ACE R/C 1400 Glider Operation Manual

R/c sailplane
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Whisper 1400 Glider
Distributed by Ace Hobby Distributors, Inc. • 116 W 19th ST, Higginsville, MO 64037
Phone: 660-584-7121 • www.acehobby.com • E-mail: acehobby@ctcis.net
Warranty
This kit is guaranteed to be free from defects in material and workmanship at the date of purchase. It does not
cover any damage caused by use or modification. The warranty does not extend beyond the product itself and is limited
only to the original cost of the kit.
By the act of building this user-assembled kit, the user accepts all resulting lliability for damage caused by the
final product. If the buyer is not prepared to accept this liability, it can be returned new and unused to the place
of purchase for a refund.
Notice: Adult Supervision Required
This is not a toy. Assembly and flying of this product requires adult supervision.
Read through this book completely and become familiar with the assembly and flight of this airplane. Inspect all
parts for completeness and damage. If you encounter any problems, call 660-584-6724 for help.
Operation Manual
Ace R/C Whisper 1400 Glider R/C Sailplane (4104-F)
Specifications:
Wingspan:
55"(1400mm)
Length:
32.5"(825mm)
Wing area:
323 sq. in.
Weight:
16 oz.(453g)
JE6103
