  • Page 1 Matrix2000 User Guide - CPD Advanced Analog Fire Alarm Control Panel 4 – 24 Zones Version: 2.0 Revision: 0.2...
  • Page 2 IMPORTANT INFORMATION Limitation of liability It is mandatory, Matrix2000 panel to be installed in accordance with this manual, applicable codes, and the instructions of the Authority Having Jurisdiction. The manufacturer shall not under any cir- cumstances be liable for any incidental or consequential damages arising from loss of property or other damages or losses owing to the failure of products beyond the cost of repair or replacement of any defective products.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. General Description 2. Keyboard Indications and Controls 2.1 POWER Indication 2.1.1 Battery faults 2.2 System FAULT indication (General Fault) 2.3.1 SIGNALING DEVICE fault 2.3.2 EARTH fault 2.3.3 AUX POWER Fault 2.4 Zone Fault indications 2.5 System ALARM indication 2.6 Zones ALARM indications 3.
  • Page 4: General Description

    4 to 24 zones. There are six (6) basic models for the Matrix2000 panel: Model Zones...
  • Page 5: Battery Faults

    (c) Blown main power fuse or PSU fuse. In the above cases, SYSTEM FAULT indicator turns ON and the on board buzzer sounds continuously. 2.1.1 Battery faults Matrix2000 panel uses a battery fault detection system that will generate a battery fault indication in the following cases: •...
  • Page 6: Signaling Device Fault

    In case (b) as listed above the System FAULT indication will turn ON and the Zones FAULT indication of the corresponding zone will blink (Figure 2, Pattern b). At the same time there is also an audible notification from the on board Buzzer. Matrix2000 - Advanced Analog Fire Alarm Control Panel...
  • Page 7: System Alarm Indication

    All the indications will turn OFF automatically after all problems are restored. Software Watchdog Matrix2000 panel contains a watchdog circuit that will activate when the micropro- cessor is either faulty or unable to execute the programmed firmware. Upon detection, the Fault relay, the on board sounder and the fault indicator on the user interface are all activated.
  • Page 8: Central Electric Keyswitch

    Control Enable position and pressing the RESET button. The key from the Keyswitch can be removed only when the keyswitch is in the Normal position. Matrix2000 - Advanced Analog Fire Alarm Control Panel...
  • Page 9: Controls Via Keypad

    If any of the zones is in bypass state the buzzer sounds every 1 minute to re- mind the user of the existing disablement. Matrix2000 - Advanced Analog Fire Alarm Control Panel...
  • Page 10 Matrix2000 Fire Alarm Control Panel Operating Instructions RESPONDING TO ALARM SIGNALS PERIODIC TEST RECOMMENDATIONS See “Maintenance,” in the Installa- Matrix2000 Evacuate the area. tion and Operation manual (Section 14, page Notify the proper authorities immediately 18). and state the nature and location of the emergency.
  • Page 11 Zone 10:______________________________________________________________________ Zone 11:______________________________________________________________________ Zone 12:______________________________________________________________________ Zone 13:______________________________________________________________________ Zone 14:______________________________________________________________________ Zone 15:______________________________________________________________________ Zone 16:______________________________________________________________________ Zone 17:______________________________________________________________________ Zone 18:______________________________________________________________________ Zone 19:______________________________________________________________________ Zone 20:______________________________________________________________________ Zone 21:______________________________________________________________________ Zone 22:______________________________________________________________________ Zone 23:______________________________________________________________________ Zone 24:______________________________________________________________________ 11 11 Matrix2000 - Advanced Analog Fire Alarm Control Panel...
  • Page 12 Document Part Number: MATRIX-UG01, CPD version 2.0, revision 0.2 - November 2010...
