Geeya GYL - W2211 User Manual

Wireless powerline modem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's manual of Wireless Powerline Modem Product
GYL - W2211

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GYL - W2211 and is the answer not in the manual?

Questions and answers

Summary of Contents for Geeya GYL - W2211

  • Page 1 User's manual of Wireless Powerline Modem Product GYL - W2211...

  • Page 2: Table Of Contents

    Contents Chapter 1Product Overview 6.6WPS Setting 1.1Packing List 6.7WDS Setting 1.2Device Specification Chapter 7System Tool 1.3Indicators on the Front Panel 7.1Network Time Setting and Interface Specification 7.2WOL Chapter 2How to Set up Internet Access 7.3Software Upgrade 2.1Correctly Set up Your Computer 7.4Load Default Settings Network Configuration 7.5Export and Load Settings...

  • Page 3: Chapter 1Product Overview

    Chapter 1Product Overview GYL-W2211 Wireless Powerline Modem is the newest product of power line solution launched by Shenzhen Geeya Technology Co., Ltd. This Wireless Powerline Modem combines the 802.11n and the antenna technologies perfectly to maximize the rate and coverage of wireless signal with the highest physical layer transmission rate of 200Mbps, which is far better than the other 802.11g product devices.

  • Page 4: Device Specification

    1.2Device Specification Specification Parameter HomePlug AV, IEEE 802.3, IEEE 802.3u, IEEE 802.11b/g/n Support Protocol A 10/100Mbps Auto-negotiation RJ45 Network Interface AC Power Plug Power Line Interface Modulation Mode CCK,DSSS,OFDM Modulation Transmission Rate Power line: 200 Mbps, Wireless: Up to 300 Mbps Operating System Systems of Windows XP, Windows 7 etc.

  • Page 5: Indicators On The Front Panel

    1.3Indicators on the Front Panel and Interface Specification LED Indicator Specification It shows that power supply is normal, and flashing shows that it is doing the PWR Normally on encryption connecting with other PLC Panel Instruction Pictures: It shows that it has already established the Normally on connection with other electricity network adapters Flashing...

  • Page 6: Chapter 2How To Set Up Internet Access

    Button Instructions Specification Button Functional Specification Press and hold the button inside the hole for 5 seconds when power is Reset Button applied, and release to recover the initial state When you press and hold the ENY button for 2 to 3 seconds, and then ENY Encryption release, it will establish the electricity network connection with other Button...
  • Page 7 Windows XP System Configuration 1.On the desktop you are using, right-click the My 2.In the following open window, right-click the Network Places and select Property in the pop-up Local Connections and select Property; menu 3.In the pop-up dialog box, select Internet 4.In the following open window, you can Protocol (TCP/IP) and then click Property select Automatically Obtain an IP Address (0):...
  • Page 8 Windows7 System Configuration 1.Click the network icon of taskbar in the lower right 2.Click Change Adapter Settings on the corner of the desktop and click Open Network left in the open window; and Sharing Center button; 3.Right-click the Local Connections icon and click Property option in the open window;...
  • Page 9 4.Double-click the Internet Protocol Version 4 5.In the following open window, you can select (TCP/Ipv4) in the open window; Automatically Obtain an IP Address (0): After finishing setting, click OK to submit settings, and then click OK to save settings in the Property of Local Connections.

  • Page 10: Logging On To Network

    2.2Logging on to Network Management Interface The default gateway IP of Geeya GYL-W2211 is 192.168.170.1. Before logining on to Network Management Interface, users must set the terminal of Geeya GYL-W221 into 192.168.170.XXX: (XXX is 2~254) as its fixed IP. Take Windows Operating System as an example, select Use the following IP address (S) in Local Connections Property Internet Protocol (TCP/IP).

  • Page 11: Management Interface

    2.In the Login Window pops up, type the Username: admin, Password: admin, and then click Login.Here, you can select the language of Management Interface if needed. 3.If the username and password typed by the user are correct, the browser will enter the main interface of administrator mode.

