Summary of Contents for MicroResearch Gravitech Group I2C-DAC I2C
- Page 1 I2C-DAC C 8-Bit Digital-to-Analog Converter User Manual GRAVITECH.US uResearch GRAVITECH GROUP Copyright © 2007 MicroResearch GRAVITECH GROUP WWW.GRAVITECH.US...
-
Page 2: User Manual
I2C-DAC C 8-Bit Digital-to-Analog Converter User Manual Description Features The I2C-DAC board is a 6-pin CMOS 8-bit • Up to 2 devices on the same bus digital-to-analog converter device using • Resolution: 8-bit bus. There external Fast Update Rate: 188 KSPS components required. -
Page 3: Pin Configuration
I2C-DAC C 8-Bit Digital-to-Analog Converter User Manual Pin Configuration VOUT (1) NC (6) GND (2) SCL (5) VCC (3) SDA (4) Pin No. Name Type Description VOUT Output Analog output voltage from DAC Supply ground Supply voltage Serial data line Input Serial clock line No connect... -
Page 4: Module Configuration
I2C-DAC C 8-Bit Digital-to-Analog Converter User Manual output, which gives an output range of 0 V Power-on LED: to VCC. It is capable of driving a load of 2 kΩ in parallel with 1000 pF to GND. The source and sink capabilities of the output The green LED on the module is amplifier can be seen in the typical illuminating when the power applied. - Page 5 I2C-DAC C 8-Bit Digital-to-Analog Converter User Manual Below are the default settings from the manufacture. Copyright © 2007 MicroResearch GRAVITECH GROUP WWW.GRAVITECH.US...
- Page 6 I2C-DAC C 8-Bit Digital-to-Analog Converter User Manual Notes Contact Us We maintain a website where you can get For sales questions or to place and order, information products, obtain direct your e-mails to sales@gravitech.us. literature and download support files. Visit Refer to our website for product pricing, us online at: shipping rates, payment instructions, and...
