be used also.
  • Page 10: Data Backup And Verification

    Safely Remove Hardware or Unplug or Eject Hardware. When the computer notifies you that it is safe to disconnect the Nexto-eXtreme, you may remove the USB cable from the As shown on the figure, insert a memory card in the corresponding Nexto-eXtreme slot, or Nexto-eXtreme and your computer.
  • Page 11 Verify: Choose VERIFY by using a (S)hort stroke If the files on the peripheral device are entirely new, the Nexto allows you to Copy or Move (press and quickly release the COPY key.) the files to the Nexto-eXtreme’s hard drive. If some of the files have been copied before,...
  • Page 12: Advanced Functions

    So, if a folder is in insert a memory card in the built-in slots or connect a USB device to the [NEXTOEX] but not in [NEXTO], then that folder will be copied to [NEXTO]. If a folder AutoMove “USB OTG”...
  • Page 13 If you select "Sync", the Nexto-eXtreme will ask you the direction of the copy. The "Quick test" takes only a few minutes. This test uses the ● hard drive’s built-in S.M.A.R.T function. [S] USB -> Nexto: Copy new folders from [NEXTO] folder of The elapsed time is displayed during the test.
  • Page 14: Charging And Installing Batteries

    5 seconds after the The Nexto-eXtreme needs a small quantity of current at all times. Recharge the battery memory card or USB device. Choosing this insertion of a memory card or USB device.
  • Page 15: Installing And Formatting A Hard Drive

    2.5" Serial ATA hard drive; its installation height must not exceed 9.5mm. Supported The hard drive in the Nexto-eXtreme must be formatted as file system "FAT32." Only the first hard drive capacity is up to 2,000GB (two terabytes.) partition can be used by the Nexto-eXtreme.
  • Page 16 Confirm the selection with a (L)ong stroke (press and hold the key for more than 1 second). To cancel, use a (S)hort stroke If you have a spare 2.5" hard drive you may use it in the Nexto-eXtreme. If the partition (press and quickly release the COPY key.) (or the first partition, if several have been created) is a FAT32-partition, then it can be used immediately.
  • Page 17: Battery Disposal

    Memory Card Built-in CF Slot Compact Flash type 1 and type 2 / MicroDrive The LiPo rechargeable battery integrated in the Nexto-eXtreme must be removed from the Support Built-in 4in1 Slot SD / SDHC / MMC / MMCPlus / MemoryStick / housing before disposal.