  • Page 12: Chapter 3Running Status

    Chapter 3Running Status 3.1Running Status You can view the router LAN interface status, wireless status and the running time of devices in the page of running status. LAN interface status: display information of LAN interface. MAC address: display the MAC address of router LAN interface. IP address: display IP address of LAN interface.
  • Page 13 Chapter 4LAN Port Setting 4.1LAN Interface Setting Enter the LAN Interface setting interface as shown: MAC address: displays The LAN MAC address of the Wireless PowerLine AP, this value cannot be changed. IP address: the login IP address of this powerline modem LAN port. The factory address is set to 192.168.170.1.

  • Page 14: Chapter 5Plc Setting

    Chapter 5 PLC Setting 5.1PLC Setting The user can scan and manage the PLC device in the PLC setting page. Network name: the user can set network name, either “default” or “private” is OK. Please make sure device names in your network are the same, so as to enable data transmission.

  • Page 15: Chapter 6Wireless Setting

    The member list: this part is used to display the related information about power line device in network. Connecting rate: displays connecting rate of current adapters and corresponding remote adapter. Connecting status: displays the status of device in this bar. The device is connected with your network if the bar displays Connect.

  • Page 16: Wireless Security Settings

    Channel: the current channel used by router. Selecting other valid working channels from drop-down list. The optional item is between 1-13, the user can also search the best channel by clicking Best Channel Searching. Broadcast (SSID): Enable by default. Select Deactivate to ban broadcasting SSID by router, in that way, wireless client is unable to scan the SSID of router.

  • Page 17: Wireless Mac Address Filter

    6.3Wireless MAC Address Filter Wireless Setting Wireless MAC Address Filter The feature of wireless MAC address filter is based the permission that allows or prohibits the assigned client to connect with wireless network. Policy: Allow means only allow those clients who are in the list to access, Reject means only prohibit those clients who are in the list to connect.
  • Page 18 1.Select Allow in the MAC address filter. 2.Type the wireless MAC address which you allow to connect with your computer. 3.Click Save to save the setting. And you can continue adding the wireless MAC address which you want to allow. For example: the computer whose wireless WLAN card address is 00:04:10:12:27:00 has no access to your wireless network.

  • Page 19: Wireless Advanced Setup

    6.4Wireless Advanced Setup Wireless Setting Wireless Advanced Setup Options of Wireless Advanced Setup detail some performance and feature configuration of some devices. The users who are familiar with wireless network may configure the more fitted setup. However, it is advisable that ordinary users do not modify these setups.

  • Page 20: Wireless Client List

    5.RTS Threshold: set the RTS door threshold of packet. If the length of packet exceeds the RTS door threshold, the router will send the RTS to its destination to consult. The default value is 2347. 6.TX Power: Wireless launch power can be chosen between the value of 1-100. 7.Short preamble: enable or deactivate.

  • Page 21: Wps Setting

    6.6WPS Setting Wireless Setting WPS Setting WPS is the protection setting of Wi-Fi. You can add the wireless clients to the network easily by this setting without any specific key configuration. For example, the configuration of SSID, safe mode and password etc. To use this wizard to add the wireless clients to the enabled WPS wireless router, requires that this clients shall support WPS feature.

  • Page 22: Wds Setting

    Wifi protect mode: a.PIN b. PBC 6.7WDS Setting Click Extended Setting Wireless Setting WDS Setting WDS (Wireless Distribution System) is able to realize the interconnection of multiple APs in one IEEE 802.11 wireless network. With no need of wired backbone network connection, WDS can expand the coverage of wireless network through multiple APs.

  • Page 23: Chapter 7System Tool

    Note: Channels among wireless routers are needed when using WDS features. The encryption method and key should be consistent with each other. IP address should be in the same network segment. Wireless AP feature will be off when using bridge mode.
  • Page 24 7.2WOL(Wake On LAN) On this page you can wake on the PC by using the MAC address of the computer in the LAN. The wake on function of LAN broadcast a magic packet based on the MAC address of the PC within the LAN.

  • Page 25: Software Upgrade

    Note: to use the function, you need to enter the BIOS when you start the computer, and set the Low Power Mode to the Off state, the Remote Wake Up function to Enable with Boot to NIC, and then change the Wake on LAN Mode value of the advanced property of the computer network card to Magic Packet, as shown below.

  • Page 26: Load Default Settings

    7.4Load Default Settings Click the Load Default Settings button to restore all the settings of the power line AP to the factory default status. 7.5Export and load Settings Here you can backup the current router settings or restore the previous router settings. Click the Save in the Export Setting to export the configuration information of the current power line AP.

  • Page 27: Reboot

    7.6Reboot Click the Reboot to take your settings into effect. The power line AP will cut off all connections after restarting. 7.7System Settings Set the administrator account number and password. Click Extended Settings System Tool System Settings, enter the following page:...

  • Page 28: System Log

    7.8System Log In the System Log, you can view a variety of situations which occur when the system starts, and you can also see if there are network attacks. Click Extended Settings System Tool Modify Login Information, enter the following page: If you want to view the log information of the wireless powerline modem in outside network, you can select to Enable remote System Log function and enter a remote IP address and save it.

  • Page 29: Traffic Statistics

    7.9Traffic Statistics This page used to display the current system memory usage, WLAN, LAN and WAN networks to send and receive data packets to the number. Appendix One: the Explanation of Common Wireless Nouns Channel If there is only a AP in the same area, you can select any AP channel and set to Auto Select by default. If there are several APs in the same area, you need to configure to each channel to fully reduce the frequency interference of APs adjacent to each other.
  • Page 30 The Wireless Network Service Set Identifier (SSID) You can specify the Wireless Network Service Set Identifier (SSID) according to the need, for example, to specify the Wireless Network Service Set Identifier (SSID) to the company name or others. To make sure that the wireless network card can roam between different APs, you need to set the same Wireless Network Service Set Identifier (SSID) for these APs.

  • Page 31: Appendix Two: Product Characteristics

    Appendix Two: Product Characteristics Support the HomePlug AV, IEEE 802.11b/g/n, IEEE 802.3 and IEEE 802.3u standards The high-gain omni-directional antenna, its signal is powerful, and its transmission distance is longer. The rate of wireless transmission is highly 300Mbps. The rate of Power line transmission is highly 200Mbps. Provide a Ethernet (LAN) interface of 10/100M self-adapting which is connected with the LAN.
  • Page 32 Please check whether the network wire which connects the wireless powerline modem device is good, and whether its corresponding network wire interface indicator is bright? Sometimes it does not mean the network wire is passing when the indicator is bright. Please check whether the PC sets IP segment the same as the wireless powerline modem gateway (the default gateway IP is 192.168.170.1, the subnet mask is 255.255.255.0, see the section 2.2 Logging on to Network Management Interface for the setting process).

  • Page 33: Appendix Four: Clear Wireless

    Appendix Four: Clear Wireless Configuration Files After changing the wireless settings of the wireless powerline modem, the corresponding configuration files will not change. This may cause some phenomenon such as disconnection or connection exception and so on. So you should clear the corresponding configuration files when you change the wireless settings of the router.
  • Page 34 Windows7 system clear wireless configuration files: 1.Right-click the Network icon and then click Property, 2.Click the Manage Wireless Network button on the left in the pop-up windows.
  • Page 35 3.You can just delete the corresponding wireless configuration files in the Wireless Network Management.

  • Page 36: Appendix Five: The Toxic And

    Appendix Five: the Toxic and Hazardous Substance List of Products Affirmation of the Toxic and Hazardous Substances in the Electronic Information Products Toxic and Hazardous Substances or Elements Component Polybrominated Hexavalent Polybrominated Lead Mercury Cadmium Names Chromium Biphenyls Diphenyl Ethers (pb) (Hg) (Cd)
  • Page 37 Contact us: Address: Floor 8, Fucheng Technology Building, Gaoxinnanyi Street, Nanshan District, Shenzhen City, Guangdong Province Postcode: 518057 Technical Support Phone: 0755-86377078 Fax: 0755-86377078-8002 Website: www.szgeeya.com...
